Table of Contents
Let us continue our Ansible Tutorial with Ansible vault. Ansible version 2.3 supports encrypting single variables using an Ansible single encrypted variable with the !vault
tag. In this article we will see some ansible vault examples of how we will use this in our playbooks.
Ansible Vault is a command line utility, by default installed along with Ansible. It allows us to encrypt secrets such as keys, credentials, passwords, and so on to include in our playbooks. By doing this, we can also use these encrypted files to share with others as they contain password protection to access the encrypted data. We can use this feature to encrypt our variables, templates, and files inside our playbooks.
1. Ansible vault encrypt file
With ansible-vault
you can encrypt any structured data file used by Ansible. So ansible vault encrypt file can encrypt files or playbooks used by Ansible. You can check man page of ansible-vault to get the list of supported arguments
The --ask-vault-pass
and --vault-password-file
options can be used as long as only a single password is needed for any given run. We will use this in upcoming chapters.
Alternatively the --vault-id
option can be used to provide the password and indicate which vault label it’s for. Here ansible vault encrypt file is performed using default
vault-id label:
[ansible@controller base]$ ansible-vault create --vault-id @prompt secret.yml New vault password (default): Confirm new vault password (default):
Once the passphrase is entered, ansible vault encrypt file opens using default editor and we're able to put content into the file, as shown below:
--- - name: This is a secret file hosts: server2.example.com tasks: - name: Execute command 'date' command: date
Now, we save our playbook file. Post ansible vault encrypt file if we try to read the contents, we'll see that they are in fact encrypted, with a small header hint for Ansible to use later
[ansible@controller base]$ cat secret.yml
$ANSIBLE_VAULT;1.1;AES256
61383366323932306663616165376432623838373662636464313136373833313533393961623139
3433326563386161393130626539643763643439656236320a646365363666396562626563333032
34623939363131366337643131653564646437353130666636393033393866346361646666326361
3239633533386466360a653436666665333365346462373935383030326563313263663962663866
66336532633662633930363864343537353265323565333535363634303038653133383465333237
34316431666139633530323566303636353437343362303961613563316261353532356663623064
35313735626234363131626662326463656163393630386232646561653233336536656431613832
39353837313531623934366663333662663966396237386337373235666237303766316431616363
65663635316631383539393935336636393838363033323831386163373265663935623734353563
6566306531623365623830623437363939376366386465383566
As you can see from the headers, AES256 is used for Vault encryption at present, meaning that as long as you use a good password when creating your Vault, your data is very secure.
2. Ansible vault view encrypted files
As you see now we cannot see the content of our encrypted file. So to view the encrypted file content using ansible vault use ansible-vault view
command with the playbook file as shown in the below ansible vault example:
[ansible@controller base]$ ansible-vault view --vault-id @prompt secret.yml Vault password (default): --- - name: This is a secret file hosts: server2.example.com tasks: - name: Execute command 'date' command: date
3. Ansible vault edit encrypted files
Once a file has been encrypted with ansible-vault
, it cannot be directly edited. Opening the file in an editor would result in the encrypted data being shown. Making any changes to the file would damage the file and Ansible would be unable to read the contents correctly. We must use ansible vault edit to first decrypt the contents of a file, allow us to edit those contents, and then encrypt the new contents before saving it back to the file.
To edit our ansible vault encrypt file secret.yml
, use ansible-vault edit
with the playbook file which will prompt for the password before decrypting and opening the editor
[ansible@controller base]$ ansible-vault edit secret.yml Vault password:
ansible-vault
opens uses default editor with a temporary file as the file path. The editor will save this, and then ansible-vault
will encrypt it and move it to replace the original file
4. Use ansible vault password file
In our earlier ansible vault example we used vault-id
to encrypt the playbook, now here we will use ansible vault password file method for encryption. You can create a plain text file and provide your password in the file which we will further use to ansible vault encrypt file.
Here in this ansible vault example I am storing my password (mypassword
) in a temporary password_file
[ansible@controller base]$ echo "mypassword" > password_file
Now you can use this password file to create or edit ansible vault encrypt file.
[ansible@controller base]$ ansible-vault edit --vault-id password_file secret.yml
OR
[ansible@controller base]$ ansible-vault edit --vault-password-file password_file secret.yml
You can use either directive with ansible vault password file to create/edit/view the playbook file.
5. Ansible vault example to encrypt existing file
The previous ansible vault examples all dealt with creating new encrypted files using the create
subcommand. But what if we want to encrypt an existing playbook file? You can use ansible-vault encrypt
in such scenario:
I have an existing un-encrypted playbook file secret_conditonal.yml
which I wish to ansible vault encrypt file by prompting for the new password. Here I am not using any ansible vault password file, instead I will use ansible-vault
with default label:
[ansible@controller base]$ ansible-vault encrypt --vault-id @prompt secret_conditonal.yml New vault password (default): Confirm new vault password (default): Encryption successful
So our ansible vault encrypt file was successful. Next you can try to check the content of the file, it should be encrypted:
[ansible@controller base]$ cat secret_conditonal.yml
$ANSIBLE_VAULT;1.1;AES256
33303661356362363565383834623763353431346135393634366164613733633639393338313333
3865353734336139653266386431356537663033363565620a643763366666323462353365653634
34323338363534663063336633626433653266376633623039353261303261616137343266336133
6430646335633065360a393637663738363739346365323932623332653631356261643865376432
61663836373262373631633733363831393937363461373938326533366231663734653139336436
33326564666437363462636163313466363733396636666361393464636363353739363331653936
63386638623261343662633764333931643431303439306531313437333066303936623466316433
3939643536366463343362383937656330313832333064653934
6. Ansible vault change password of encrypted files
Over time, as contributors come and go, it is a good idea to rotate the password used to encrypt your secrets. Encryption is only as good as the protection of the password. ansible-vault
provides a subcommand that allows us to change the password named rekey
You can use below command to get the list of available supported parameters with "rekey
"
[ansible@controller base]$ ansible-vault rekey --help
We use --ask-vault-pass
to prompt ansible-vault
for password change.
[ansible@controller base]$ ansible-vault rekey --ask-vault-pass secret.yml Vault password: New Vault password: Confirm New Vault password: Rekey successful
So we successfully changed our ansible-vault
password for secret.yml
playbook file
7. Ansible vault decrypt file
You can also use ansible vault decrypt file to decrypt playbook files in Ansible. If at some point, the need to encrypt data files goes away, you can use ansible-vault decrypt
subcommand to remove encryption for one or more encrypted files. Instead of using ansible vault password file I will use --ask-vault-pass
. Check below ansible vault example:
[ansible@controller base]$ ansible-vault decrypt --ask-vault-pass secret.yml Vault password: Decryption successful
So we were able to ansible vault decrypt file here. Now you can use any editor to view the content of your playbook file.
8. Using ansible vault in playbook
- For using ansible vault in playbook, we need to be able to inform
ansible-playbook
how to access any encrypted data it might encounter. - Unlike
ansible-vault
, which exists solely to deal with file encryption or decryption, ansible-playbook is more general-purpose, and it will not assume it is dealing with encrypted data by default. - Luckily, all of our familiar --vault-id parameters from the previous examples work just the same in ansible-playbook as they do in
ansible-vault
and requires no special handling using ansible vault in playbook - Ansible will hold the provided passwords and IDs in memory for the duration of the playbook execution.
I have a secret.yml
playbook file with below content
--- - name: This is a secret file hosts: server2.example.com tasks: - name: Execute command 'date' command: date
In the below ansible vault example, We will execute this playbook with "--vault-id @prompt
" which will prompt us with the password for the yml file before processing the playbook.
[ansible@controller base]$ ansible-playbook --vault-id @prompt secret.yml Vault password (default): PLAY [This is a secret file] ************************************************************************************ TASK [Gathering Facts] ****************************************************************************************** ok: [server2.example.com] TASK [Execute command 'date'] *********************************************************************************** changed: [server2.example.com] PLAY RECAP ****************************************************************************************************** server2.example.com : ok=2 changed=1 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
So here we are using ansible vault in playbook, after we provide the password ansible-playbook will process the yml file tasks.
9. Using Ansible playbook with vault password file
We know Ansible is all about automating things but with the above example, ansible-playbook prompts for user input to get the password so this can be a problem with some org. To overcome you can create a plan text hidden file which contains the password of the playbook. For example I have created a text file password_file which contains my password
[ansible@controller base]$ echo "password" > password_file
Now I can re-reun my ansible playbook with this vault password file using the below syntax
[ansible@controller base]$ ansible-playbook secret.yml --vault-password-file=password_file
10. Ansible vault encrypt string
Before the release of Ansible 2.3, secure data had to be encrypted in a separate file. Now we don't need to encrypt entire file and instead we can only ansible vault encrypt string such as passwords from the playbook file. You can use encrypt_string
subcommand of ansible-vault, which produces an encrypt string that can be placed into an Ansible YAML file.
In the below ansible vault example we have a sample playbook file where we use ansible vault encrypt string
[ansible@controller base]$ cat secret1.yml --- - name: inline secret variable demonstration hosts: server1.example.com gather_facts: false vars: my_secret: secure_password tasks: - name: print the secure variable debug: var: my_secret
Now here in the YML file we have provided the password secure_password
in plain text format. Anybody can open this yml file and get the password information which is insecure. So we can either encrypt the entire yml file or we also have an option to encrypt only the secure_password
string using ansible vault encrypt string.
To encrypt secure_password
string use the below command, again here we use default vault-id label:
[ansible@controller base]$ ansible-vault encrypt_string --vault-id @prompt secure_password New vault password (default): Confirm new vault password (default): !vault | $ANSIBLE_VAULT;1.1;AES256 32373330386330643061613237393466393363333031303965383063316338393261616134353233 6364623038303966323834396636646463613837373461380a303662373161393466326139383565 64396538393562343464666337633337353130306365666637373266393965633766366436623836 3430396234626533340a613637393563333131626665626535393462653139346563383062343535 6335 Encryption successful
The ansible vault encrypt string is successful. This gives us the encryption key for secure_password
string which we will use in our ansible vault example playbook file in the below format
[ansible@controller base]$ cat secret1.yml
---
- name: inline secret variable demonstration
hosts: server1.example.com
gather_facts: false
vars:
my_secret: !vault |
$ANSIBLE_VAULT;1.1;AES256
32373330386330643061613237393466393363333031303965383063316338393261616134353233
6364623038303966323834396636646463613837373461380a303662373161393466326139383565
64396538393562343464666337633337353130306365666637373266393965633766366436623836
3430396234626533340a613637393563333131626665626535393462653139346563383062343535
6335
tasks:
- name: print the secure variable
debug:
var: my_secret
As you see I have replaced secure_password
string with the encrypted key we got from ansible vault encrypt string command above:
Now you can re-reun this ansible using ansible vault in playbook:
[ansible@controller base]$ ansible-playbook --vault-id @prompt secret1.yml Vault password (default): PLAY [inline secret variable demonstration] ********************************************************************* TASK [print the secure variable] ******************************************************************************** ok: [server1.example.com] => { "my_secret": "secure_password" } PLAY RECAP ****************************************************************************************************** server1.example.com : ok=1 changed=0 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
Note that the playbook runs exactly as it did the first time we tested it, when all the data was open for the world to see. Now, however, we have successfully ansible vault encrypt string in an otherwise unencrypted YAML playbook.
What’s Next
Next in our Ansible Tutorial we will provision AWS EC2 instances using Ansible where we will launch and manage EC2 instances using ansible playbook
