In my last article I shared the steps to configure controller node in OpenStack manually, now in this article I will share the steps to configure and build ceph storage cluster using CentOS 7. Ceph is an open source, scalable, and software-defined object store system, which provides object, block, and file system storage in a single platform. Ceph has a capability to self-heal, self-manage, and does not have a single point of failure. It is a perfect replacement for a traditional storage system and an efficient storage solution for the object and block storage of cloud environments.

How to configure or build ceph storage cluster in Openstack ( CentOS 7 )



Before we start with the steps to build ceph storage cluster, let us understand some basic terminologies

Monitors:

A Ceph Monitor (ceph-mon) maintains maps of the cluster state, including the monitor map, manager map, the OSD map, and the CRUSH map. These maps are critical cluster state required for Ceph daemons to coordinate with each other. Monitors are also responsible for managing authentication between daemons and clients. At least three monitors are normally required for redundancy and high availability.

Managers:

A Ceph Manager daemon (ceph-mgr) is responsible for keeping track of runtime metrics and the current state of the Ceph cluster, including storage utilization, current performance metrics, and system load. The Ceph Manager daemons also host python-based plugins to manage and expose Ceph cluster information, including a web-based dashboard and REST API. At least two managers are normally required for high availability.

Ceph OSDs:

A Ceph OSD (object storage daemon, ceph-osd) stores data, handles data replication, recovery, rebalancing, and provides some monitoring information to Ceph Monitors and Managers by checking other Ceph OSD Daemons for a heartbeat. At least 3 Ceph OSDs are normally required for redundancy and high availability.



My infrastructure detail.

We will build ceph storage cluster with two nodes ceph storage with one OSD per storage node and one admin node where we will perform most of our tasks. So in total we have three virtual machines running on Oracle Virtual Box on top of my Windows laptop.

Below are the configuration I have used for my storage and admin nodes

 adminstorage1storage2
OSCentOS 7CentOS 7CentOS 7
Disk 110 GB10 GB10 GB
Disk 24 GB4 GB4 GB
RAM4 GB4 GB4 GB
vCPU222
Network10.0.2.1010.0.2.1310.0.2.14
Hostnamecontrollerstorage1storage2



About ceph-deploy tool

ceph-deploy is the official tool to deploy Ceph clusters. It works on the principle of having an admin node with SSH access (without password) to all machines in your Ceph cluster; it also holds a copy of the Ceph configuration file. Every time you carry out a deployment action, it uses SSH to connect to your Ceph nodes to carry out the necessary steps. Although the ceph-deploy tool is an entirely supported method, which will leave you with a perfectly functioning Ceph cluster, ongoing management of Ceph will not be as easy as desired. Larger scale Ceph clusters will also cause a lot of management overheads if ceph-deploy is to be used. For this reason, it is recommended that ceph-deploy is limited to test or small-scale production clusters, although as you will see, an orchestration tool allows the rapid deployment of Ceph and is probably better suited for test environments where you might need to continually build new Ceph clusters.



Install pre-requisite rpms

To get the required rpms to build ceph storage cluster we need to install epel repo and enable ceph repo
Install the latest available epel repo on your admin node

# yum install -y https://dl.fedoraproject.org/pub/epel/epel-release-latest-7.noarch.rpm

Add the Ceph repository to your yum configuration file at /etc/yum.repos.d/ceph.repo with the following command. Replace {ceph-stable-release} with a stable Ceph release (e.g., mimic.)

# cat /etc/yum.repos.d/ceph.repo
[ceph-noarch]
name=Ceph noarch packages
baseurl=https://download.ceph.com/rpm-mimic/el7/noarch/
enabled=1
gpgcheck=1
type=rpm-md
gpgkey=https://download.ceph.com/keys/release.asc

Next install ceph-deploy:

# yum -y install ceph-deploy



Configure NTP

To build ceph storage cluster it is very important that all the nodes part of the cluster are in time sync with each other. So NTP is very important. Install the ntp package and configure your ntp.conf with your nearest server

# yum -y install ntp

My server pool list are as below which I have added in my ntp.conf

server 0.asia.pool.ntp.org
server 1.asia.pool.ntp.org
server 2.asia.pool.ntp.org
server 3.asia.pool.ntp.org

Next start and enable your ntp daemon on both the storage node

# systemctl start ntpd

# systemctl enable ntpd



Create ceph user

The ceph-deploy utility must login to a Ceph node as a user that has passwordless sudo privileges, because it needs to install software and configuration files without prompting for passwords.

We will create a new user ceph on both the storage nodes

# useradd ceph
# echo redhat | passwd --stdin ceph

Give sudo permission to the “ceph” user

# echo "ceph ALL = (root) NOPASSWD:ALL" | sudo tee /etc/sudoers.d/ceph
# chmod 0440 /etc/sudoers.d/ceph



Enable Passwordless SSH

Since ceph-deploy will not prompt for a password, you must generate SSH keys on the admin node and distribute the public key to each Ceph node. ceph-deploy will attempt to generate the SSH keys for initial monitors.

Generate ssh-keys on the admin node

# ssh-keygen -t rsa

Next copy the public key to the target storage nodes

# ssh-copy-id ceph@storage1
# ssh-copy-id ceph@storage2

Modify the ~/.ssh/config file of your ceph-deploy admin node so that ceph-deploy can log in to Ceph nodes as the user you created without requiring you to specify --username {username} each time you execute ceph-deploy. This has the added benefit of streamlining ssh and scp usage.

# cat ~/.ssh/config
Host storage1
   Hostname storage1
   User ceph
Host storage2
   Hostname storage2
   User ceph



Validate connectivity

Now since our password less is setup it is time to validate the connectivity

# ssh ceph@storage1
Last login: Sat Nov 17 12:48:38 2018 from 10.0.2.10
[ceph@storage1 ~]$ logout
Connection to storage1 closed.

# ssh ceph@storage2
Last login: Sat Nov 17 12:30:31 2018 from 10.0.2.13
[ceph@storage2 ~]$ logout
Connection to storage2 closed.

So all looks good.



Open firewall ports

During your POC stage you can also stop and disable the firewall to make sure the config works. But before going to production the firewall must be enabled again

On monitors

# firewall-cmd --zone=public --add-service=ceph-mon --permanent

On OSDs

# firewall-cmd --zone=public --add-service=ceph --permanent

Once you have finished configuring firewalld with the --permanent flag, you can make the changes live immediately without rebooting:

# firewall-cmd --reload



Handle Selinux

On CentOS and RHEL, SELinux is set to Enforcing by default. To streamline your installation, we recommend setting SELinux to Permissive or disabling it entirely and ensuring that your installation and cluster are working properly before hardening your configuration. To set SELinux to Permissive, execute the following:

# setenforce 0

Ensure that your package manager has priority/preferences packages installed and enabled. On CentOS, you may need to install EPEL. On RHEL, you may need to enable optional repositories.

# yum install yum-plugin-priorities

Create a directory on your admin node for maintaining the configuration files and keys that ceph-deploy generates for your cluster.

# mkdir my-cluster

and navigate inside this directory as the ceph-deploy tool will create all the required configuration file in your current working directory

# cd my-cluster



Steps to build ceph storage cluster

The ceph-deploy tool operates out of a directory on an admin node.

On your admin node from the directory you created for holding your configuration details, perform the following steps using ceph-deploy.

Create the cluster:

# ceph-deploy new storage1 storage2

Check the output of ceph-deploy with ls and cat in the current directory. You should see a Ceph configuration file (ceph.conf), a monitor secret keyring (ceph.mon.keyring), and a log file for the new cluster.

If you have more than one network interface, add the public network setting under the [global] section of your Ceph configuration file. See the Network Configuration Reference for details.

public network = 10.1.2.0/24

to use IPs in the 10.1.2.0/24 (or 10.1.2.0/255.255.255.0) network



Install Ceph packages from your admin node:

# ceph-deploy install storage1 storage2
<< Output trimmed >>
[storage2][DEBUG ]
[storage2][DEBUG ] Complete!
[storage2][INFO  ] Running command: sudo ceph --version
[storage2][DEBUG ] ceph version 13.2.2 (02899bfda814146b021136e9d8e80eba494e1126) mimic (stable)
NOTE:
The ceph-deploy utility will install Ceph on each node.

Check the ceph version from your storage nodes

[root@storage1 ~]# ceph --version
ceph version 13.2.2 (02899bfda814146b021136e9d8e80eba494e1126) mimic (stable)

Deploy the initial monitor(s) and gather the keys:

# ceph-deploy mon create-initial
<< Output trimmed >>

[storage1][DEBUG ] fetch remote file
[storage1][INFO  ] Running command: sudo /usr/bin/ceph --connect-timeout=25 --cluster=ceph --admin-daemon=/var/run/ceph/ceph-mon.storage1.asok mon_status
[storage1][INFO  ] Running command: sudo /usr/bin/ceph --connect-timeout=25 --cluster=ceph --name mon. --keyring=/var/lib/ceph/mon/ceph-storage1/keyring auth get client.admin
[storage1][INFO  ] Running command: sudo /usr/bin/ceph --connect-timeout=25 --cluster=ceph --name mon. --keyring=/var/lib/ceph/mon/ceph-storage1/keyring auth get client.bootstrap-mds
[storage1][INFO  ] Running command: sudo /usr/bin/ceph --connect-timeout=25 --cluster=ceph --name mon. --keyring=/var/lib/ceph/mon/ceph-storage1/keyring auth get client.bootstrap-mgr
[storage1][INFO  ] Running command: sudo /usr/bin/ceph --connect-timeout=25 --cluster=ceph --name mon. --keyring=/var/lib/ceph/mon/ceph-storage1/keyring auth get client.bootstrap-osd
[storage1][INFO  ] Running command: sudo /usr/bin/ceph --connect-timeout=25 --cluster=ceph --name mon. --keyring=/var/lib/ceph/mon/ceph-storage1/keyring auth get client.bootstrap-rgw
[ceph_deploy.gatherkeys][INFO  ] Storing ceph.client.admin.keyring
[ceph_deploy.gatherkeys][INFO  ] Storing ceph.bootstrap-mds.keyring
[ceph_deploy.gatherkeys][INFO  ] Storing ceph.bootstrap-mgr.keyring
[ceph_deploy.gatherkeys][INFO  ] keyring 'ceph.mon.keyring' already exists
[ceph_deploy.gatherkeys][INFO  ] Storing ceph.bootstrap-osd.keyring
[ceph_deploy.gatherkeys][INFO  ] Storing ceph.bootstrap-rgw.keyring
[ceph_deploy.gatherkeys][INFO  ] Destroy temp directory /tmp/tmpYahdve

Once you complete the process, your local directory should have the following keyrings:

ceph.client.admin.keyring
ceph.bootstrap-mgr.keyring
ceph.bootstrap-osd.keyring
ceph.bootstrap-mds.keyring
ceph.bootstrap-rgw.keyring
ceph.bootstrap-rbd.keyring

Use ceph-deploy to copy the configuration file and admin key to your admin node and your Ceph Nodes so that you can use the ceph CLI without having to specify the monitor address and ceph.client.admin.keyring each time you execute a command.

# ceph-deploy admin storage1 storage2
[ceph_deploy.conf][DEBUG ] found configuration file at: /root/.cephdeploy.conf
[ceph_deploy.cli][INFO  ] Invoked (2.0.1): /usr/bin/ceph-deploy admin storage1 storage2
[ceph_deploy.cli][INFO  ] ceph-deploy options:
[ceph_deploy.cli][INFO  ]  username                      : None
[ceph_deploy.cli][INFO  ]  verbose                       : False
[ceph_deploy.cli][INFO  ]  overwrite_conf                : False
[ceph_deploy.cli][INFO  ]  quiet                         : False
[ceph_deploy.cli][INFO  ]  cd_conf                       :
[ceph_deploy.cli][INFO  ]  cluster                       : ceph
[ceph_deploy.cli][INFO  ]  client                        : ['storage1', 'storage2']
[ceph_deploy.cli][INFO  ]  func                          :
[ceph_deploy.cli][INFO  ]  ceph_conf                     : None
[ceph_deploy.cli][INFO  ]  default_release               : False
[ceph_deploy.admin][DEBUG ] Pushing admin keys and conf to storage1
[storage1][DEBUG ] connection detected need for sudo
[storage1][DEBUG ] connected to host: storage1
[storage1][DEBUG ] detect platform information from remote host
[storage1][DEBUG ] detect machine type
[storage1][DEBUG ] write cluster configuration to /etc/ceph/{cluster}.conf
[ceph_deploy.admin][DEBUG ] Pushing admin keys and conf to storage2
[storage2][DEBUG ] connection detected need for sudo
[storage2][DEBUG ] connected to host: storage2
[storage2][DEBUG ] detect platform information from remote host
[storage2][DEBUG ] detect machine type
[storage2][DEBUG ] write cluster configuration to /etc/ceph/{cluster}.conf



Deploy a manager daemon. (Required only for luminous+ builds):

# ceph-deploy mgr create storage1
[ceph_deploy.conf][DEBUG ] found configuration file at: /root/.cephdeploy.conf
[ceph_deploy.cli][INFO  ] Invoked (2.0.1): /usr/bin/ceph-deploy mgr create storage1
[ceph_deploy.cli][INFO  ] ceph-deploy options:
[ceph_deploy.cli][INFO  ]  username                      : None
[ceph_deploy.cli][INFO  ]  verbose                       : False
[ceph_deploy.cli][INFO  ]  mgr                           : [('storage1', 'storage1')]
[ceph_deploy.cli][INFO  ]  overwrite_conf                : False
[ceph_deploy.cli][INFO  ]  subcommand                    : create
[ceph_deploy.cli][INFO  ]  quiet                         : False
[ceph_deploy.cli][INFO  ]  cd_conf                       :
[ceph_deploy.cli][INFO  ]  cluster                       : ceph
[ceph_deploy.cli][INFO  ]  func                          :
[ceph_deploy.cli][INFO  ]  ceph_conf                     : None
[ceph_deploy.cli][INFO  ]  default_release               : False
[ceph_deploy.mgr][DEBUG ] Deploying mgr, cluster ceph hosts storage1:storage1
[storage1][DEBUG ] connection detected need for sudo
[storage1][DEBUG ] connected to host: storage1
[storage1][DEBUG ] detect platform information from remote host
[storage1][DEBUG ] detect machine type
[ceph_deploy.mgr][INFO  ] Distro info: CentOS Linux 7.4.1708 Core
[ceph_deploy.mgr][DEBUG ] remote host will use systemd
[ceph_deploy.mgr][DEBUG ] deploying mgr bootstrap to storage1
[storage1][DEBUG ] write cluster configuration to /etc/ceph/{cluster}.conf
[storage1][WARNIN] mgr keyring does not exist yet, creating one
[storage1][DEBUG ] create a keyring file
[storage1][DEBUG ] create path recursively if it doesn't exist
[storage1][INFO  ] Running command: sudo ceph --cluster ceph --name client.bootstrap-mgr --keyring /var/lib/ceph/bootstrap-mgr/ceph.keyring auth get-or-creat                                                                                e mgr.storage1 mon allow profile mgr osd allow * mds allow * -o /var/lib/ceph/mgr/ceph-storage1/keyring
[storage1][INFO  ] Running command: sudo systemctl enable ceph-mgr@storage1
[storage1][WARNIN] Created symlink from /etc/systemd/system/ceph-mgr.target.wants/ceph-mgr@storage1.service to /usr/lib/systemd/system/ceph-mgr@.service.
[storage1][INFO  ] Running command: sudo systemctl start ceph-mgr@storage1
[storage1][INFO  ] Running command: sudo systemctl enable ceph.target



Add OSDs:

NOTE:
For the purposes of these instructions, we assume you have an unused disk in each node called /dev/sdc. Be sure that the device is not currently in use and does not contain any important data.
# ceph-deploy osd create --data /dev/sdc storage1
<< Output trimmed >>

[storage1][INFO  ] Running command: sudo /bin/ceph --cluster=ceph osd stat --format=json
[ceph_deploy.osd][DEBUG ] Host storage1 is now ready for osd use.
# ceph-deploy osd create --data /dev/sdc storage2
<< Output trimmed >>

[storage2][INFO  ] Running command: sudo /bin/ceph --cluster=ceph osd stat --format=json
[ceph_deploy.osd][DEBUG ] Host storage2 is now ready for osd use.

So we are all done now here.



Now we brought up a functioning Ceph cluster from scratch and incrementally scaled it without taking it down. Next we’ll explore a number of operations we can perform to customise, populate, and manage Ceph clusters.



To check the cluster health

[root@storage2 ~]# ceph health
HEALTH_OK

Check the OSD and cluster status

[root@storage1 ~]# ceph -s
  cluster:
    id:     454f796c-ed9f-4242-89b4-e0d43f740ffd
    health: HEALTH_OK

  services:
    mon: 2 daemons, quorum storage1,storage2
    mgr: storage1(active)
    osd: 2 osds: 2 up, 2 in

  data:
    pools:   0 pools, 0 pgs
    objects: 0  objects, 0 B
    usage:   2.0 GiB used, 6.0 GiB / 8.0 GiB avail
    pgs:



OSD dump

The ceph osd dump command shows a wealth of lower-level information about our clusters. This includes a list of pools with their attributes and a list of OSDs each including reweight adjustment, up/in status, and more. This command is mostly used in unusual troubleshooting situations.

[root@storage2 ~]# ceph osd dump
epoch 15
fsid 454f796c-ed9f-4242-89b4-e0d43f740ffd
created 2018-11-17 13:19:39.387450
modified 2018-11-17 16:14:46.813272
flags sortbitwise,recovery_deletes,purged_snapdirs
crush_version 6
full_ratio 0.95
backfillfull_ratio 0.9
nearfull_ratio 0.85
require_min_compat_client jewel
min_compat_client jewel
require_osd_release mimic
max_osd 3
osd.0 up   in  weight 1 up_from 11 up_thru 0 down_at 10 last_clean_interval [5,9) 10.0.2.13:6800/1236 10.0.2.13:6801/1236 10.
osd.1 up   in  weight 1 up_from 13 up_thru 0 down_at 12 last_clean_interval [0,0) 10.0.2.14:6800/1079 10.0.2.14:6801/1079 10.



CRUSH dump

This command presents much the same information as ceph osd tree, though in a different, JSON, format.

# ceph osd crush dump



OSD list

The ceph osd ls command simply returns a list of the OSD numbers currently deployed within the cluster.

[root@storage2 ~]# ceph osd ls
0
1



Get the quorum status

[root@storage2 ~]# ceph quorum_status --format json-pretty

{
    "election_epoch": 8,
    "quorum": [
        0,
        1
    ],
    "quorum_names": [
        "storage1",
        "storage2"
    ],
    "quorum_leader_name": "storage1",
    "monmap": {
        "epoch": 1,
        "fsid": "454f796c-ed9f-4242-89b4-e0d43f740ffd",
        "modified": "2018-11-17 13:17:57.395486",
        "created": "2018-11-17 13:17:57.395486",
        "features": {
            "persistent": [
                "kraken",
                "luminous",
                "mimic",
                "osdmap-prune"
            ],
            "optional": []
        },
        "mons": [
            {
                "rank": 0,
                "name": "storage1",
                "addr": "10.0.2.13:6789/0",
                "public_addr": "10.0.2.13:6789/0"
            },
            {
                "rank": 1,
                "name": "storage2",
                "addr": "10.0.2.14:6789/0",
                "public_addr": "10.0.2.14:6789/0"
            }
        ]
    }
}



Reference:

Official Ceph Page



Lastly I hope the steps from the article to build ceph storage cluster in Openstack using CentOS 7 Linux was helpful. So, let me know your suggestions and feedback using the comment section.



Leave a Reply

Your email address will not be published. Required fields are marked *
