Beginners guide on Kubernetes Namespace with examples

You may have heard about Linux namespace which are used to isolate system processes from each other. In a similar concept we have namespace in Kubernetes which can provide a scope for objects names. We will learn more about Kubernetes namespace in this tutorial.



Understanding Kubernetes Namespaces

  • Kubernetes uses namespaces to organize objects in the cluster.
  • You can think of each namespace as a folder that holds a set of objects.
  • Namespace implements strict resource separation
  • Resource limitation through quota can be implemented at a Namespace level also
  • Use namespaces to separate customer environments within one Kubernetes cluster
  • By default, the kubectl command-line tool interacts with the default namespace.
  • If you want to use a different namespace, you can pass kubectl the --namespace flag.
  • For example, kubectl --namespace=mystuff references objects in the mystuff namespace.
  • If you want to interact with all namespaces - for example, to list all Pods in your cluster you can pass the --all-namespaces flag.

Four namespaces are defined when a cluster is created:

  • default: this is where all the Kubernetes resources are created by default
  • kube-node-lease: an administrative namespace where node lease information is stored - may be empty and/or non-existing
  • kube-public: a namespace that is world-readable. Generic information can be stored here but it's often empty
  • kube-system: contains all infrastructure pods



Why do we need namespaces?

Using multiple namespaces allows you to split complex systems with numerous components into smaller distinct groups. This is useful in scenarios wherein you want to split and limit resources across different resources. Resource names only need to be unique within a namespace. Two different namespaces can contain resources of the same name.

Although namespaces allow you to isolate objects into distinct groups, which allows you to operate only on those belonging to the specified namespace, they don’t provide any kind of isolation of running objects. For example, you may think that when different users deploy pods across different namespaces, those pods are isolated from each other and can’t communicate, but that’s not necessarily the case. Whether namespaces provide network isolation depends on which networking solution is deployed with Kubernetes. When the solution doesn’t provide inter-namespace network isolation, if a pod in namespace foo knows the IP address of a pod in namespace bar, there is nothing preventing it from sending traffic, such as HTTP requests, to the other pod.



List available namespaces

To get the list of available namespaces. Up to this point, we have operated only in the default namespace.

[root@controller ~]# kubectl get ns
NAME              STATUS   AGE
default           Active   14d
kube-node-lease   Active   14d
kube-public       Active   14d
kube-system       Active   14d

Alternatively you can also use kubectl get namespace. To get a list of all the available namespaces:

[root@controller ~]# kubectl get all --all-namespaces
NAMESPACE     NAME                                                 READY   STATUS    RESTARTS   AGE
kube-system   pod/coredns-f9fd979d6-nmsq5                          1/1     Running   4          14d
kube-system   pod/coredns-f9fd979d6-xtsrj                          1/1     Running   4          14d
kube-system   pod/etcd-controller.example.com                      1/1     Running   4          14d
kube-system   pod/kube-apiserver-controller.example.com            1/1     Running   4          14d
kube-system   pod/kube-controller-manager-controller.example.com   1/1     Running   4          14d
kube-system   pod/kube-proxy-6fxwf                                 1/1     Running   3          14d
kube-system   pod/kube-proxy-7v9zg                                 1/1     Running   4          14d
kube-system   pod/kube-proxy-snk6p                                 1/1     Running   3          14d
kube-system   pod/kube-scheduler-controller.example.com            1/1     Running   4          14d
kube-system   pod/weave-net-jczxg                                  2/2     Running   12         14d
kube-system   pod/weave-net-md24g                                  2/2     Running   236        14d
kube-system   pod/weave-net-rxpl5                                  2/2     Running   239        14d

NAMESPACE     NAME                 TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)                  AGE
default       service/kubernetes   ClusterIP   10.96.0.1            443/TCP                  14d
kube-system   service/kube-dns     ClusterIP   10.96.0.10           53/UDP,53/TCP,9153/TCP   14d

NAMESPACE     NAME                        DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE   NODE SELECTOR            AGE
kube-system   daemonset.apps/kube-proxy   3         3         3       3            3           kubernetes.io/os=linux   14d
kube-system   daemonset.apps/weave-net    3         3         3       3            3                              14d

NAMESPACE     NAME                      READY   UP-TO-DATE   AVAILABLE   AGE
kube-system   deployment.apps/coredns   2/2     2            2           14d

NAMESPACE     NAME                                DESIRED   CURRENT   READY   AGE
kube-system   replicaset.apps/coredns-f9fd979d6   2         2         2       14d

To list the pods from a specific namespace, for example to list all the pods under default namespace we will use following command:

[root@controller ~]# kubectl get pods -n default
NAME                            READY   STATUS    RESTARTS   AGE
nginx-deploy-58f9bf94f7-4cwlr   1/1     Running   0          43h
nginx-deploy-58f9bf94f7-98jr8   1/1     Running   0          43h
pod-as-user-guest               1/1     Running   2          12d
pod-privileged                  1/1     Running   2          12d
pod-with-host-network           1/1     Running   2          12d

Here you can also use --namespace instead of -n.



Creating a namespace

A namespace is a Kubernetes resource like any other, so you can create it by posting a YAML file to the Kubernetes API server or directly via kubectl command.



Using YAML file

To create a Kubernetes namespace using YAML file we would need the KIND and apiVersion. To get the KIND value of a namespace we will list down the api-resources:

[root@controller ~]# kubectl api-resources | grep -iE 'namespace|KIND'
NAME                              SHORTNAMES   APIGROUP                       NAMESPACED   KIND
namespaces                        ns                                          false        Namespace

Now that we have the KIND value, we can use this to get the respective apiVersion:

[root@controller ~]# kubectl explain Namespace | head -n 2
KIND:     Namespace
VERSION:  v1

Now since we have the KIND and apiVersion value, let's create a custom-namespace.yaml file with the following listing’s contents:

[root@controller ~]# cat app-ns.yml
apiVersion: v1
kind: Namespace
metadata:
   name: app

Now, use kubectl to post the file to the Kubernetes API server:

[root@controller ~]# kubectl create -f create-namespace.yml
namespace/app created

List the available namespaces:

[root@controller ~]# kubectl get ns
NAME               STATUS   AGE
app                Active   34s
default            Active   37d
kube-node-lease    Active   37d
kube-public        Active   37d
kube-system        Active   37d



Using kubectl command

Although writing a file like the previous one isn’t a big deal, it’s still a hassle. Luckily, you can also create namespaces with the dedicated kubectl create namespace command, which is quicker than writing a YAML file. To create a namespace using kubectl command:

[root@controller ~]# kubectl create ns dev
namespace/dev created

List the available namespace:

[root@controller ~]# kubectl get ns
NAME               STATUS   AGE
app                Active   2m12s
default            Active   37d
dev                Active   2s
kube-node-lease    Active   37d
kube-public        Active   37d
kube-system        Active   37d
pods-quota-ns      Active   36d



Get details of namespace

To get a much detailed output of individual namespace we use kubectl describe command. As you can see currently there are no quota or LimitRange assigned to this namespace which we will cover in How to assign Kubernetes resource quota with examples

[root@controller ~]# kubectl describe ns default
Name:         default
Labels:
Annotations:
Status:       Active

No resource quota.

No LimitRange resource.

To get the details of namespace in YAML format:

[root@controller ~]# kubectl get ns default -o yaml
apiVersion: v1
kind: Namespace
metadata:
  creationTimestamp: "2020-11-11T05:46:42Z"
  managedFields:
  - apiVersion: v1
    fieldsType: FieldsV1
    fieldsV1:
      f:status:
        f:phase: {}
    manager: kube-apiserver
    operation: Update
    time: "2020-11-11T05:46:42Z"
  name: default
  resourceVersion: "155"
  selfLink: /api/v1/namespaces/default
  uid: e45242f9-2f0e-4bcb-a385-6058044f20ce
spec:
  finalizers:
  - kubernetes
status:
  phase: Active



Create resource objects in other namespaces

BY default any resource object you create such as Pods, deployments or any other objects, all of them are created in default namespace unless you explicitly define the namespace in YAML file or as an input argument to kubectl.



Method-1: Using YAML file

In this example I will create a new Pod with nginx container and explicitly define the namespace as "app" in the YAML file itself under metadata:

[root@controller ~]# cat nginx-app.yml
apiVersion: v1
kind: Pod
metadata:
  name: nginx-app
  namespace: app
spec:
  containers:
  - name: nginx
    image: nginx
    ports:
    - containerPort: 80

We will create this Pod:

[root@controller ~]# kubectl create -f nginx-app.yml
pod/nginx-app created

As expected now if we look out for this Pod in default namespace, we get NotFound

[root@controller ~]# kubectl get pods -n default nginx-app
Error from server (NotFound): pods "nginx-app" not found

Because we have created this Pod in app namespace:

[root@controller ~]# kubectl get pods -n app nginx-app
NAME        READY   STATUS    RESTARTS   AGE
nginx-app   1/1     Running   0          30s



Method-2: Using kubectl command

We can also pass an input argument to the kubectl command as -n <namespace-name> to assign a namespace. Here I have a different YAML file:

apiVersion: v1
kind: Pod
metadata:
  name: nginx-dev
spec:
  containers:
  - name: nginx
    image: nginx
    ports:
    - containerPort: 80

We will create this Pod inside "dev" namespace:

[root@controller ~]# kubectl create -f nginx-dev.yml -n dev
pod/nginx-dev created

List the newly created Pod under dev namespace:

[root@controller ~]# kubectl get pods -n dev
NAME        READY   STATUS    RESTARTS   AGE
nginx-dev   1/1     Running   0          34s



Terminating namespaces

We have created a number of pods and namespaces in this tutorial which we don't need anymore so let's delete them.



Deleting a Pod using name

We have already covered this in Beginners guide on Kubernetes Pods with examples. By deleting a pod, you’re instructing Kubernetes to terminate all the containers that are part of that pod. Kubernetes sends a SIGTERM signal to the process and waits a certain number of seconds (30 by default) for it to shut down gracefully. If it doesn’t shut down in time, the process is then killed through SIGKILL.

[root@controller ~]# kubectl delete pod nginx-dev
pod "nginx-dev" deleted



Deleting pods by deleting the whole namespace

By default when we delete a namespace then all the pods under the provided namespace would also be terminated:

[root@controller ~]# kubectl delete ns dev
namespace "dev" deleted



Deleting all pods in a namespace, while keeping the namespace

Here I have a Pod running inside app namespace:

[root@controller ~]# kubectl get pods -n app
NAME        READY   STATUS    RESTARTS   AGE
nginx-app   1/1     Running   0          23m

Now to delete all the pods inside app namespace:

[root@controller ~]# kubectl delete pods -n app --all
pod "nginx-app" deleted

Since we had a single pod so only that one is deleted.



Delete all resources in a namespace

You can delete the ReplicationController and the pods, as well as all the Services you’ve created, by deleting all resources in the current namespace with a single command. To demonstrate this command I have created some of the resource objects in app namespace:

[root@controller ~]# kubectl delete all --all -n app
pod "myapp-replicaset-5hwhc" deleted
pod "myapp-replicaset-hmqj9" deleted
pod "myapp-replicaset-q6m5r" deleted
pod "nginx-deploy-58f9bf94f7-fztpl" deleted
pod "nginx-deploy-58f9bf94f7-qnjhq" deleted
service "nginx-deploy" deleted
deployment.apps "nginx-deploy" deleted
replicaset.apps "myapp-replicaset" deleted
replicaset.apps "nginx-deploy-58f9bf94f7" deleted

The first all in the command specifies that you’re deleting resources of all types, and the --all option specifies that you’re deleting all resource instances instead of specifying them by name.

NOTE:

Deleting everything with the all keyword doesn’t delete absolutely everything. Certain resources (like Secrets) are preserved and need to be deleted explicitly.



Conclusion

In this Kubernetes tutorial we learned all about namespace and how it can be used to allow different teams to use the same cluster as though they were using separate Kubernetes clusters. You may assign different set of quotas and LimitRange to individual namespace.
