How to read user input during boot stage with systemd in Linux

In this article I will share a sample systemd unit file which can be used to read user input during boot stage using shell script with systemd in RHEL/CentOS 7/8 Linux. It is possible that for a system administrator there are some tasks such as setting hostname or something which requires him/her to read user input during boot stage before login prompt comes up. And then based on the user input certain task is performed using a background script.

This is possible using systemd unit service file in RHEL/CentOS 7/8 Linux.

Advertisement



Some more articles on similar topic:



Step 1: Overview on systemd

I hope you are already familiar with below topics



Step 2: Create Sample script

We will use a custom small script with until loop to read user input during boot stage. So unless the script gets the user input, it will not allow the boot stage to complete.

[root@centos-8 ~]# cat /tmp/welcome.sh
#!/bin/bash
until [[ -n ${REPLY} ]]; do
    read -ep "Enter your name: "
done
echo "WELCOME ${REPLY^^}"; sleep 5

Here the script will prompt "Enter your name" and then will wait for user input. If we call this script at boot up stage then the script will read user input during boot stage and proceed accordingly.



Step 3: Create systemd unit service file to read user input during boot stage

Now we need a systemd unit service file which will call our script at boot stage to read user input. The file should be located in either /usr/lib/systemd/system/ or /etc/systemd/system/. Below is a sample systemd unit service file:

[root@centos-8 ~]# cat /etc/systemd/system/take-user-input.service
[Unit]
Description=Get user input at boot stage
After=network.target
Before=sshd.service systemd-logind.service getty@tty1.service

[Service]
Type=oneshot
TTYPath=/dev/tty13
ExecStartPre=/usr/bin/chvt 13
ExecStart=/tmp/welcome.sh
ExecStartPost=/usr/bin/chvt 1
TimeoutStartSec=0
StandardInput=tty
TTYVHangup=yes
TTYVTDisallocate=yes

[Install]
WantedBy=default.target
RequiredBy=sshd.service systemd-logind.service getty@tty1.service

Here,

After=   	If the script needs any other system facilities (networking, etc), modify the [Unit] section to include appropriate
		After=, Wants=, or Requires= directives, as described in: man systemd.unit

Before=   	If the script needs to be run before other services--for example, prior to starting sshd or console/graphical
		logins--ensure there is a Before=XYZ.service in the [Unit] section and a corresponding RequiredBy=XYZ.service
		in the [Install] section.

TTYPath=   	Specify a tty number here (the writer's choice of tty13 here was mostly arbitrary; however, keep in mind that
		numbers higher than 12 require the chvt command to access them).

ExecStartPre=/usr/bin/chvt 13   This changes the physical console to tty13 (i.e., the tty specified with TTYPath=).

ExecStart=   The full path to the main script, including any desired script arguments.

ExecStartPost=/usr/bin/chvt 1   This changes the physical console back to tty1 after the script finishes (this line
				is not always necessary, e.g., if a display manager starts after the script, it will
				probably steal focus by changing the physical console back to whichever tty it is running on).

TimeoutStartSec=    When a service doesn't signal start-up completion within TimeoutStartSec, systemd considers the service failed;
		    for long-running shell scripts it is essential to modify TimeoutStartSec or disable the timeout logic altogether
		    as above, with TimeoutStartSec=0. See man systemd.service for more details

StandardInput=tty   This line is absolutely necessary; without specifying the value tty here, this setting defaults to null.
					(Note that StandardOutput= and StandardError= can also be independently set;
					however, by default they inherit their value from StandardInput=.)

For more information check man page of systemd.exec

Refresh the systemd configuration files

[root@centos-8 ~]# systemctl daemon-reload

Enable the service to automatically start at next boot

[root@centos-8 ~]# systemctl enable take-user-input.service
Created symlink /etc/systemd/system/default.target.wants/take-user-input.service → /etc/systemd/system/take-user-input.service.
Created symlink /etc/systemd/system/sshd.service.requires/take-user-input.service → /etc/systemd/system/take-user-input.service.
Created symlink /etc/systemd/system/systemd-logind.service.requires/take-user-input.service → /etc/systemd/system/take-user-input.service.
Created symlink /etc/systemd/system/getty@tty1.service.requires/take-user-input.service → /etc/systemd/system/take-user-input.service.

Now you are all done, proceed with the reboot of the Linux node.



Step 4: Verify the systemd unit file configuration

Post reboot connect to the GUI console of you Linux host, since I am using Oracle VirtualBox, I will connect to the console of my Virtual Machine.

Here as you see the booting has halted and is awaiting for user input from our script /tmp/welcome.sh

How to read user input during boot stage in CentOS/RHEL 7/8 Linux

Once you give the input the booting of your Linux OS will continue.

As this stage we had explicitly used Before=sshd.service and After=network.target to execute script before activating sshd hence sshd will not be active at this stage although network should be active.



Advertisement

References:
How to allow a custom service script in RHEL7 to run in the foreground and accept user input



Lastly I hope the steps from the article to read user input during boot stage using systemd on CentOS/RHEL 7 Linux was helpful. So, let me know your suggestions and feedback using the comment section.



Related Searches: read user input in shell script at boot stage in Linux. bash read input from stdin during boot up. take input at the startup script in Linux.

Didn't find what you were looking for? Perform a quick search across GoLinuxCloud

If my articles on GoLinuxCloud has helped you, kindly consider buying me a coffee as a token of appreciation.

Buy GoLinuxCloud a Coffee

For any other feedbacks or questions you can either use the comments section or contact me form.

Thank You for your support!!

6 thoughts on “How to read user input during boot stage with systemd in Linux”

  1. Hi, thanks for your help. The steps works well for Ubuntu but with Debian doesn’t work. I got this error:

    ● firstboot.service - Get user input at boot stage
       Loaded: loaded (/etc/systemd/system/firstboot.service; enabled; vendor preset
       Active: failed (Result: exit-code) since Sun 2021-08-08 20:40:47 UTC; 17s ago
      Process: 766 ExecStartPre=/usr/bin/chvt 13 (code=exited, status=203/EXEC)

    Aug 08 20:40:47 debiandev systemd[1]: Starting Get user input at boot stage...
    Aug 08 20:40:47 debiandev systemd[766]: firstboot.service: Failed to execute com
    Aug 08 20:40:47 debiandev systemd[766]: firstboot.service: Failed at step EXEC s
    Aug 08 20:40:47 debiandev systemd[1]: firstboot.service: Control process exited,
    Aug 08 20:40:47 debiandev systemd[1]: firstboot.service: Failed with result 'exi
    Aug 08 20:40:47 debiandev systemd[1]: Failed to start Get user input at boot sta
    Reply
    • I am afraid I don’t have a Debian setup but the logs should help. You can use journalctl -u firstboot and go to the last line to check the recent logs

      Reply
      • root@debiandev:~# journalctl -u firstboot
        -- Logs begin at Mon 2021-08-09 14:02:08 UTC, end at Mon 2021-08-09 14:03:02 UTC
        Aug 09 14:02:12 debiandev systemd[1]: Starting Get user input at boot stage...
        Aug 09 14:02:12 debiandev systemd[727]: firstboot.service: Failed to execute com
        Aug 09 14:02:12 debiandev systemd[727]: firstboot.service: Failed at step EXEC s
        Aug 09 14:02:12 debiandev systemd[1]: firstboot.service: Control process exited,
        Aug 09 14:02:12 debiandev systemd[1]: firstboot.service: Failed with result 'exi
        Aug 09 14:02:12 debiandev systemd[1]: Failed to start Get user input at boot sta
        Aug 09 14:02:13 debiandev systemd[1]: Starting Get user input at boot stage...
        Aug 09 14:02:13 debiandev systemd[738]: firstboot.service: Failed to execute com
        Aug 09 14:02:13 debiandev systemd[738]: firstboot.service: Failed at step EXEC s
        Aug 09 14:02:13 debiandev systemd[1]: firstboot.service: Control process exited,
        Aug 09 14:02:13 debiandev systemd[1]: firstboot.service: Failed with result 'exi
        Aug 09 14:02:13 debiandev systemd[1]: Failed to start Get user input at boot sta
        Aug 09 14:02:36 debiandev systemd[1]: Starting Get user input at boot stage...
        Aug 09 14:02:36 debiandev systemd[741]: firstboot.service: Failed to execute com
        Aug 09 14:02:36 debiandev systemd[741]: firstboot.service: Failed at step EXEC s
        Aug 09 14:02:36 debiandev systemd[1]: firstboot.service: Control process exited,
        Aug 09 14:02:36 debiandev systemd[1]: firstboot.service: Failed with result 'exi
        Aug 09 14:02:36 debiandev systemd[1]: Failed to start Get user input at boot sta
        Aug 09 14:03:02 debiandev systemd[1]: Starting Get user input at boot stage...
        Aug 09 14:03:02 debiandev systemd[752]: firstboot.service: Failed to execute com
        Aug 09 14:03:02 debiandev systemd[752]: firstboot.service: Failed at step EXEC s
        Aug 09 14:03:02 debiandev systemd[1]: firstboot.service: Control process exited,
        Aug 09 14:03:02 debiandev systemd[1]: firstboot.service: Failed with result 'exi
        Aug 09 14:03:02 debiandev systemd[1]: Failed to start Get user input at boot sta
        Reply
