Things to consider when creating CSR with OpenSSL


Written by - Deepak Prasad

I have now covered multiple tutorials on working with openssl certificates. But there is one question where I get a lot of questions where certificate doesn't work due to incorrect entries in Certificate Signing Request.

So I have decided to create a dedicated tutorial to explain why CSR is important, and things to consider when writing a CSR.



Problems which you can face with incorrect CSR

  • Writing a CSR is the most crucial part of generating a certificate. If your CSR is not proper then:
  • RootCA may fail to sign the certificate
  • Your MTLS authentication will not work with TCP handshake error
  • You will end up creating multiple certificates for each host if you are not familiar with SAN
  • Your X.509 extensions will not be properly added
  • and many more ..



Important points to consider when creating CSR

  • The openssl command will by default consider /etc/pki/tls/openssl.cnf as the configuration file unless you specify your own configuration file using -config.
  • The req_distinguished_name field is used to get the details which will be asked while generating the CSR. You can alter this section inside the openssl.cnf and add the default values, modify the conditions such as min and max allowed characters etc
  • There are different policy sections available in the openssl.cnf. The policy_anything is normally used for self-signed certificates where all the fields except commonName are optional.
  • The policy_match section is used to generate RootCA certificates. If you are planning to use this RootCA certificate to sign any server or client certificate, then the respective sections marked as match must be same between RootCA and server or client certificate. In case you provide your stateOrProvinceName as Karnataka in RootCA and KARNATAKA in server certificate then the signing will fail as both will be considered as different values.
  • commonName is used for MTLS communications. The commonName must match the HOSTNAME or FQDN of the server on the server certificate and client on the client certificate. So if we have apache-client.example.com sending request to apache-server.example.com with MTLS authentication then the server certificate should have commonName as apache-server.example.com and client certificate should have apache-client.example.com
  • To consider High Availability and Load balancing, in IT organizations we use single FQDN mapped to multiple IP Addresses so in such case we prefer to use SAN certificates. So an -extfile param can be used with openssl command to provide the list of IP Address which would be validated for respective certificate. In such case you can provide the server's domain name as commonName while generating the CSR.
NOTE:
Since this article is all about Certificate Signing Request, I will not explain other areas of certificate generation. This article assumes that you have necessary environment such as openssl command, private keys etc to generate the CSR



Modify default values for CSR (using custom configuration)

Now let us define our own configuration file which will have all the set of default values to be used to generate the CSR. Here is my sample configuration file:

[root@controller certs]# cat custom_openssl.cnf

Sample Output:

distinguished_name = req_distinguished_name

[ req_distinguished_name ]
countryName                     = Country Name (2 letter code)
countryName_default             = IN
countryName_min                 = 2
countryName_max                 = 2
stateOrProvinceName             = State or Province Name (full name) ## Print this message
stateOrProvinceName_default     = KARNATAKA ## This is the default value
localityName                    = Locality Name (eg, city) ## Print this message
localityName_default            = BANGALORE ## This is the default value
0.organizationName              = Organization Name (eg, company) ## Print this message
0.organizationName_default      = GoLinuxCloud ## This is the default value
organizationalUnitName          = Organizational Unit Name (eg, section) ## Print this message
organizationalUnitName_default  = Admin ## This is the default value
commonName                      = Common Name (eg, your name or your server hostname) ## Print this message
commonName_max                  = 64
emailAddress                    = Email Address ## Print this message
emailAddress_max                = 64

Next let us try to generate CSR using this custom configuration file:

[root@controller certs]# openssl req -new -key server.key -out server.csr -config custom_openssl.cnf
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [IN]:
State or Province Name (full name) [KARNATAKA]:
Locality Name (eg, city) [BANGALORE]:
Organization Name (eg, company) [GoLinuxCloud]:
Organizational Unit Name (eg, section) [Admin]:
Common Name (eg, your name or your server's hostname) []:server.example.com ## provide hostname of your localhost
Email Address []: ## can be skipped or provide any email address

As expected, all the default values have been updated based on our custom configuration. So I can just press ENTER and default values will be considered for the CSR.

Although we need to provide Common Name which should have the server's hostname or FQDN



Self-Signed Certificate CSR Example

Let us start with the self-signed certificates first. This is the fastest way to achieve a TLS communication with minimal security as it is better than plain text based communication.

Here is a sample output to generate the CSR for self-signed certificate. Since we have not defined any configuration file, by default openssl will consider /etc/pki/tls/openssl.cnf:

[root@controller certs]# openssl req -new -key server.key -out server.csr

-----
Country Name (2 letter code) [XX]:IN    ## By default maximum 2 char allowed
State or Province Name (full name) []:ANYTHING  ## can be anything
Locality Name (eg, city) [Default City]:ANYTHING  ## can be anything
Organization Name (eg, company) [Default Company Ltd]:ANYTHING  ## can be anything
Organizational Unit Name (eg, section) []:ANYTHING  ## can be anything
Common Name (eg, your name or your server hostname) []:server.example.com  ## provide the hostname/fqdn of the localhost server node
Email Address []:ANYTHING ## can be anything

Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []: ## can be anything or leave empty
An optional company name []: ## can be anything or leave empty



RootCA Certificate CSR Example

We also need to write a CSR when creating our own RootCA certificate. If you are not providing your own openssl.cnf then by default /etc/pki/tls/openssl.cnf will be considered.

Now by default RootCA certificate follows below below guidelines from /etc/pki/tls/openssl.cnf:

policy          = policy_match

# For the CA policy
[ policy_match ]
countryName             = match
stateOrProvinceName     = match
organizationName        = match
organizationalUnitName  = optional
commonName              = supplied
emailAddress            = optional

This would mean that both RootCA and server/client certificate must have same countryName, stateOrProvinceName and organizationName or else the signing will fail.

Let us take a look at this with a practical example:

Let me generate my RootCA certificate:

[root@controller certs]# openssl genrsa -out ca.key 4096

[root@controller certs]# openssl req -new -x509 -days 365 -key ca.key -out cacert.pem

-----
Country Name (2 letter code) [XX]:IN
State or Province Name (full name) []:KARNATAKA
Locality Name (eg, city) [Defaultt City]:BENGALORE
Organization Name (eg, company) [Default Company Ltd]:GoLinuxCloud
Organizational Unit Name (eg, section) []:Admin
Common Name (eg, your name or your server's hostname) []:RootCA
Email Address []:

[root@controller certs]# ls -l cacert.pem
-rw-r--r-- 1 root root 2049 Aug 28 00:16 cacert.pem

Now we will generate one server certificate:

[root@controller certs]# openssl genrsa  -out server.key 4096

[root@controller certs]# openssl req -new -key server.key -out server.csr

-----
Country Name (2 letter code) [XX]:IN
State or Province Name (full name) []:Karnataka
Locality Name (eg, city) [Defaultt City]:Bengaluru
Organization Name (eg, company) [Default Company Ltd]:Golinuxcloud
Organizational Unit Name (eg, section) []:Dev
Common Name (eg, your name or your server's hostname) []:server.example.com
Email Address []:

Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:
An optional company name []:

As you may have noticed, I have provided the different values for countryName, stateOrProvinceName and organizationName for both rootCA and server certificate CSR.

Let us try to now create server certificate by signing this using CSR and rootCA certificate:

[root@controller certs]# openssl ca  -days 2650 -notext -batch -create_serial -cert cacert.pem -keyfile ca.key -in server.csr -out cacert.pem
Using configuration from /etc/pki/tls/openssl.cnf
Check that the request matches the signature
Signature ok
The stateOrProvinceName field is different between
CA certificate (KARNATAKA) and the request (Karnataka)

As expected, the first check itself has failed since the stateOrProvinceName has different CASE even though the content is same hence they are considered different.

But you can still use openssl x509 command to generate server certificate, the difference is that you will not be able to keep a track of different certificates signed by your RootCA:

[root@controller certs]# openssl x509 -req -days 3650 -in server.csr -CA cacert.pem -CAkey ca.key -CAcreateserial -out server.crt
Signature ok
subject=C = IN, ST = Karnataka, L = Bengaluru, O = Golinuxcloud, OU = Dev, CN = server.example.com
Getting CA Private Key

Verify the certificate content:

[root@controller certs]# openssl x509 -noout -text -in server.crt | grep -E 'Subject:|Issuer:'
        Issuer: C = IN, ST = KARNATAKA, L = BENGALORE, O = GoLinuxCloud, OU = Admin, CN = RootCA
        Subject: C = IN, ST = Karnataka, L = Bengaluru, O = Golinuxcloud, OU = Dev, CN = server.example.com

As you can see, the CSR content for both Issuer and Certificate is different and yet you were able to generate the certificate.



Generate CSR for SAN certificate

We can create a custom configuration file with the list of SAN details which needs to be added to the CSR:

[root@controller certs]# cat custom_openssl.cnf
[req]
req_extensions = req_ext
distinguished_name = req_distinguished_name

[req_distinguished_name]
countryName                     = Country Name (2 letter code)
stateOrProvinceName             = State or Province Name (full name)
localityName                    = Locality Name (eg, city)
0.organizationName              = Organization Name (eg, company)
organizationalUnitName          = Organizational Unit Name (eg, section)
commonName                      = Common Name (eg, your name or your server\'s hostname)
emailAddress                    = Email Address

[req_ext]
subjectAltName = @alt_names

[alt_names]
IP.1 = 10.10.10.13
IP.2 = 10.10.10.14
IP.3 = 10.10.10.17
DNS.1 = centos8-2.example.com
DNS.2 = centos8-3.example.com

Under alt_names section you can provide the list of your IP or hostname or FQDN which will be used for the authentication. Now if your certificate will act as a server certificate then you should all the IP details from your server node and if your certificate will act as a client then you should client details.

The TCP handshake will check the SAN field from both server and client certificate when trying to perform an MTLS connection.

Let us generate our CSR using this configuration file:

[root@controller certs]# openssl req -new -newkey rsa:4096 -nodes  -out server.csr -config custom_openssl.cnf
Generating a RSA private key
.......++++
.........................
......................................................++++
writing new private key to stdout
-----BEGIN PRIVATE KEY-----
MIIJRAIBADANBgkqhkiG9w0BAQEFAASCCS4wggkqAgEAAoICAQC9oU7pOjTF60sd
60EwhsLCaYyUg7dExVDfBt1GwbSRYvk/LphTXck7K8rlmeJv7ECOk/2ju9Ad5wXl

...

Country Name (2 letter code) []:IN
State or Province Name (full name) []:Karnataka
Locality Name (eg, city) []:Bengaluru
Organization Name (eg, company) []:GoLinuxCloud
Organizational Unit Name (eg, section) []:Admin
Common Name (eg, your name or your server's hostname) []:example.com
Email Address []:

Next verify the Subject Alternative Field in your CSR:

[root@controller certs]# openssl req -noout -text -in server.csr | grep -A 1 "Subject Alternative Name"
            X509v3 Subject Alternative Name:
                IP Address:10.10.10.13, IP Address:10.10.10.14, IP Address:10.10.10.17, DNS:centos8-2.example.com, DNS:centos8-3.example.com

Let me also cover some further modifications which can be done to a certificate



Add custom X.509 extensions to Certificate

There are multiple x509 extensions which you can assign to your certificate.

This can be done by updating your openssl.cnf file or you can create a custom configuration file and use that to generate certificate. You may have noticed multiple extension fields in your openssl.cnf such as

  • v3_ca
  • v3_req
  • crl_ext
  • proxy_cert_ext
  • ..

where each field contains separate set of x509 extensions. You can define the default extension under [req] section as shown below:

[ req ]
default_bits            = 2048
default_md              = sha256
default_keyfile         = privkey.pem
distinguished_name      = req_distinguished_name
attributes              = req_attributes
x509_extensions         = v3_ca

Alternatively you can use -extensions <extension_name> to use a specific extension while signing your certificate.

For example, here I have created an external configuration file with the list of x509 extensions I want to add to my certificate:

[root@controller certs]# cat custom_openssl.cnf
authorityKeyIdentifier=keyid,issuer
basicConstraints=CA:FALSE
keyUsage = digitalSignature, nonRepudiation, keyEncipherment, dataEncipherment
extendedKeyUsage = serverAuth, clientAuth

Now let me generate my certificate using this configuration file:

[root@controller certs]# openssl x509 -req -days 3650 -in server.csr -CA cacert.pem -CAkey ca.key -CAcreateserial -out server.crt -extfile custom_openssl.cnf
Signature ok
subject=C = IN, ST = KARNATAKA, L = BANGALORE, O = GoLinuxCloud, OU = Admin, CN = example
Getting CA Private Key

Verify the X.509 extensions inside the certificate:

[root@controller certs]# openssl x509 -noout -text -in server.crt | grep -A 10 "X509v3 extensions"
        X509v3 extensions:
            X509v3 Authority Key Identifier:
                keyid:AC:42:BE:30:0E:43:34:22:EC:1E:AA:5A:D1:9E:C6:C4:BA:72:0F:E0

            X509v3 Basic Constraints:
                CA:FALSE
            X509v3 Key Usage:
                Digital Signature, Non Repudiation, Key Encipherment, Data Encipherment
            X509v3 Extended Key Usage:
                TLS Web Server Authentication, TLS Web Client Authentication
    Signature Algorithm: sha256WithRSAEncryption



Summary

We have covered different areas related to generating CSR required to sign a certificate. Now you can use a CSR to sign either a RootCA certificate, server or client certificate. I have also explained the important points which one should consider when trying to create a CSR or else they may face TCP handshake failures or certificate signing related failures.

The Common Name is considered as the most important field of any Certificate and must be filled cautiously, especially when generating server or client certificate.

Let me know if you have any questions or feedbacks using the comments section.



Views: 30

Deepak Prasad

He is the founder of GoLinuxCloud and brings over a decade of expertise in Linux, Python, Go, Laravel, DevOps, Kubernetes, Git, Shell scripting, OpenShift, AWS, Networking, and Security. With extensive experience, he excels in various domains, from development to DevOps, Networking, and Security, ensuring robust and efficient solutions for diverse projects. You can reach out to him on his LinkedIn profile or join on Facebook page.

Can't find what you're searching for? Let us assist you.

Enter your query below, and we'll provide instant results tailored to your needs.

If my articles on GoLinuxCloud has helped you, kindly consider buying me a coffee as a token of appreciation.

Buy GoLinuxCloud a Coffee

For any other feedbacks or questions you can send mail to admin@golinuxcloud.com

Thank You for your support!!

2 thoughts on “Things to consider when creating CSR with OpenSSL”

  1. Problem with SAN’s is that they expose list of all domains which is not what many admins wants. I don’t want people of some services to know about my all other services via SAN’s. That’s why i inject separate certs in my proxy for different set of services.

    Reply

Leave a Comment
