Enroll TPM2, FIDO2, and Recovery Keys on LUKS2 with systemd-cryptenroll

systemd-cryptenroll adds hardware and recovery unlock paths to an existing LUKS2 volume:

• Writes credentials to LUKS2 key slots
• Records how to use them in the header token area (JSON metadata)
• Lets systemd-cryptsetup in the initramfs consume those tokens at boot

Unlock options covered:

• TPM2 seal
• FIDO2 security key (hmac-secret)
• PKCS#11 smartcard
• Printed recovery key

Examples use /dev/sdc1 from encrypt a partition with LUKS. Recovery-key enrollment output comes from a disposable loop lab on this host; TPM2 and FIDO2 commands match physical hardware when devices are present.

Related guides:

• Auto mount LUKS at boot using crypttab
• LUKS header backup before adding or wiping slots
• Clevis and Tang NBDE — network-assisted unlock for fleets

Tested on: Ubuntu 26.04 LTS (Resolute Raccoon); kernel 7.0.0-27-generic; systemd 259.5; cryptsetup 2.8.4.

Quick reference

Replace /dev/sdc1 with your LUKS2 partition.

• You need an existing passphrase or --unlock-key-file to authorize enrollment

Some flags vary by systemd version. This guide was tested against Ubuntu 26.04 (systemd 259). On older Ubuntu or Debian releases, check systemd-cryptenroll --help before using newer options:

What you need

• LUKS2 volume (not LUKS1) — confirm with cryptsetup luksDump
• Root or sudo
• An existing unlock secret (passphrase or key file) for every enrollment except --wipe-slot
• For TPM2: TPM 2.0 chip or firmware vTPM (/dev/tpmrm0 or /dev/tpm0)
• For FIDO2: security key with hmac-secret support
• For boot unlock: matching /etc/crypttab option and regenerated initramfs (update-initramfs -u -k all on Ubuntu/Debian when multiple kernels are installed)
• LUKS header backup before wiping slots

On Fedora and other distributions, install systemd and cryptsetup locally—the enrollment commands are the same when versions are new enough.

LUKS2 tokens and the JSON metadata area

LUKS2 stores two related concepts in the header:

cryptsetup luksDump prints a human summary under Tokens:. Export the full JSON for one token:

sudo cryptsetup token export --token-id 0 /dev/sdc1

After recovery-key enrollment on a lab loop volume, token 0 looked like:

{"type":"systemd-recovery","keyslots":["1"]}

Confirm the volume is LUKS2 before enrolling:

sudo cryptsetup luksDump /dev/sdc1 | head -5

Sample output:

LUKS header information
Version:       	2
Epoch:         	3
Metadata area: 	16384 [bytes]
Keyslots area: 	16744448 [bytes]

LUKS1 volumes have no Tokens: section — systemd-cryptenroll refuses them.

Hardware and environment requirements

On this lab VM, list TPM2 candidates:

systemd-cryptenroll --tpm2-device=list

Sample output:

No suitable TPM2 devices found.

List FIDO2 devices:

systemd-cryptenroll --fido2-device=list

Sample output:

No FIDO2 devices found.

List PKCS#11 tokens:

systemd-cryptenroll --pkcs11-token-uri=list

Sample output:

No suitable PKCS#11 tokens found.

Check for TPM device nodes:

ls /dev/tpm* 2>/dev/null || echo "No /dev/tpm* nodes"

Sample output:

No /dev/tpm* nodes

Install and list devices

systemd-cryptenroll ships with systemd on Ubuntu 26.04 (package systemd).

List block devices that look like LUKS2 candidates:

systemd-cryptenroll --list-devices

Sample output (trimmed):

/dev/sdc1
/dev/disk/by-uuid/e2e306a9-d94e-45d9-b209-4c9975fcede5
...

/dev/sdc1 is the lab secondary disk. The list also includes symlinks under /dev/disk/by-*.

If you omit the device argument and are not wiping slots, the tool may default to the block device backing /var (often the root filesystem) — always pass the LUKS partition explicitly.

Enroll a recovery key

Recovery keys are long, random, hyphen-separated words:

• Occupy a normal LUKS key slot
• Register a systemd-recovery token so administrators know which slot is the recovery path

You must prove an existing key:

• Interactive (preferred): run without --unlock-key-file and type the passphrase when prompted
• Automation: --unlock-key-file only when the unlock secret is already stored as a key file
• Do not type real passphrases into shell commands — history, scrollback, and /tmp handling can leak them

Enroll interactively on your LUKS partition:

sudo systemd-cryptenroll --recovery-key /dev/sdc1

Or authorize with an existing key file:

chmod 600 /path/to/existing-unlock.key
sudo systemd-cryptenroll --recovery-key --unlock-key-file=/path/to/existing-unlock.key /dev/sdc1

On a disposable loop LUKS2 volume (same command shape as /dev/sdc1), enrollment printed:

A secret recovery key has been generated for this volume:

    cnfnjjdb-dgtrvjbu-fivfvvkb-lddibdcr-irijjtkb-ufrkvbdd-ckcjkfhe-uillgvvt

Please save this secret recovery key at a secure location. It may be used to
regain access to the volume if the other configured access credentials have
been lost or forgotten. The recovery key may be entered in place of a password
whenever authentication is requested.
New recovery key enrolled as key slot 1.

Confirm the new slot and systemd-recovery token:

sudo cryptsetup luksDump /dev/sdc1 | sed -n '/Keyslots:/,/Digests:/p'

Sample output after recovery enrollment:

Keyslots:
  0: luks2
	...
  1: luks2
	...
	PBKDF:      pbkdf2
	...
Tokens:
  0: systemd-recovery
	Keyslot:    1

Test the recovery key without opening the mapper (replace with your generated key):

printf '%s' 'cnfnjjdb-dgtrvjbu-fivfvvkb-lddibdcr-irijjtkb-ufrkvbdd-ckcjkfhe-uillgvvt' | \
  sudo cryptsetup open --test-passphrase /dev/sdc1

Silent exit code 0 means the recovery key matches the enrolled slot.

Enroll TPM2

When a TPM2 device is present, list it first:

systemd-cryptenroll --tpm2-device=list

Sample output on hardware with a TPM:

/path/to/tpm2 (driver: …)

Enroll with automatic device selection. To bind unlock to boot state, pass PCR values — PCR 7 is a common starting point because it reflects Secure Boot policy:

sudo systemd-cryptenroll --tpm2-device=auto --tpm2-pcrs=7 /dev/sdc1

TPM2 enrollment without PCR binding:

• sudo systemd-cryptenroll --tpm2-device=auto /dev/sdc1 — omit --tpm2-pcrs
• TPM can unlock whenever the TPM seed matches
• Weaker assurance about firmware, kernel, or bootloader integrity

PCR binding cautions:

• PCR 7 — common starting point (Secure Boot policy)
• PCR 11 — mainly useful with UKI/systemd-stub boot paths
• Avoid binding to many firmware PCRs (0, 2, …) unless you have tested kernel, firmware, Secure Boot, and bootloader updates

After enrollment:

• luksDump shows a systemd-tpm2 token linked to the new key slot
• Wire crypttab with tpm2-device=auto
• Test systemd-cryptsetup attach before reboot
• Regenerate initramfs on Ubuntu/Debian: sudo update-initramfs -u -k all (or -u alone if only one kernel is installed)

VM testing:

• Enable a virtual TPM in VMware, Hyper-V, or libvirt
• Plain VirtualBox without vTPM keeps returning “No suitable TPM2 devices found”

Enroll FIDO2

FIDO2 enrollment needs a security key that implements the hmac-secret extension. List devices:

systemd-cryptenroll --fido2-device=list

Plug in the key, then enroll:

sudo systemd-cryptenroll --fido2-device=auto /dev/sdc1

Useful flags:

After FIDO2 enrollment:

• Add crypttab with fido2-device=auto
• Test systemd-cryptsetup attach before reboot
• Ensure initramfs includes FIDO2 support (cryptsetup-initramfs and a recent systemd on Ubuntu)

Enroll PKCS#11 (smartcard)

List smartcard or token URIs:

systemd-cryptenroll --pkcs11-token-uri=list

Enroll with a specific URI or auto:

sudo systemd-cryptenroll --pkcs11-token-uri=auto /dev/sdc1

PKCS#11 cautions:

• Cannot add another PKCS#11 key when the volume is already PKCS#11-only for unlock (see systemd-cryptenroll(1))
• Keep a passphrase, recovery key, FIDO2, or TPM2 slot available for rotation
• Wire crypttab with pkcs11-uri=auto and test attach before reboot

Wipe or rotate enrollments

Remove a specific key slot (for example after losing a FIDO2 key):

sudo systemd-cryptenroll --wipe-slot=2 /dev/sdc1

Before wiping a slot:

• Confirm another working slot remains (cryptsetup luksDump)
• Keep a LUKS header backup
• You can combine --wipe-slot with a new enrollment in one invocation

To change passphrases without hardware tokens, use cryptsetup luksChangeKey or see change LUKS keys and cipher.

Boot integration with crypttab

Enrollment writes token metadata to the LUKS2 header. Boot unlock still needs crypttab to name the mechanism:

• Plain luks — passphrase or recovery key prompt only (not unattended hardware unlock)
• tpm2-device=auto — TPM2 token unlock
• fido2-device=auto — FIDO2 token unlock
• pkcs11-uri=auto — PKCS#11 token unlock

Read the LUKS UUID for crypttab:

sudo cryptsetup luksUUID /dev/sdc1

Sample output on the lab disk:

e2e306a9-d94e-45d9-b209-4c9975fcede5

Add one line to /etc/crypttab based on what you enrolled:

# TPM2 unlock
secure_data UUID=e2e306a9-d94e-45d9-b209-4c9975fcede5 none luks,tpm2-device=auto

# FIDO2 unlock
secure_data UUID=e2e306a9-d94e-45d9-b209-4c9975fcede5 none luks,fido2-device=auto

# PKCS#11 unlock
secure_data UUID=e2e306a9-d94e-45d9-b209-4c9975fcede5 none luks,pkcs11-uri=auto

# Recovery key or passphrase prompt
secure_data UUID=e2e306a9-d94e-45d9-b209-4c9975fcede5 none luks

Recovery key at boot:

• Not unattended unlock
• High-entropy passphrase you type at the normal prompt when hardware unlock is unavailable

Boot flow:

1. Enroll TPM2, FIDO2, PKCS#11, or a recovery key on /dev/sdc1
2. Add the matching crypttab line (mount LUKS at boot for fstab and generator behavior)
3. Test attach before rebooting — official crypttab examples use this pattern

Test TPM2 attach (requires TPM enrollment on the volume):

sudo systemd-cryptsetup attach secure_data /dev/sdc1 none tpm2-device=auto
sudo systemd-cryptsetup detach secure_data

Test FIDO2 attach (key plugged in):

sudo systemd-cryptsetup attach secure_data /dev/sdc1 none fido2-device=auto
sudo systemd-cryptsetup detach secure_data

Test PKCS#11 attach (smartcard present):

sudo systemd-cryptsetup attach secure_data /dev/sdc1 none pkcs11-uri=auto
sudo systemd-cryptsetup detach secure_data

4. Regenerate initramfs on Ubuntu/Debian:

sudo update-initramfs -u -k all

For a single currently running kernel, sudo update-initramfs -u is usually enough.

5. On boot, systemd-cryptsetup@secure_data.service uses crypttab options to try token unlock before prompting

Fleet alternative:

• Clevis and Tang NBDE — network-assisted unlock instead of or alongside local TPM/FIDO2

Troubleshooting

References

• systemd-cryptenroll(1)
• systemd-cryptsetup(8)
• crypttab(5) man page
• cryptsetup token JSON format
• Ubuntu man page: systemd-cryptenroll(1)

Summary

• Adds TPM2, FIDO2, PKCS#11, and recovery-key unlock paths to LUKS2 volumes and stores token metadata in the header JSON area
• Recovery keys work on any machine; TPM2 and FIDO2 need real hardware (or vTPM for TPM2 in VMs)
• After enrollment, add the matching crypttab option (tpm2-device=auto, fido2-device=auto, or pkcs11-uri=auto), test with systemd-cryptsetup attach, regenerate initramfs, and keep a recovery key or passphrase slot as a backstop
