How to check Transparent HugePages in Linux

Transparent HugePages (THP) is a Linux memory-management feature that can back anonymous memory with larger pages, commonly 2 MB instead of normal 4 KB pages. Larger pages can reduce Translation Lookaside Buffer (TLB) overhead for workloads that scan or keep large memory regions hot, such as databases, virtual machines, JVMs, analytics jobs, and some high-performance services.

This guide shows how to check whether THP is enabled, how to check static hugepage status, how to read system-wide AnonHugePages, and how to identify per-process Transparent HugePage usage with smaps and smaps_rollup. The sample outputs below were tested on a Linux host, including a practical process that requested THP with madvise.

THP vs static hugepages

Linux has two related but different hugepage mechanisms:

Do not treat HugePages_Total: 0 as proof that THP is disabled. It only means no static HugeTLB pages are reserved. THP can still be enabled and used through AnonHugePages.

For background on memory pages and Linux memory accounting, see Linux memory management overview. For CPU support and hugepage sizes, see how to check CPU support for hugepages.

Quick commands

Check Transparent HugePages mode

Read /sys/kernel/mm/transparent_hugepage/enabled:

$ cat /sys/kernel/mm/transparent_hugepage/enabled
always [madvise] never

The active mode is shown in square brackets. In this tested output, madvise is active.

Check the THP defrag policy:

$ cat /sys/kernel/mm/transparent_hugepage/defrag
always defer defer+madvise [madvise] never

The active defrag mode is also shown in square brackets. In this tested output, madvise is active.

Defrag controls how aggressively the kernel compacts memory to create hugepage-sized contiguous ranges. Aggressive defrag can improve THP allocation success but may add latency for some workloads.

Check THP page size

The PMD-sized THP page size is exposed in bytes:

$ cat /sys/kernel/mm/transparent_hugepage/hpage_pmd_size
2097152

2097152 bytes is 2 MB. That is the common THP size on x86_64 systems.

Check system-wide hugepage counters

Use /proc/meminfo to see both Transparent HugePages and static HugeTLB counters:

$ grep -i huge /proc/meminfo
AnonHugePages:      2048 kB
ShmemHugePages:        0 kB
FileHugePages:         0 kB
HugePages_Total:       0
HugePages_Free:        0
HugePages_Rsvd:        0
HugePages_Surp:        0
Hugepagesize:       2048 kB
Hugetlb:               0 kB

Important fields:

In the tested output, static hugepages are not reserved because HugePages_Total is 0. THP is still present because AnonHugePages is 2048 kB.

Check static hugepage configuration

Static HugeTLB pages are controlled by vm.nr_hugepages and related settings:

$ sysctl vm.nr_hugepages vm.nr_overcommit_hugepages
vm.nr_hugepages = 0
vm.nr_overcommit_hugepages = 0

Here, vm.nr_hugepages = 0 means the kernel has not reserved a static HugeTLB pool. That does not disable THP. Static hugepages and THP are separate mechanisms.

To configure static hugepages, see how to configure HugePages using hugeadm and vm.nr_hugepages.

Check NUMA node hugepage counters

On NUMA systems, node-level memory files show hugepage counters per node:

$ grep -i huge /sys/devices/system/node/node*/meminfo
Node 0 AnonHugePages:      2048 kB
Node 0 ShmemHugePages:        0 kB
Node 0 FileHugePages:         0 kB
Node 0 HugePages_Total:     0
Node 0 HugePages_Free:      0
Node 0 HugePages_Surp:      0

This is useful when a multi-socket or NUMA host shows THP usage on one node but not another. The tested host has one visible NUMA node, node0.

Practical test: create THP-backed memory

A passive system may show little or no AnonHugePages at the moment you check. To prove how per-process THP accounting works, start a temporary process that requests THP with madvise(MADV_HUGEPAGE), touches 128 MB of anonymous memory, and sleeps while you inspect it.

$ python3 - <<'PY' &
import ctypes, mmap, os, time
size = 128 * 1024 * 1024
mm = mmap.mmap(-1, size, flags=mmap.MAP_PRIVATE | mmap.MAP_ANONYMOUS)
addr = ctypes.addressof(ctypes.c_char.from_buffer(mm))
libc = ctypes.CDLL('libc.so.6', use_errno=True)
ret = libc.madvise(ctypes.c_void_p(addr), ctypes.c_size_t(size), ctypes.c_int(14))
print(os.getpid(), ret, ctypes.get_errno(), flush=True)
for off in range(0, size, 4096):
    mm[off] = 1
time.sleep(90)
PY
62725 0 0
$ PID=$!
$ echo "$PID"
62725

The Python process printed 62725 0 0. The first value is the process ID, the second value is the madvise() return code, and the third value is errno. Return code 0 and errno 0 mean the madvise() call succeeded.

Check basic memory information for the process:

$ grep '^VmRSS\|^RssAnon\|^Threads' /proc/$PID/status
VmRSS:    140736 kB
RssAnon:  134252 kB
Threads:       1

The process has one thread and about 134 MB of anonymous resident memory.

Check per-process THP usage with smaps_rollup

For a quick per-process total, use /proc/PID/smaps_rollup:

$ grep -E '^(Rss|Pss|AnonHugePages):' /proc/$PID/smaps_rollup
Rss:              140736 kB
Pss:              138266 kB
AnonHugePages:     88064 kB

In this tested output, the process uses 88064 kB of anonymous Transparent HugePages. This value can be lower than the process RSS because not every mapped page must be backed by THP.

Check per-process THP usage with smaps

You can also sum every AnonHugePages line in /proc/PID/smaps:

$ awk '/^AnonHugePages:/ {sum += $2} END {print sum " kB"}' /proc/$PID/smaps
88064 kB

The summed value matches smaps_rollup for the tested process.

To see which mapping uses THP:

$ awk '/^[0-9a-f].*-/{map=$0} /^AnonHugePages:/ && $2>0 {print $0; print map; print ""}' /proc/$PID/smaps | head -n 10
AnonHugePages:     88064 kB
787fe9c00000-787ff1c00000 rw-p 00000000 00:00 0

This shows the mapping that has non-zero AnonHugePages.

Check system-wide THP after the test

While the test process is running, system-wide AnonHugePages increases:

$ grep -i '^AnonHugePages' /proc/meminfo
AnonHugePages:     90112 kB

This is system-wide THP usage. It includes the test process and any other process using anonymous THP at that moment.

Find all processes using Transparent HugePages

Use this loop to scan processes with readable smaps_rollup and print only processes with non-zero AnonHugePages:

$ for f in /proc/[0-9]*/smaps_rollup; do
>   pid=${f#/proc/}; pid=${pid%/smaps_rollup}
>   kb=$(awk '/^AnonHugePages:/ {print $2}' "$f" 2>/dev/null || true)
>   if [ -n "$kb" ] && [ "$kb" -gt 0 ]; then
>     comm=$(ps -p "$pid" -o comm= 2>/dev/null || true)
>     printf '%-8s %10s kB %s\n' "$pid" "$kb" "$comm"
>   fi
> done | sort -k2,2nr | head -n 5
62725         88064 kB python3
35249          2048 kB hugo

The tested output shows the temporary Python process using 88064 kB of THP and a separate hugo process using 2048 kB.

If you get permission errors, run as root or use sudo. Some kernels and security settings restrict access to other users' smaps files.

For general per-process memory checks, see how to check memory usage per process in Linux.

Interpret common results

Should Transparent HugePages be enabled?

There is no universal answer. THP can help workloads with large contiguous memory access patterns, but it can hurt latency-sensitive workloads if memory compaction causes stalls. That is why many database products document specific THP recommendations.

General guidance:

• Use madvise when you want applications to opt in to THP.
• Use always only after testing workload latency and memory behavior.
• Use never when the application vendor recommends disabling THP or when THP causes measurable latency spikes.
• Use static HugeTLB pages when an application explicitly requires reserved hugepages.

To disable THP persistently on RHEL/CentOS-style systems, see how to disable Transparent HugePages on RHEL 8.

Troubleshooting

Summary

Use cat /sys/kernel/mm/transparent_hugepage/enabled to check the THP mode. Use grep -i huge /proc/meminfo to compare Transparent HugePages counters such as AnonHugePages with static HugeTLB counters such as HugePages_Total. Use /proc/PID/smaps_rollup or /proc/PID/smaps to prove which process is actually using THP.

The most important distinction is this: vm.nr_hugepages and HugePages_Total are for static HugeTLB pages, while AnonHugePages shows Transparent HugePages currently in use.

References

• Linux kernel: Transparent Hugepage Support
• Oracle Linux: Configuring Transparent HugePages
• Clear Linux: Configure Huge Pages
• proc(5) Linux manual page
