In this article I will share the steps to configure PXE boot server using HTTP, Kickstart and DHCP / DNSMASQ service on a CentOS 7 node. The same list of steps will work on RHEL 7 as well. But to configure PXE boot server on RHEL you need an active subscription to be able to download the required rpms or you can also download these rpms by creating a local repository using the RHEL vanilla DVD image.

It is not mandatory to only use the services from this article to configure PXE boot server in Linux. You can also use other services like NFS, FTP etc to serve the purpose.

How to configure PXE boot server in Linux (CentOS / RHEL 7)



What is PXE boot server?

PXE, or Preboot eXecution Environment, allows you to instruct computers to boot using network resources. This allows you to control a single source to install servers without the need to physically insert some DVDs or USB sticks.



Design of the PXE network boot

  • When a machine uses the PXE (Pre-eXecution Environment) to boot directly off the network, it needs to get an IP address from a DHCP server.
  • The DHCP server can also give it the details of a TFTP server from which to retrieve an executable file. Typically for a Linux client, this file is called pxelinux.0.
    NOTE:
    If you use DNSMASQ then it takes care of pointing booting systems to the tftp server by providing the enable-tftp option in the dnsmasq configuration file and you do not need a separate DHCP server.
  • Once the client retrieves and executes pxelinux.0, it is hard-coded to look for a file from the pxelinux.cfg/ subdirectory relative to where pxelinux.0 was found.
  • Here we have a PXE file which will contain PXE boot menu and the location of the repository which will be used for the installation.



Create kickstart file

When you install a Red Hat system, a file with the name anaconda-ks.cfg is created in the home directory of the root user. This file contains most settings that were used while installing your computer. It is a good starting point if you want to try out an automated Kickstart installation.

You can also use system-config-kickstart tool on the GUI to create your own kickstart file. Follow the official CentOS page to get the various options with this tool.

Since we plan to automate our installation using kickstart and network boot PXE server so we will need a working kickstart file. I have written another article which contains a sample kickstart configuration file which you can use for reference. For this article I will use kickstart file /root/kickstart.conf with below content.

# System authorization information
auth --enableshadow --passalgo=sha512

# Use Network installation media
url –url="http://10.0.2.20/rhel/"

# Use textual install
text

# Run the Setup Agent on first boot
firstboot --disable
ignoredisk --only-use=sda

# Keyboard layouts
keyboard --vckeymap=us --xlayouts='us'

# System language
lang en_US.UTF-8

# Network information
network --bootproto=dhcp --device=enp0s8 --onboot=off --noipv6 --activate
network --hostname=node2.example.com

# Root password
rootpw --iscrypted $6$CXxBapbzNlScWzBU$45c4bxK9/pDVls/aJcaT/9kENR0OFxMhohBf7k8RrBWtzTs42ljw4SER0AqYTDEdWHlDWE4BTTnQX8vkMWJ6l1

# System services
services --enabled="chronyd"

# System timezone
timezone Asia/Kolkata --isUtc

# System bootloader configuration
bootloader --append=" crashkernel=auto" --location=mbr --boot-drive=sda

# Partition clearing information
clearpart --none --initlabel
autopart --type=plain --fstype=ext4

%packages
@^infrastructure-server-environment
@base
@core
chrony
kexec-tools

%end



Configure HTTP

Loading kickstart files over the network from the kernel line during an install only supports NFS, HTTP, and FTP. In this recipe, I choose HTTP as it is a common technology within companies and easy to secure.

Install the Apache server rpm if not installed already

NOTE:
On RHEL system you must have an active subscription to RHN or you can configure a local offline repository using which “yum” package manager can install the provided rpm and it’s dependencies.
# yum -y install http

Create a directory to contain the kickstart file(s) by running the following command:

# mkdir /var/www/html/kickstart
# cp /root/kickstart.conf /var/www/html/kickstart

Give appropriate permission

# chown -R apache:apache /var/www/html/

Enable and start the httpd daemon, as follows:

# systemctl enable httpd
Created symlink from /etc/systemd/system/multi-user.target.wants/httpd.service to /usr/lib/systemd/system/httpd.service.

# systemctl start httpd

Next try to download the kickstart file to make sure it is accessible from the apache server

[root@node1 # wget http://10.0.2.20/kickstart/kickstart.conf
--2018-11-05 21:14:32-- http://10.0.2.20/kickstart/kickstart.conf
Connecting to 10.0.2.20:80... connected.
HTTP request sent, awaiting response... 200 OK
Length: 1491 (1.5K) [text/plain]
Saving to: ‘kickstart.conf’

100%[======================================>] 1,491 --.-K/s in 0s

2018-11-05 21:14:32 (319 MB/s) - ‘kickstart.conf’ saved [1491/1491]



Setup the source repository for network installation

The next step to set up an installation server is to configure a network server as installation server. This comes down to copying the entire installation DVD to a share on a network server, which makes the installation server an online repository. After doing this, you can use a client computer to access the installation files.

I have a vanilla Red Hat DVD which I will use as my repository for the installation via network but instead of copying, I will mount my image.

# mount /root/rhel-server-7.4-x86_64-dvd.iso /var/www/html/rhel/
mount: /dev/loop0 is write-protected, mounting read-only

Since we will use the repo over our HTTP server hence I will use mount partition inside /var/www/html



Configure TFTP service

Now that you have set up a network installation server, it is time to configure PXE boot. This allows you to boot a server you want to install from the network card of the server. (You normally have to change default boot order, or press a key while booting, to activate PXE boot (Mostly F12) The PXE server next hands out a boot image that the server you want to install uses to start the initial phase of the boot.



Install the RPMs

First of all you need to install all the rpms required to configure PXE boot server

[root@node1 # yum -y install syslinux tftp-server xinetd
NOTE:
The xinetd service is also known as the Internet super service. It comes from a time where memory resources were limited, and to use memory as efficiently as possible, xinetd could be configured to listen on many ports, making it possible to access many different services. Using xinetd can still be helpful, particularly for services that are not accessed very often. The xinetd service will make sure that the service is started when some processes access its port, and will also shut it down after a specific period of inactivity.

Enable the tftp server’s xinetd daemon, as follows:

# sed -i '/disable/ s/yes/no/' /etc/xinetd.d/tftp

Now, enable and start the xinetd daemon by running the following:

# systemctl enable xinetd
# systemctl start xinetd

Copy the syslinux boot loaders to the tftp server’s boot directory by executing the following command:

# cp -r /usr/share/syslinux/* /var/lib/tftpboot

Copy initrd and kernel from the RHEL 7 installation media to /var/lib/tftpboot/rhel7/, and run the following commands:

# mkdir /var/lib/tftpboot/rhel7

Since our DVD is already mounted on /var/www/html/rhel, we can copy the required files from the same location

# cp /var/www/html/images/pxeboot/{initrd.img,vmlinuz} /var/lib/tftpboot/rhel7/

Next, create the PXE configuration directory using this command:

# mkdir /var/lib/tftpboot/pxelinux.cfg

Then, create the PXE configuration file, as follows: /var/lib/tftpboot/pxelinux.cfg/default.

default menu.c32
prompt 0
timeout 300
ontimeout 2

menu title PXE Boot Menu
label 1
  menu label ^1 - Install RHEL 7 x64 with Local http Repo
  kernel rhel7/vmlinuz
  append initrd=rhel7/initrd.img showopts  method=http://10.0.2.20/rhel/ devfs=nomount ks=http://10.0.2.20/kickstart/kickstart.conf

label 2
  menu label ^2 - Boot from local media
  localboot 0x80

Here we are using menu.c32 to get the splash screen menu and defining a timeout of 300 value and within the timeout value if there is no user input then 2nd label will be called i.e. to boot from local disk.
In this file, make sure that the title of the menu label starts with a ^, which identifies it as a menu label title. Also make sure that the append line is one line only that starts with append and ends with the URL to the Kickstart file.



Next you can either use DNSMASQ or DHCP server, I have shared the steps to configure both but you can choose one as per your continence



Steps to configure PXE boot server using DNSMASQ server

In case you plan to use DNSMASQ instead of DHCP, then you can use the below steps to configure your DNSMASQ services



Install the RPMs

First of all you need to install all the rpms required to configure PXE boot server

NOTE:
On RHEL system you must have an active subscription to RHN or you can configure a local offline repository using which "yum” package manager can install the provided rpm and it’s dependencies.
[root@node1 # yum -y install dnsmasq



Configure DNSMASQ

Next configure the DNSMASQ server by editing /etc/dnsmasq.conf, as follows:

# interfaces to bind to
interface=eth0,lo
# the domain for this DNS server
domain=example.com
# DHCP lease range
dhcp-range=eth0,10.0.2.200,10.0.2.220,10h
# PXE – the address of the PXE server
dhcp-boot=pxelinux.0,pxeserver,10.0.2.20
# Gateway
dhcp-option=3,10.0.2.2
pxe-prompt="Press F8 for menu.", 60
enable-tftp
tftp-root=/var/lib/tftpboot

Enable and start dnsmasq using the following:

# systemctl enable dnsmasq
# systemctl start dnsmasq



Steps to configure PXE boot server using DHCP server

In case you plan to use DHCP instead of DNSMASQ, then you can use the below steps to configure your DHCP services



Configure DHCP Server

On an installation server, the TFTP server cannot exist without a DHCP server. When making a PXE boot, the DHCP server is the first to answer with all the required IP-related configuration and information about the DHCP server that is to be used.



Install the RPMs

First of all you need to install all the rpms required to configure PXE boot server

[root@node1 # yum -y install dhcp

Next configure your /etc/dhcp/dhcpd.conf. Below is my sample config file. Here you need to add separate entry for every host MAC Address (as highlighted) to netboot using PXE server.

#
# DHCP Server Configuration file.
#   see /usr/share/doc/dhcp*/dhcpd.conf.example
#   see dhcpd.conf(5) man page
#

allow bootp;
allow booting;
max-lease-time 1200;
default-lease-time 900;
log-facility local7;

option ip-forwarding    false;
option mask-supplier    false;

   subnet 10.0.2.0 netmask 255.255.255.0 {

       option  routers   10.0.2.2;
       option  domain-name-servers  127.0.0.1;
       range 10.0.2.30 10.0.2.40;
       next-server 10.0.2.20;
       filename "pxelinux.0";
   }

In the DHCP configuration file, a subnet is specified. This is the subnet where the PXE server should offer its services. In most configurations, this would be a dedicated network, which is a good idea, because you do not want workstations that perform a PXE boot to get installed with Red Hat Enterprise Linux by accident. If you want to offer PXE-based installation services on a network where also clients are in use that rely on PXE boot, it is recommended to define a class statement to define which machines should be allowed to use PXE boot and which should not.

Within the subnet definition, the next-server statement gives the IP address of the server that is configured with TFTP. Even if it is on the same server that is offering DHCP, you should still specify the next-server IP address. The filename statement defines the file that should be offered to workstations that are making a PXE boot. Notice that this filename is relative to the TFTP server root as defined in the TFTP configuration file.

Open the firewall on your server using these commands (however, this may not be necessary):

# firewall-cmd --add-service=dns --permanent
# firewall-cmd --add-service=dhcp --permanent
# firewall-cmd --add-service=tftp --permanent
# firewall-cmd --reload
NOTE:
If you face any issues during your POC stage then you can disable and stop the firewall services and validate your configuration to isolate the cause of the failure. Once the issue is found, it is strongly recommended to keep the firewall services enabled and active.



How the flow would work?

  • Now we are all done with our configuration. It is time to boot your target node via NIC card.
  • Once the target node boots from NIC card, it will search for available DHCP server.
  • DNSMASQ/DHCPD daemon takes care of pointing booting systems to the tftp server by providing the enable-tftp option in the dnsmasq configuration or next-server in the dhcpd.conf file.
  • syslinux is needed to provide the necessary binaries to boot from the network.
  • The tftp server itself provides access to the syslinux files, RHEL 7 kernel, and initrd for the system to boot from.
  • The PXE configuration file provides the necessary configuration to boot a system, including a kickstart file that automatically installs your system.



On your server side in the /var/log/messages you can monitor the progress of the PXE boot

When using DHCP

Nov 6 00:26:01 node1 dhcpd: DHCPDISCOVER from 08:00:27:88:0b:f3 via eth0
Nov 6 00:26:02 node1 dhcpd: DHCPOFFER on 10.0.2.30 to 08:00:27:88:0b:f3 via eth0
Nov 6 00:26:04 node1 dhcpd: DHCPREQUEST for 10.0.2.30 (10.0.2.20) from 08:00:27:88:0b:f3 via eth0
Nov 6 00:26:04 node1 dhcpd: DHCPACK on 10.0.2.30 to 08:00:27:88:0b:f3 via eth0
Nov 6 00:26:04 node1 xinetd[1018]: START: tftp pid=8021 from=10.0.2.30
Nov 6 00:26:04 node1 in.tftpd[8[8022]Client 10.0.2.30 finished pxelinux.0
Nov 6 00:26:04 node1 in.tftpd[8[8033]Client 10.0.2.30 finished pxelinux.cfg/default
Nov 6 00:26:04 node1 in.tftpd[8[8034]Client 10.0.2.30 finished menu.c32
Nov 6 00:26:04 node1 in.tftpd[8[8035]Client 10.0.2.30 finished pxelinux.cfg/default



When using DNSMASQ

Nov 5 23:48:15 node1 dnsmasq-dhcp[7[7036]DHCPDISCOVER(eth0) 08:00:27:88:0b:f3
Nov 5 23:48:15 node1 dnsmasq-dhcp[7[7036]DHCPOFFER(eth0) 10.0.2.217 08:00:27:88:0b:f3
Nov 5 23:48:15 node1 dnsmasq-dhcp[7[7036]DHCPREQUEST(eth0) 10.0.2.217 08:00:27:88:0b:f3
Nov 5 23:48:15 node1 dnsmasq-dhcp[7[7036]DHCPACK(eth0) 10.0.2.217 08:00:27:88:0b:f3
Nov 5 23:48:21 node1 dnsmasq-dhcp[7[7036]PXE(eth0) 10.0.2.217 08:00:27:88:0b:f3 pxelinux.0
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]sent /var/lib/tftpboot/pxelinux.0 to 10.0.2.217
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/01-08-00-27-88-0b-f3 not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0A0002D9 not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0A0002D not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0A0002 not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0A000 not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0A00 not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0A0 not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0A not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]file /var/lib/tftpboot/pxelinux.cfg/0 not found
Nov 5 23:48:21 node1 dnsmasq-tftp[7[7036]sent /var/lib/tftpboot/pxelinux.cfg/default to 10.0.2.217
Nov 5 23:48:22 node1 dnsmasq-tftp[7[7036]sent /var/lib/tftpboot/menu.c32 to 10.0.2.217
Nov 5 23:48:22 node1 dnsmasq-tftp[7[7036]sent /var/lib/tftpboot/pxelinux.cfg/default to 10.0.2.217



NOTE:

Here in the message as you see multiple messages with not found.
Once the client retrieves and executes pxelinux.0, it is hard-coded to look for a file from the pxelinux.cfg/ subdirectory relative to where pxelinux.0 was found.

First, it will look for a file named after the MAC address, in the form 01-xx-xx-xx-xx-xx-xx; then, it will look for a file named by the IP address as provided by the DHCP server. The IP address is looked up in hexadecimal format. i.e. 10 in hexadecimal is 0x0A, 0 is 0x00, 2 is 0x02, and 217 is 0xD9, so 10.0.2.217 is 0x0A0002D9.

You can also get this value using printf in the below format

# printf "%02x%02x%02x%02x\n" 10 0 2 217
0a0002d9



Below is a sample of the splash screen with “PXE Boot menu” which will be printed on that target node once booted from the NIC card.

How to configure PXE boot server in Linux (CentOS / RHEL 7)



Lastly I hope the steps from the article to configure PXE boot server on Linux was helpful. This is a very small part of what actually we can do when configuring a PXE boot server. There are various other options to customise the configuration or use other protocols like NFS. So, let me know your suggestions and feedback using the comment section.



3 Comments

  1. Hi Admin ,

    Excellent blog post , I tried this today and worked like a charm , thanks for the lovely write up on PXE booting . It gave an great understanding about the pxe boot process for a person like who is relatively new to linux and networking 🙂

  2. Hi,

    I have setup PXE server as mentioned above but splash screen not coming on client, i am able to on server that pxelinux.0 has been successfully sent to client. what might be the issue?

    1. default menu.c32

      This file shows the splash screen, if this is not available then the screen will also not be visible.
      Disable your firewall and selinux to make sure they are not the cause of the problem.
