In this article I will share different commands and methods to Test SSH connection in Linux and Unix with real time practical examples.
Method 1: Use timeout with bash utility to test SSH connection
/usr/bin/timeout utility is installed by default in most distros which is part of coreutils rpm in Linux
Check if coreutils is installed on your server
# rpm -q coreutils coreutils-8.22-24.el7.x86_64
We can use bash utility with timeout to test SSH connection by checking port 22 status.
If you are using a different port for 22 then you can replace it in the below syntax
Syntax:
# timeout <value> bash -c "</dev/tcp/<server>/<port>"
Here server2 is my target host, I will execute the command with a timeout value of 5s on port 22
[root@server1 ~]# timeout 5 bash -c "</dev/tcp/server2/22"
If the exit status is 0, it means test ssh connection was successful
[root@server1 ~]# echo $?
0
Or if you get "connection refused" with non-zero exit status then test SSH connection has failed
[root@server1 ~]# timeout 5 bash -c "</dev/tcp/server2/22" bash: connect: Connection refused bash: /dev/tcp/10.10.10.10/22: Connection refused [root@server1 ~]# echo $? 1
Shell Script Example
We can use this tool in a shell script to test SSH connection over port 22
# cat /tmp/check_connectivity.sh #!/bin/bash server=10.10.10.10 # server IP port=22 # port connect_timeout=5 # Connection timeout timeout $connect_timeout bash -c "</dev/tcp/$server/$port" if [ $? == 0 ];then echo "SSH Connection to $server over port $port is possible" else echo "SSH connection to $server over port $port is not possible" fi
Method 2: Use nmap to test SSH connection
/usr/bin/nmapis provided bynmaprpm.nmapis widely used to check port status so we can usenmapto checkport 22status on target hostnmapis not installed by default in most distros and you must install it before using it- On RHEL/CentOS environment use yum or
dnfto installnmap
# yum -y install nmap
Syntax:
# nmap <server> -PN -p ssh | egrep 'open|closed|filtered'
Here,
-Pn Treat all hosts as online -- skip host discovery -p ssh Only scan the default SSH port open means that an application on the target machine is listening for connections/packets on that port closed ports have no application listening on them, though they could open up at any time filtered means that a firewall, filter, or other network obstacle is blocking the port so that Nmap cannot tell whether it is open or closed.
Here server2 is my target host and we are looking for nmap port status
[root@server1 ~]# nmap server2 -Pn -p ssh | egrep -io 'open|closed|filtered' closed [root@server1 ~]# nmap server2 -Pn -p ssh | egrep -io 'open|closed|filtered' open
Shell script Example
We can use this command in our shell script to test SSH connection over port 22
[root@server1 ~]# cat /tmp/check_connectivity.sh #!/bin/bash server=10.10.10.10 # server IP port=22 # port connect_timeout=5 # Connection timeout status=`nmap $server -Pn -p $port | egrep -io 'open|closed|filtered'` if [ $status == "open" ];then echo "SSH Connection to $server over port $port is possible" elif [ $status == "filtered" ]; then echo "SSH Connection to $server over port $port is possible but blocked by firewall" elif [ $status == "closed" ]; then echo "SSH connection to $server over port $port is not possible" else echo "Unable to get port $port status from $server" fi
Method 3: Use netcat or nc to test SSH connection
- In my earlier article I had shared the steps to use
ncandncatto transfer files between Linux server. - We can also use
ncandncatutility to check port status from target hosts and test SSH connection ncandncatis provided bynmap-ncatrpm
To check if nmap-ncat is installed on your server
# rpm -q nmap-ncat nmap-ncat-6.40-19.el7.x86_64
Syntax:
# nc --wait <value> <server> <port> < /dev/null &> /dev/null
Here we have defined a connection timeout period of 5 second which you can change based on your environment
Check the exit status of nc command in this command. For 0 exit status we know that port 22 is open and SSH connection will be successful.
[root@server1 ~]# nc --wait 5 server2 22 < /dev/null &> /dev/null [root@server1 ~]# echo $? 0
For non-zero exit status we know that SSH connection will fail for respective target host
[root@server1 ~]# nc --wait 5 server2 22 < /dev/null &> /dev/null [root@server1 ~]# echo $? 1
Shell Script Example
We can use this command in our shell script example to automate the verification
# cat /tmp/check_connectivity.sh #!/bin/bash server=10.10.10.10 # server IP port=22 # port connect_timeout=5 # Connection timeout nc --wait $connect_timeout $server $port < /dev/null &> /dev/null if [ $? == 0 ];then echo "SSH Connection to $server over port $port is possible" else echo "SSH connection to $server over port $port is not possible" fi
Method 4: Use SSH to check SSH connection
- I know we are looking for SSH alternatives to check SSH connection but if you have a setup configured with password less connection then you can also use SSH for this verification
- We will use
ConnectTimeoutto make sure our SSH don't get stuck waiting for connection to become active StrictHostKeyCheckingis used to avoid any security and fingerprint prompt- If
BatchModeisyesthen passphrase/password querying will be disabled
sshpass or expect scriptHere we are using 'exit 0' as the remote command to be called on successful SSH
[root@server1 ~]# ssh -q -o BatchMode=yes -o StrictHostKeyChecking=no -o ConnectTimeout=5 server2 'exit 0' [root@server1 ~]# echo $? 0
While if the output exit status is non-zero so we know the test SSH connection has failed
[root@server1 ~]# ssh -q -o BatchMode=yes -o StrictHostKeyChecking=no -o ConnectTimeout=5 server2 'exit 0' [root@server1 ~]# echo $? 255
Shell Script Example
We can use this command in our existing shell script for automation purpose:
# cat /tmp/check_connectivity.sh #!/bin/bash server=10.10.10.10 # server IP port=22 # port connect_timeout=5 # Connection timeout ssh -q -o BatchMode=yes -o StrictHostKeyChecking=no -o ConnectTimeout=$connect_timeout $server 'exit 0' if [ $? == 0 ];then echo "SSH Connection to $server over port $port is possible" else echo "SSH connection to $server over port $port is not possible" fi
Method 5: Use telnet to test SSH connection
telnetis another very handy tool to check port status/usr/bin/telnetis provided by telnet rpm which is part of default repositories and you do not need any third party repository
Check if telnet is installed
# rpm -q telnet telnet-0.17-65.el7_8.x86_64
Syntax:
# telnet <server> <port>
But since our end goal is to automate so we will tweak the syntax
# echo quit | telnet <server> <port> 2>/dev/null | egrep -qi Connected
Let us use this to test SSH connection in Linux. if we are able to grep for "Connected" then port 22 is reachable and SSH connection is possible
[root@server1 ~]# echo quit | telnet server2 22 2>/dev/null | egrep -qi Connected [root@server1 ~]# echo $? 0
If we get a non-zero exit status, this means that we were unable to grep "Connected" in the output hence SSH connection is not possible
[root@server1 ~]# echo quit | telnet server2 22 2>/dev/null | egrep -qi Connected [root@server1 ~]# echo $? 1
Shell Script Example
We will use telnet with our existing sample shell script to test SSH connection
# cat /tmp/check_connectivity.sh #!/bin/bash server=10.10.10.10 # server IP port=22 # port connect_timeout=5 # Connection timeout echo quit | telnet $server $port 2>/dev/null | egrep -qi "Connected" if [ $? == 0 ];then echo "SSH Connection to $server over port $port is possible" else echo "SSH connection to $server over port $port is not possible" fi
Conclusion
In this tutorial guide we learned about different internal tools within Linux and Unix which can be used to test and verify SSH connection before actually attempting the SSH. We do not need to rely on additional third party tools for such verification. It is always a good idea to first check the network connectivity and port 22 availability before performing the SSH to avoid un-necessary wait time and timeout scenarios
Lastly I hope the commands from this article to test SSH connection on Linux and Unix was helpful. So, let me know your suggestions and feedback using the comment section.
References
I have used below external references for this tutorial guide
How to create a bash script to check the SSH connection?
For mthod 5, I use this command:
Found this useful. Thanks for the detailed tutorial.
Can u give a few examples to check the SSH connection possibility on Windows 10 PC to a Raspberry Pi?
I wish I could help but I don’t have that kind of infra to test this scenario
What would be a good test for ssh over an Socky5 proxy? I have docker image that proxies a vpn connection. I can test it’s web proxy function with “curl” as that utility supports proxies and the container doesn’t have to have a user account to get a response.
For ssh, the docker image needs to make sure it can connect to a remote server over its own proxy( on port 9000 in my example ). Something like this would work if the container had an account to use to login, but it doesn’t ( in my environment, only people have accounts, service accounts are not permitted)
E.g. ssh -q -o BatchMode=yes -o StrictHostKeyChecking=no -o ProxyCommand=”nc -x localhost:9000 %h %p” -o ConnectTimeout=3 remote_ssh_host ‘exit 0’
What might be a good alternative?
I am afraid, I am also not familiar with such environment and possible solution. Although we wouldn’t need a service account to execute SSH. SA is used when we intend to connect source host for some activity but your usecase is only to execute ssh client. In Kubernetes + docker we defined runAsUser which we use to perform SSH. In docker also we can define –user but I am not sure if this is allowed in your environment.
We use ssh keys, so the docker image / container would need to have those keys as well. However, the issue I encountered was that Alpine linux image had the Busybox version of netcat, which does not support the “
-x” proxy parameter.I found the netcat-bsd package for Alpine that supports the “-x” proxy parameter. I installed that to my image and was able to use “
timeout 3 nc -zvx localhost:9000 hostname 22” to test access to the remote port 22 using the proxy as a relay.so
curl --fail --proxyis used to Web proxy tests, and the netcat command tests the socks proxy connection.This was really helpful.
What about using ssh-keyscan ? then you know if you get a key it means is ready for ssh connection
ssh-keyscanis another utility similar to SSH which performs connection to remote host. So the problem may remain the same if the utility gets stuck sossh-keyscanhas it’s own timeout argument (-T).It all actually depends on end user’s requirement.
Here is an improved version that scans a range of ip’s, checks for ssh password-less auth and prints hostname as well
#!/bin/bash username="username" for server in "192.168.0."{200..214} do ssh -q -o ConnectTimeout=2 -o NumberOfPasswordPrompts=0 -l $username -i ~/.ssh/id_rsa "$server" 'exit 0' inc=$? ns=$(nslookup $server| awk '/1:/{print $4}') if [ $inc -eq 0 ]; then echo "$server + $ns" else echo "$server - $ns" fi doneMy view is rather than using SSH just to verify the connectivity would be resource intensive and time consuming. SSH method is well suited only when we plan to do SSH and as a pre-check we use this method to make sure SSH session doesn’t get stuck forever waiting for the connection.
For method 4 you can use “-o NumberOfPasswordPrompts=0” so it doesn’t prompt for password in case key auth is not accepted
