How to Install Modoboa Mail Server on Ubuntu

Running your own mail server on Ubuntu is a common homelab and small-business goal. Modoboa wraps Postfix, Dovecot, Nginx, Amavis, SpamAssassin, and ClamAV behind a Python web admin panel and webmail—so you do not have to wire every component by hand.

This guide walks through a full Modoboa install on Ubuntu: server prep, DNS, the official modoboa-installer, post-install domain and mailbox setup, client configuration, deliverability (SPF, DKIM, DMARC, PTR), testing, and the failures people hit most often in production threads and GitHub issues. I ran the installer on Ubuntu 25.04 and kept the real terminal output below so you can compare your VPS. Where something tripped me up—missing Radicale paths, proxy env vars breaking curl, the old modo check_mx command in outdated guides—you will find the fix in the same section.

Tested on: Ubuntu 25.04 (Plucky Puffin); kernel 6.14.0-37-generic.

Quick command reference

What Modoboa includes

Modoboa is a free, open-source mail hosting platform (ISC license) written in Python. A typical install bundles:

You manage domains, mailboxes, and aliases in the browser. End users can use webmail or clients like Thunderbird and Outlook. The same installer supports Ubuntu 20.04 LTS (Focal) and newer per the official modoboa-installer.

Prerequisites

Before you run the installer, confirm you have:

VPS providers and port 25

Inbound port 25 to your server is usually fine. Outbound port 25 is what providers block—and without it you cannot deliver mail directly to Gmail, Outlook, and others.

Providers often mentioned as allowing port 25 (verify current policy before you buy): OVH, Contabo, Kamatera, Hetzner, and similar bare-metal or niche VPS hosts. DigitalOcean, Vultr, and AWS commonly block outbound 25 unless you open a support ticket—and they may re-block later.

Test after install:

timeout 8 bash -c 'echo quit | telnet gmail-smtp-in.l.google.com 25'

On my test host, outbound port 25 was open. You should see something like this when it works:

Trying 192.178.211.26...
Connected to gmail-smtp-in.l.google.com.
Escape character is '^]'.
Connection closed by foreign host.

Connection timeout or Unable to connect means you need an unblock or an SMTP relay (e.g. SendGrid, Amazon SES). See Postfix relay restrictions if you route outbound mail through a provider.

Step 1 — Plan DNS records

Mail breaks when DNS is wrong. Set these before running the installer if you use Let's Encrypt.

Required before install

Set hostname on the server

sudo hostnamectl set-hostname mail.example.com

Ensure /etc/hosts resolves the FQDN (add only if missing):

grep -q 'mail.example.com' /etc/hosts || echo '127.0.1.1 mail.example.com mail' | sudo tee -a /etc/hosts

Verify:

hostname -f

You want the FQDN you set—for example:

mail.example.com

After install (deliverability)

You will add SPF, DKIM, and DMARC once the domain exists in Modoboa. PTR (reverse DNS) is set at your hosting provider, not your domain registrar—value should be mail.example.com.

Step 2 — Update Ubuntu and install dependencies

Log in via SSH and update packages:

sudo apt update
sudo apt upgrade -y

Install tools the installer needs:

sudo apt install -y git python3-virtualenv python3-pip curl gnupg2 dnsutils inetutils-telnet

See apt on Linux if you are new to package management on Ubuntu. curl is handy later when you probe the web UI from the shell.

Optional but useful if the installer fails on Cairo-related Python packages:

sudo apt install -y libcairo2-dev pkg-config python3-dev

Before the first install, create the Radicale config directory. This one caught me on a retest—the installer can fail if /etc/modoboa-radicale does not exist yet:

sudo mkdir -p /etc/modoboa-radicale

After dependencies install, git --version on my host reported:

git version 2.48.1

Step 3 — Download and configure the Modoboa installer

Clone the official installer:

git clone https://github.com/modoboa/modoboa-installer
cd modoboa-installer
ls -l run.py

Clone and listing looked like this on my machine:

Cloning into 'modoboa-installer'...
-rwxr-xr-x 1 user user 10336 ... run.py

Generate installer.cfg (replace example.com with your apex domain, not mail.example.com):

sudo python3 ./run.py --stop-after-configfile-check example.com

The config check prints a short welcome and creates installer.cfg when it is missing:

Welcome to Modoboa installer!

Checking the installer...
Installer seems up to date!
Checks complete

Configuration file installer.cfg not found, creating new one.

Edit the config:

sudo nano installer.cfg

Fresh installer.cfg files usually contain lines like these (sudo grep -E '^(hostname|type|engine)' installer.cfg):

hostname = mail.%(domain)s
type = amavis
type = self-signed
engine = postgres

Common installer.cfg settings

TLS — production (recommended):

[certificate]
type = letsencrypt

[letsencrypt]
email = [email protected]

TLS — lab / internal only:

[certificate]
type = self-signed

Database — PostgreSQL (default):

[database]
engine = postgres
host = 127.0.0.1
install = true

Database — MariaDB/MySQL:

[database]
engine = mysql
host = 127.0.0.1
install = true

Use a real email for Let's Encrypt; the default placeholder address will cause certificate issuance to fail. For more on TLS in front of Nginx, see install an SSL certificate on Nginx.

Step 4 — Run the installer

Confirm DNS for mail.example.com resolves to this server:

dig +short mail.example.com A

The command should print your server IP. Empty output means the A record is missing or not propagated yet.

Start the interactive install:

sudo python3 ./run.py --interactive example.com

Confirm when prompted. On my test host (3 vCPU, 8 GB RAM), the full run.py pass took about 10 minutes end to end. Budget 15–25 minutes on a fresh 2 GB VPS—ClamAV definition downloads and pip compiles are usually the slow part.

Near the start of a successful run you should see the component list and install banners:

Your mail server will be installed with the following components:
fail2ban modoboa amavis clamav dovecot nginx postfix postwhite spamassassin uwsgi radicale opendkim
The process can be long, feel free to take a coffee and come back later ;)
Starting...
Generating new self-signed certificate
Installing fail2ban
Installing modoboa
Installing radicale
Installing uwsgi
Installing nginx
Installing postfix
Installing dovecot
Installing amavis
Installing spamassassin
Installing clamav
Installing opendkim

When it finishes cleanly, the installer prints the admin URL and default password:

Congratulations! You can enjoy Modoboa at https://mail.example.com (admin:password)

Verify services and web UI

After install, confirm core services and ports:

systemctl is-active nginx postfix dovecot uwsgi postgresql
ss -lnpt | grep -E ':443|:25|:587|:993'
curl --noproxy '*' -k -sI --resolve mail.example.com:443:127.0.0.1 https://mail.example.com/accounts/login/

Use --noproxy '*' if your shell has http_proxy/https_proxy set—otherwise curl may fail against localhost. That bit me on a host with proxy env vars exported.

Core services on my install were all active:

nginx              active
postfix            active
dovecot            active
uwsgi              active
postgresql         active

Listening mail and web ports looked like this:

LISTEN 0  100  0.0.0.0:25    0.0.0.0:*
LISTEN 0  511  0.0.0.0:443   0.0.0.0:*
LISTEN 0  100  0.0.0.0:587   0.0.0.0:*
LISTEN 0  100  0.0.0.0:993   0.0.0.0:*
LISTEN 0  100  127.0.0.1:9999  0.0.0.0:*

The login page returned HTTP/2 200 with a Modoboa title:

HTTP/2 200
server: nginx/1.26.3 (Ubuntu)
content-type: text/html; charset=utf-8

Page title: Welcome to Modoboa. Modoboa version installed: 2.9.0. I did not run a full Gmail round-trip on the test domain—that needs real DNS and mailboxes in the admin UI (covered in Step 5).

If it fails, retry with debug output:

sudo python3 ./run.py --interactive --debug example.com

Reboot once to ensure all services start cleanly:

sudo shutdown -r now

Default login

Change the password immediately: Admin → Settings → Profile.

Step 5 — Add your domain and mailboxes

Add the mail domain

1. Open the admin panel → Domains → Add.
2. Enter example.com as the domain name.
3. Enable DKIM signing (selector e.g. modoboa, key length 2048).
4. Optionally create a domain admin; SMTP best practice expects a [email protected] address.

Create a mailbox

1. Domains → select your domain → Mailboxes → Add → Account.
2. Role: Simple user.
3. Set username (e.g. alice) and password.

Create an alias (optional)

Domains → your domain → Aliases → Add — e.g. [email protected] → [email protected].

Step 6 — Publish SPF, DKIM, and DMARC

These records live at your DNS host. They are what Gmail, Microsoft, and Yahoo check before accepting your mail.

SPF (TXT on apex domain)

Tighten later with ip4:YOUR.SERVER.IP if you send only from this host.

Verify:

dig example.com TXT +short

Until you publish your own record, dig against a reserved name like example.com may show the IANA placeholder:

"v=spf1 -all"

Your domain should show your own SPF record after you publish it.

DKIM (TXT record)

In Modoboa: Domains → your domain → DNS → Show key. Copy the Bind/named format.

If DKIM keys do not appear after several hours, generate them manually:

sudo /srv/modoboa/env/bin/python /srv/modoboa/instance/manage.py modo manage_dkim_keys

You may see harmless Django model warnings—keys still generate:

amavis.Msgrcpt.mail: (fields.W342) Setting unique=True on a ForeignKey ...
amavis.Quarantine.mail: (fields.W342) Setting unique=True on a ForeignKey ...

DMARC (TXT record)

Start with p=none to collect reports; move to quarantine or reject when confident.

PTR (reverse DNS)

At your VPS panel, set reverse DNS for your IPv4 (and IPv6 if used) to mail.example.com.

Check:

dig -x YOUR.SERVER.IP +short

When PTR is set correctly at your host, you should get your mail hostname:

mail.example.com.

Run Modoboa repair checks

After DNS propagates and you add domains in the admin UI, run:

sudo /srv/modoboa/env/bin/python /srv/modoboa/instance/manage.py modo repair

Typical output flags objects that need an owner or alias—run this after DNS propagates and you add domains in the admin UI:

Checking for... Sometime objects have no owner....
Checking for... Sometime mailboxes have no alias....

Older Modoboa guides mention modo check_mx; that subcommand is not available in Modoboa 2.9.x—use modo repair and dig instead.

Step 7 — Test sending and receiving

Webmail

Log out of the admin account. Log in as your mailbox user at the same URL. Compose a message to an external address (Gmail, etc.) and reply from outside to your new mailbox.

mail-tester.com

1. Visit mail-tester.com.
2. Send an email from your Modoboa account to the address shown.
3. Review score and fix SPF, DKIM, PTR, or content issues reported.

Aim for 8/10 or higher before relying on the server for production mail.

Step 8 — Configure email clients (Thunderbird / Outlook)

Modoboa supports AutoMX for automatic client discovery; manual settings work everywhere.

Microsoft Outlook may require SMTPS on port 465—enable it in Postfix if clients cannot send.

Accept the Let's Encrypt certificate in the client; with self-signed certs you must trust the certificate manually.

Troubleshooting common Modoboa issues on Ubuntu

Greylisting delays inbound mail

Modoboa enables Postfix greylisting by default. Mail may arrive after a few minutes. Log hint:

postfix/postscreen: NOQUEUE: reject: ... 450 4.3.2 Service currently unavailable

To disable, comment out postscreen_* lines at the end of /etc/postfix/main.cf, then:

sudo systemctl restart postfix

Policy daemon not listening (port 9999)

If /var/log/mail.log shows:

warning: connect to 127.0.0.1:9999: Connection refused

Restart supervisor:

sudo systemctl restart supervisor
sudo ss -lnpt | grep 9999

When policyd is running, port 9999 should be listening locally:

LISTEN 0 100 127.0.0.1:9999 0.0.0.0:*

If still down, comment out check_policy_service inet:127.0.0.1:9999 in smtpd_recipient_restrictions inside /etc/postfix/main.cf and restart Postfix.

Web interface 502 or connection refused

sudo systemctl status nginx --no-pager
sudo nginx -t
sudo systemctl restart nginx

A healthy config test looks like:

nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
nginx: configuration file /etc/nginx/nginx.conf test is successful

Check logs: /var/log/nginx/error.log and /var/log/mail.log.

Out of memory (ClamAV / database killed)

On 1 GB RAM, clamav-freshclam or ClamAV may loop or OOM-kill other services. Options:

• Upgrade to 2–3 GB RAM.
• Temporarily stop freshclam during install: sudo systemctl stop clamav-freshclam.
• Tune ClamAV memory limits for small VPS workloads.

Minimum RAM notes from community installs: ~1 GB without ClamAV, ~2 GB with ClamAV.

Installation fails (radicale / partial install)

Some installs failed when /etc/modoboa-radicale was missing. If the installer errors on calendar (Radicale) setup:

sudo mkdir -p /etc/modoboa-radicale

After creating it, ls should show the directory:

drwxr-xr-x 2 root root 4096 ... /etc/modoboa-radicale

Re-run with --debug. If a previous attempt left state behind, use a fresh VM or purge leftover packages (postfix, dovecot, nginx, postgresql, clamav, etc.) before retrying—the installer has no official uninstall command.

Let's Encrypt rate limits or wrong hostname

Ensure mail.example.com resolves publicly before install. After five failed attempts, Let's Encrypt may rate-limit—fix DNS, wait, and re-run certbot or the installer.

Renew TLS certificates

Modoboa installs certbot (often under /opt/certbot-auto). Add a daily cron as root:

sudo crontab -e

@daily /opt/certbot-auto renew -q && systemctl reload nginx postfix dovecot

Adjust the certbot path if yours differs: sudo find / -name '*certbot*' 2>/dev/null.

Port 25 blocked — use an SMTP relay

Configure Postfix to relay through a provider such as SendGrid when outbound 25 is blocked. See SendGrid Postfix integration for relay syntax and Postfix relay restrictions for policy context on this site.

Optional: reverse proxy and TLS offload

Homelab setups sometimes put HAProxy, Caddy, or Nginx in front of Modoboa on a single public IP. That is advanced: you must forward TCP 25, 587, 993, and 443 (or terminate TLS consistently) without breaking SMTP STARTTLS. Document your proxy config separately; the stock installer expects Nginx on the mail host.

Security and maintenance habits

• Change default admin / password immediately.
• Keep Ubuntu updated: sudo apt update && sudo apt upgrade.
• Monitor blacklists and DMARC reports Modoboa can surface.
• Back up /srv/modoboa, Postfix/Dovecot configs, and your database regularly.
• Do not expose unused admin ports; use firewall rules allowing only 22, 25, 80, 443, 587, 993 as needed.

For timezone and system clock accuracy (important for TLS and mail timestamps), see set timezone on Ubuntu.

Summary

Modoboa on Ubuntu is one of the faster paths to a self-hosted mail stack: the installer handles Postfix, Dovecot, Nginx, filtering, and the web UI on Ubuntu 20.04 LTS and newer. On my test host the full install took about 10 minutes; plan 15–25 minutes on a fresh 2 GB VPS where ClamAV and pip have to download from scratch.

Success still depends on the boring parts—DNS (MX, A, PTR, SPF, DKIM, DMARC), a clean server with enough RAM, and outbound port 25 or a relay. After install, confirm the login page returns HTTP 200, change the default admin password, add domains and mailboxes in the admin UI, then test with mail-tester.com before you rely on the server for production mail. If outbound 25 is blocked, relay through SendGrid or SES rather than fighting your VPS provider.

Official references: Modoboa documentation and modoboa-installer on GitHub.
