keytool vs OpenSSL: CSR, PKCS12, Keystore Import & Certificate Inspection

Linux administrators routinely touch both keytool (JDK keystore management) and openssl (PEM, CSR, and live TLS debugging). They overlap on PKCS12 and X.509 certificates but diverge on file formats, network inspection, and where the private key lives during a CA signing workflow.

This guide compares the two tools task by task — CSR generation, inspecting a remote certificate, PEM key handling, PKCS12 creation, Java keystore import, and chain debugging — so you reach for the right binary instead of fighting format conversions.

Tested on: Ubuntu 26.04 LTS; OpenJDK 25.0.3; OpenSSL 3.x; kernel 7.0.0-27-generic.

Quick comparison

Use this table when you know the task but not which binary to open. Both tools speak X.509; the difference is whether the deliverable is a Java keystore or PEM files on disk.

Task	keytool	OpenSSL	Practical pick
Generate CSR from keystore entry	`keytool -certreq -alias NAME`	`openssl req -new -key key.pem`	keytool for Java-first workflows; OpenSSL when you already have PEM keys
Inspect remote TLS certificate	`keytool -printcert -sslserver host:443 -v` for basic certificate view	`openssl s_client -connect host:443 -servername host -showcerts`	OpenSSL for full live TLS debugging; keytool for quick Java-side certificate printing
Work with PEM private key / cert	Export with `-exportcert -rfc`; import with `-importcert`	Native `.pem` / `.crt` / `.key` files	OpenSSL for nginx/Apache; keytool for JVM stores
Create PKCS12 bundle	`-genkeypair` creates PKCS12 directly; `-importkeystore` converts	`openssl pkcs12 -export`	Either; keytool is simpler when starting from Java
Import into Java keystore	`-importcert`, `-importkeystore`, `-genkeypair`	Build PKCS12 with `openssl pkcs12`, then `keytool -list` to verify	keytool for import; OpenSSL to assemble PEM into PKCS12
Debug TLS certificate chain	`keytool -list -v` (local chain length, issuer)	`openssl s_client -showcerts` (live chain from server)	OpenSSL for live handshake; keytool for what the JVM loads

Install keytool with Install keytool on Ubuntu. For broader OpenSSL commands see the OpenSSL cheat sheet.

CSR generation

A certificate signing request (CSR) is what you upload to a CA. The tool you pick depends on where the private key already lives.

keytool: CSR from an existing keystore entry

The private key stays inside the keystore. Generate the key pair first, then export only the CSR file for your CA.

bash


keytool -genkeypair -alias localhost -keyalg RSA -keysize 2048 -validity 365 \
  -storetype PKCS12 -keystore server.p12 -storepass changeit \
  -dname "CN=localhost, O=Demo, C=US" -noprompt

keytool -certreq -alias localhost -keystore server.p12 -storetype PKCS12 -storepass changeit -file localhost.csr
head -3 localhost.csr

text


-----BEGIN NEW CERTIFICATE REQUEST-----
MIICpTCCAY0CAQAwMDELMAkGA1UEBhMCVVMxDTALBgNVBAoTBERlbW8xEjAQBgNV
BAMTCWxvY2FsaG9zdDCCASIwDQYJKoZIhvcNAQEBBQADggEPADCCAQoCggEBAMzt

The PEM header confirms the CSR is valid. After the CA signs the certificate, import the reply with keytool -importcert (see keytool cheat sheet).

OpenSSL: CSR from a PEM private key

OpenSSL keeps the key and CSR as separate files on disk until you bundle them into PKCS12 or copy the signed cert back into Java.

bash


openssl req -new -newkey rsa:2048 -nodes \
  -keyout localhost.key -out localhost.csr \
  -subj "/CN=localhost/O=Demo/C=US"

head -3 localhost.csr

text


-----BEGIN CERTIFICATE REQUEST-----
MIICdTCCAV0CAQAwMDESMBAGA1UEAwwJbG9jYWxob3N0MQ0wCwYDVQQKDAREZW1v
MQswCQYDVQQGEwJVUzCCASIwDQYJKoZIhvcNAQEBBQADggEPADCCAQoCggEBAK/t

Use OpenSSL when your CA portal expects PEM uploads or when nginx already has a .key file. Use keytool when Tomcat or Spring Boot will read a PKCS12 keystore and you want one fewer file to protect on disk.

Inspect a remote certificate

keytool can print a remote server certificate with -printcert -sslserver, but OpenSSL is more useful when you need handshake details, SNI behavior, verification errors, and the exact chain presented by the server.

Quick Java-side view of the leaf certificate:

bash

keytool -printcert -sslserver www.google.com:443

text


Certificate #0
====================================
Owner: CN=www.google.com
Issuer: CN=WE2, O=Google Trust Services, C=US
Serial number: 21698f5855a36d521249e4fffa486457
Valid from: Mon Jun 15 14:11:54 IST 2026 until: Mon Sep 07 14:11:53 IST 2026

For full TLS debugging, pipe s_client into openssl x509:

bash


echo | openssl s_client -connect www.google.com:443 -servername www.google.com 2>/dev/null \
  | openssl x509 -noout -subject -issuer -dates -fingerprint -sha256

The exact issuer, dates, and fingerprint change as the site rotates certificates; treat this as sample output:

text


subject=CN=www.google.com
issuer=C=US, O=Google Trust Services, CN=WE2
notBefore=Jun 15 08:41:54 2026 GMT
notAfter=Sep  7 08:41:53 2026 GMT
sha256 Fingerprint=07:AA:5B:E9:3B:FB:D2:D7:05:3B:EC:90:1F:4B:19:96:1D:ED:BE:69:3C:86:C7:01:DE:A3:AC:3C:75:A1:BE:92

The fingerprint is what you compare against a cert stored in a keystore. Add -showcerts on the s_client side to dump the full chain the server sends. Compare the leaf fingerprint to what you have locally with keytool -list -v (see list and inspect keystore entries).

PEM key and certificate handling

PEM is the lingua franca on Linux web servers. Java stores prefer PKCS12 or JKS, but keytool can import and export PEM when you bridge the two worlds.

Need	OpenSSL	keytool
Generate RSA key + self-signed cert as PEM	`openssl req -x509 -newkey rsa:2048 -nodes ...`	`keytool -genkeypair`, then `keytool -exportcert -rfc`
View a PEM certificate	`openssl x509 -in cert.pem -noout -text`	`keytool -printcert -file cert.pem`
Verify key matches cert	Compare public-key hashes: `openssl x509 -in cert.pem -pubkey -noout \| openssl sha256` and `openssl pkey -in key.pem -pubout \| openssl sha256`	Export the keystore cert first with `keytool -exportcert -rfc`, then compare the public-key hash with OpenSSL
Convert PEM cert into truststore	Not the right tool for Java truststore import	`keytool -importcert -alias ca -file ca.pem -keystore trust.p12 -storetype PKCS12`

To confirm a keystore entry round-trips to PEM, export the cert and parse it with OpenSSL:

bash

keytool -exportcert -alias localhost -keystore server.p12 -storetype PKCS12 -storepass changeit -rfc -file localhost.pem
openssl x509 -in localhost.pem -noout -subject

text

subject=C=US, O=Demo, CN=localhost

OpenSSL owns day-to-day PEM file workflows on Linux. keytool bridges PEM files into Java keystores and truststores.

PKCS12 creation

PKCS12 (.p12) is the format Tomcat, Spring Boot, and modern keytool default to. You can create it natively in Java or assemble it from PEM with OpenSSL.

keytool: PKCS12 from the start

Modern JDK defaults to PKCS12. A single command creates the store with the private key inside — no loose .key file on disk:

bash


keytool -genkeypair -alias server -keyalg RSA -keysize 2048 -validity 365 \
  -storetype PKCS12 -keystore server.p12 -storepass changeit \
  -dname "CN=server.example.com, O=Demo, C=US" -noprompt

keytool -list -keystore server.p12 -storetype PKCS12 -storepass changeit

text

Keystore type: PKCS12

Your keystore contains 1 entry

server, Jul 2, 2026, PrivateKeyEntry,

The PrivateKeyEntry line means Spring Boot or Tomcat can load this file directly as a server keystore.

OpenSSL: PKCS12 from PEM key and certificate

When your CA delivered separate .crt and .key files (typical for nginx), bundle them for Java:

bash

openssl pkcs12 -export -inkey localhost.key -in signed.crt \
  -out bundle.p12 -name localhost -passout pass:changeit

keytool -list -keystore bundle.p12 -storetype PKCS12 -storepass changeit

text

Keystore type: PKCS12

Your keystore contains 1 entry

localhost, Jul 2, 2026, PrivateKeyEntry,

The certificate and private key must be a matching pair — OpenSSL rejects mismatched modulus. If keytool -list fails with keystore password was incorrect, check -passout matches the password you pass to Java.

To migrate legacy JKS files, convert in place with importkeystore:

bash

keytool -importkeystore -srckeystore old.jks -destkeystore new.p12 \
  -deststoretype PKCS12 -srcstorepass changeit -deststorepass changeit -noprompt

keytool -list -keystore new.p12 -storetype PKCS12 -storepass changeit | head -5

text

Keystore type: PKCS12

Your keystore contains 1 entry

myalias, Jul 2, 2026, PrivateKeyEntry,

Alias names and entry types carry over from the source JKS.

See also Create PKCS12 from CRT and KEY for an OpenSSL-focused walkthrough.

Java keystore import

Once you have PEM or PKCS12 material from OpenSSL or a CA portal, keytool is the native tool for populating Java keystores and truststores. OpenSSL does not understand JKS alias namespaces.

Operation	Command
Import CA / peer cert (truststore)	`keytool -importcert -alias ca -file ca.pem -keystore trust.p12 -storetype PKCS12 -storepass PASS -noprompt`
Import signed server cert reply	`keytool -importcert -alias localhost -file signed.crt -keystore server.p12 -storetype PKCS12 -storepass PASS`
Import PKCS12 from OpenSSL	Use the `.p12` directly, or copy entries with `keytool -importkeystore`
Convert JKS → PKCS12	`keytool -importkeystore -srckeystore old.jks -destkeystore new.p12 -deststoretype PKCS12 ...`

A quick truststore import from a PEM CA file looks like this:

bash


keytool -importcert -alias lab-ca -file ca.pem \
  -keystore trust.p12 -storetype PKCS12 -storepass changeit -noprompt
keytool -list -keystore trust.p12 -storetype PKCS12 -storepass changeit

text

Keystore type: PKCS12

Your keystore contains 1 entry

lab-ca, Jul 2, 2026, trustedCertEntry,

trustedCertEntry means the JVM will trust TLS servers that chain to this CA. OpenSSL produces the PEM; keytool owns the Java-side import, alias rename (change alias guide), and optional merge into cacerts.

Chain debugging

Chain problems show up as handshake failures on the wire or as PKIX path building failed inside Java. Use OpenSSL against the live host first, then keytool against the file your JVM loads.

OpenSSL: live handshake and chain presentation

Point s_client at the hostname clients use (SNI matters on shared IPs):

bash

echo | openssl s_client -connect www.google.com:443 -servername www.google.com -showcerts 2>&1 | tail -8

text


---
No client certificate CA names sent
Peer signing digest: SHA256
Peer signature type: ECDSA
Server Temp Key: X25519, 253 bits
---
SSL handshake has read 3801 bytes and written 1620 bytes
Verification: OK
Verify return code: 0 (ok)

Verify return code: 0 (ok) means OpenSSL built a trusted path with its default CA bundle. Non-zero codes such as unable to get local issuer certificate or self-signed certificate in certificate chain tell you the server omitted an intermediate or the client trust store is incomplete.

keytool: what the JVM will load locally

List the keystore your app actually reads — not what you think is on disk:

bash

keytool -list -v -keystore server.p12 -storetype PKCS12 -storepass changeit 2>&1 | grep -E 'Alias name:|Entry type:|Certificate chain length:'

text


Alias name: https
Entry type: PrivateKeyEntry
Certificate chain length: 2

Certificate chain length: 1 on a production server often means intermediate CA certificates are missing from the keystore. Import intermediates as trustedCertEntry before the signed server reply, or include them in the CA bundle you import.

Combine both tools: use s_client to capture what the remote host presents, then fix your local store with keytool -importcert until keytool -list -v shows the full chain. For PKIX errors in Java clients see keystore vs truststore.

When to use which tool

Pick keytool when the runtime is Java and the artifact is a keystore or truststore file:

Tomcat, Jetty, Spring Boot, or a custom JSSE app reads a .p12 or .jks file
You manage keystore vs truststore roles inside the JVM
You want the private key generated inside the store without a loose PEM on disk

Pick OpenSSL when the runtime is PEM-centric or you need wire-level TLS debugging:

nginx, Apache, HAProxy, or system services expect PEM files
You need to inspect a remote TLS endpoint (s_client)
You operate a private CA with openssl ca or need CRL/OCSP tooling
You debug handshake or chain issues against a live host

Many teams use OpenSSL through the CA signing step, then openssl pkcs12 -export or keytool -importkeystore for the Java deployment artifact.

References

Summary

keytool and OpenSSL both handle X.509 certificates and PKCS12, but they optimize for different runtimes. Use keytool for Java keystore lifecycle (generate, CSR, import, list, alias management). Use OpenSSL for PEM workflows, live remote inspection with s_client, and TLS chain debugging on the wire. keytool -printcert -sslserver can print certificates from a remote TLS server, but OpenSSL remains the better tool for handshake and chain diagnostics.

Frequently Asked Questions

1. Should I use keytool or OpenSSL for Java TLS?

Use keytool when the deliverable is a Java keystore or truststore (PKCS12/JKS) consumed by Tomcat, Spring Boot, or JSSE. Use OpenSSL for PEM-centric Linux services (nginx, Apache, HAProxy), OpenSSH, and inspecting live remote certificates with s_client. Many teams use both: OpenSSL for CA and PEM operations, keytool for the final keystore import.

2. Can OpenSSL create a Java keystore?

OpenSSL creates PKCS12 files with openssl pkcs12 -export, which Java accepts as a keystore. keytool -importkeystore can also convert between formats. For native Java workflows (genkeypair, certreq, importcert) keytool keeps the private key inside the store from the start without a separate PEM step.

3. How do I inspect a remote TLS certificate — keytool or OpenSSL?

Use OpenSSL for full live TLS inspection. Run echo | openssl s_client -connect host:443 -servername host 2>/dev/null | openssl x509 -noout -text. keytool can print a remote server certificate with keytool -printcert -sslserver host:443 -v, but openssl s_client gives richer handshake diagnostics, explicit SNI with -servername, full chain output with -showcerts, and verify return codes.

4. Which tool is better for debugging certificate chains?

OpenSSL s_client shows the chain the server presents and verification errors in real time. keytool -list -v shows what is stored locally (chain length, issuer, fingerprints). Use s_client to debug handshake failures against a live host, then keytool -list -v to confirm what your JVM will actually load.

5. Can I generate a CSR with both keytool and OpenSSL?

Yes. keytool -certreq exports a CSR from an existing keystore entry. openssl req -new creates a CSR from a PEM private key. CAs accept either format. With keytool the private key never leaves the keystore; with OpenSSL you manage separate .key and .csr files until you build PKCS12 or import into Java.
