How to Extract a Private Key from PFX with OpenSSL

You exported a .pfx or .p12 file from Windows IIS, Azure, or a vendor portal and now Linux wants separate PEM files—a private key and a certificate nginx or Apache can load. OpenSSL’s pkcs12 subcommand unpacks PKCS#12 bundles: one import password unlocks the PFX, then you split out the key, leaf certificate, and CA chain.

This guide covers every common extraction path: private key with password, unencrypted key for nginx (-nodes), PFX files that use an empty import password, certificate and chain only, legacy Windows PFX that need -legacy, and how to verify the key matches the cert. I ran the commands on Ubuntu 25.04 with OpenSSL 3.4.1 using a test PFX built from a local certificate. For creating PFX files from scratch, see Generate a self-signed certificate.

Tested on: Ubuntu 25.04 (Plucky Puffin); kernel 6.14.0-37-generic; OpenSSL 3.4.1.

Quick answer: extract private key from PFX

Replace cert.pfx and the password with your file and export password:

openssl pkcs12 -in cert.pfx -passin pass:YOUR_PFX_PASSWORD \
  -nocerts -nodes -out private.key

• -passin — password that protects the PFX file (the export/import password)
• -nocerts — extract only the private key, not certificates
• -nodes — write an unencrypted PEM key (required for nginx/Apache auto-reload)

Confirm the key is valid:

openssl rsa -in private.key -noout -check

RSA key ok

The PEM file should contain -----BEGIN PRIVATE KEY----- (or BEGIN RSA PRIVATE KEY). A few lines of Bag Attributes above that header are normal and nginx ignores them.

PFX, P12, and PKCS#12 — same format

One PFX file can hold the end-entity certificate, intermediate CAs, and the matching private key. The PFX password (export password) encrypts the whole bundle—it is not the same as a passphrase on an extracted .key unless you choose to encrypt the output.

Inspect what is inside without extracting:

openssl pkcs12 -in cert.pfx -passin pass:YOUR_PFX_PASSWORD -info -noout

MAC: sha256, Iteration 2048
MAC length: 32, salt length: 8
PKCS7 Encrypted data: PBES2, PBKDF2, AES-256-CBC, Iteration 2048, PRF hmacWithSHA256
Certificate bag
Certificate bag
PKCS7 Data
Shrouded Keybag: PBES2, PBKDF2, AES-256-CBC, Iteration 2048, PRF hmacWithSHA256

Two certificate bags usually mean leaf plus CA/intermediate; Shrouded Keybag confirms a private key is present.

Extract private key with PFX password

Unencrypted key for nginx or Apache (most common)

openssl pkcs12 -in server.pfx -passin pass:ExportPass123 \
  -nocerts -nodes -out server.key
chmod 600 server.key

OpenSSL 3.x accepts -noenc as an alias for -nodes on extract.

Encrypted output key (keep passphrase on the PEM)

Omit -nodes. OpenSSL prompts twice for a new password that encrypts server.key:

openssl pkcs12 -in server.pfx -passin pass:ExportPass123 \
  -nocerts -out server-encrypted.key

Or set the output password on the command line:

openssl pkcs12 -in server.pfx -passin pass:ExportPass123 \
  -nocerts -passout pass:KeyPass456 -out server-encrypted.key

Decrypt later for nginx:

openssl rsa -in server-encrypted.key -passin pass:KeyPass456 -out server.key

Pass PFX password without shell history

read -s PFXPASS
openssl pkcs12 -in server.pfx -passin env:PFXPASS -nocerts -nodes -out server.key
unset PFXPASS

From a file (restrict permissions):

chmod 600 pfx.pass
openssl pkcs12 -in server.pfx -passin file:pfx.pass -nocerts -nodes -out server.key
shred -u pfx.pass

Extract private key when the PFX has no password

Some lab exports or internal tools create a PFX with an empty import password. Use -passin pass: (nothing after the colon):

openssl pkcs12 -in nopass.pfx -passin pass: -nocerts -nodes -out private.key

If OpenSSL still fails, the file is not passwordless—try the export password from the team that generated the PFX.

Extract certificate and CA chain (not the key)

Leaf / entity certificate only (-clcerts):

openssl pkcs12 -in server.pfx -passin pass:ExportPass123 \
  -clcerts -nokeys -out server.crt

subject=CN=nginx.example.test

CA / intermediate certificates (-cacerts):

openssl pkcs12 -in server.pfx -passin pass:ExportPass123 \
  -cacerts -nokeys -out ca-chain.crt

Full chain for nginx (leaf first, then intermediates):

cat server.crt ca-chain.crt > fullchain.crt

nginx example:

ssl_certificate     /etc/nginx/ssl/fullchain.crt;
ssl_certificate_key /etc/nginx/ssl/server.key;

See Install SSL certificate on Nginx for the full server block.

Extract everything into one PEM file

When you want a single file with key and certs (some tools accept combined PEM):

openssl pkcs12 -in server.pfx -passin pass:ExportPass123 \
  -nodes -out bundle.pem

The file contains multiple BEGIN blocks (key plus one or more certificates). Split later with an editor, or use the separate -nocerts / -nokeys commands above for cleaner nginx layout.

Windows PFX on Linux: -legacy

Older Windows exports sometimes use RC2 or legacy 3DES inside the PFX. OpenSSL 3.x defaults to modern ciphers; if you see errors like unsupported or digital envelope routines, add -legacy:

openssl pkcs12 -in legacy.pfx -passin pass:Legacy123 -legacy \
  -nocerts -nodes -out private.key

The same flag works when creating PFX files for older Windows tools:

openssl pkcs12 -export -in cert.crt -inkey private.key -out legacy.pfx \
  -passout pass:Legacy123 -legacy

Verify key matches certificate

After extraction, confirm the private key belongs to the certificate before you reload a web server:

openssl x509 -noout -modulus -in server.crt | openssl md5
openssl rsa  -noout -modulus -in server.key  | openssl md5

Matching MD5(stdin)= lines mean the pair is correct. For full cert details, see View certificate with OpenSSL.

Test TLS once nginx is configured:

openssl s_client -connect your.host.name:443 -servername your.host.name </dev/null 2>/dev/null | \
  openssl x509 -noout -subject -dates

End-to-end script for nginx

Adjust paths and password handling for production (avoid pass: in scripts when possible):

PFX=server.pfx
PFXPASS='ExportPass123'

openssl pkcs12 -in "$PFX" -passin pass:"$PFXPASS" -nocerts -nodes -out server.key
openssl pkcs12 -in "$PFX" -passin pass:"$PFXPASS" -clcerts -nokeys -out server.crt
openssl pkcs12 -in "$PFX" -passin pass:"$PFXPASS" -cacerts -nokeys -out chain.crt
cat server.crt chain.crt > fullchain.crt
chmod 600 server.key

Move files to /etc/nginx/ssl/ or your distro layout, then nginx -t && systemctl reload nginx.

Troubleshooting

Wrong password example from a failed run:

Mac verify error: invalid password?

Security notes

• The PFX password protects the bundle at rest; -nodes output is plaintext—restrict with filesystem permissions and avoid committing keys to git.
• Delete temporary PFX copies on shared servers after extraction.
• Prefer extracting on the target Linux host rather than emailing PFX files.
• Public websites should use CA-issued certificates, not long-lived self-signed material from a PFX lab export.

References

• openssl-pkcs12 manual
• Generate self-signed certificate (create a PFX)
• View certificate with OpenSSL
• Install SSL certificate on Nginx
• OpenSSL config and paths
• OpenSSL tutorial hub

Summary

Use openssl pkcs12 -in cert.pfx -passin pass:PFX_PASSWORD -nocerts -nodes -out private.key to extract an unencrypted private key for nginx or Apache. The -passin value is always the PFX import password; -nodes controls whether the output key is encrypted. Split certificates with -clcerts -nokeys for the leaf and -cacerts -nokeys for the chain, then concatenate for ssl_certificate. For passwordless PFX files, use -passin pass:. Old Windows exports may need -legacy on OpenSSL 3.x. Verify with openssl rsa -check and matching modulus MD5 hashes before you reload a web server.
