How to make circular color gradient in Python? [SOLVED]


Written by - Deepak Prasad

Different methods to create circular color gradient in Python

A color gradient is a way to smoothly transition between two or more colors. A circular gradient is a type of color gradient that transitions in a circular pattern, typically starting with one color at the center and gradually transitioning to other colors as you move outward.

There are several ways to create a circular color gradient in Python, some of the most common methods include:

  1. Using the matplotlib.colors.LinearSegmentedColormap class: This is a method that I explained in my previous answer, it uses a list of colors to create a colormap and numpy to calculate the distance from the center of the grid to each point in the grid. This distance is then used as the input for the colormap.
  2. Using the matplotlib.colors.ListedColormap class: This method uses a discrete set of colors to create the gradient, it could be useful when you have a fixed number of colors.
  3. Using a polar coordinate system and a color map: This method uses a polar coordinate system to create the circular gradient, and a color map to map the values of the coordinates to colors.
  4. Using the PIL library: You can use the ImageDraw.pieslice() method of the PIL library to create a circular gradient by filling a pie-shaped area with a gradient.



Pre-requisite - Install matplotlib module

We are going to be using matplotlib module in most of our examples but it is not part of Python's built-in default library and hence must be installed separately. I am using Python3.9 in my environment so I will use pip3 to install this module:

# pip3 install matplotlib
Collecting matplotlib
  Downloading matplotlib-3.6.3-cp39-cp39-manylinux_2_17_x86_64.manylinux2014_x86_64.whl (11.8 MB)
     |████████████████████████████████| 11.8 MB 7.3 MB/s
Collecting contourpy>=1.0.1
  Downloading contourpy-1.0.7-cp39-cp39-manylinux_2_17_x86_64.manylinux2014_x86_64.whl (299 kB)
     |████████████████████████████████| 299 kB 4.6 MB/s
Collecting pillow>=6.2.0
  Downloading Pillow-9.4.0-cp39-cp39-manylinux_2_28_x86_64.whl (3.4 MB)
     |████████████████████████████████| 3.4 MB 3.9 MB/s
Collecting kiwisolver>=1.0.1
  Downloading kiwisolver-1.4.4-cp39-cp39-manylinux_2_12_x86_64.manylinux2010_x86_64.whl (1.6 MB)
     |████████████████████████████████| 1.6 MB 2.5 MB/s
Requirement already satisfied: pyparsing>=2.2.1 in /usr/local/lib/python3.9/site-packages (from matplotlib) (2.4.7)
Collecting packaging>=20.0
  Downloading packaging-23.0-py3-none-any.whl (42 kB)
     |████████████████████████████████| 42 kB 469 kB/s
Requirement already satisfied: python-dateutil>=2.7 in /usr/lib/python3.9/site-packages (from matplotlib) (2.8.1)
Requirement already satisfied: numpy>=1.19 in /usr/local/lib64/python3.9/site-packages (from matplotlib) (1.24.1)
Collecting fonttools>=4.22.0
  Downloading fonttools-4.38.0-py3-none-any.whl (965 kB)
     |████████████████████████████████| 965 kB 2.2 MB/s
Collecting cycler>=0.10
  Downloading cycler-0.11.0-py3-none-any.whl (6.4 kB)
Requirement already satisfied: six>=1.5 in /usr/lib/python3.9/site-packages (from python-dateutil>=2.7->matplotlib) (1.15.0)
Installing collected packages: pillow, packaging, kiwisolver, fonttools, cycler, contourpy, matplotlib
Successfully installed contourpy-1.0.7 cycler-0.11.0 fonttools-4.38.0 kiwisolver-1.4.4 matplotlib-3.6.3 packaging-23.0 pillow-9.4.0



Example-1: Using matplotlib.colors.LinearSegmentedColormap class

Here is an example of how to create a circular color gradient using the matplotlib.colors.LinearSegmentedColormap class:

import numpy as np
import matplotlib.pyplot as plt
from matplotlib.colors import LinearSegmentedColormap

# define color map
colors = [(1, 0, 0), (1, 1, 0), (0, 1, 0), (0, 1, 1), (0, 0, 1), (1, 0, 1), (1, 0, 0)]
cmap = LinearSegmentedColormap.from_list("my_cmap", colors)

# create color map
X, Y = np.meshgrid(np.linspace(-1,1,100), np.linspace(-1,1,100))
R = np.sqrt(X**2 + Y**2)

# plot color map
plt.figure(figsize=(5,5))
plt.pcolormesh(X, Y, R, cmap=cmap)
plt.axis("equal")
plt.show()
print("Circular gradient created")

In this example, the colors list defines a sequence of RGB tuples that represent the colors in the gradient. The LinearSegmentedColormap.from_list() method is used to create a colormap from this list of colors.

The numpy function meshgrid is used to create a grid of coordinates, and the numpy function sqrt is used to calculate the distance from the center of the grid to each point in the grid. This distance is then used as the input for the colormap.

Finally, the plt.pcolormesh method is used to plot the color map, and the plt.axis method is used to make sure that the aspect ratio of the plot is equal.

This code will create a circular color gradient with the defined colors, if you want to change the colors, you can change the colors tuple. And you can adjust the size of the plot by changing the figsize parameter in plt.figure().

Output:

How to make circular color gradient in Python? [SOLVED]



Example-2: Using matplotlib.colors.ListedColormap class

Here is an example of how to create a circular color gradient using the matplotlib.colors.ListedColormap class:

import matplotlib.colors as mcolors
import matplotlib.pyplot as plt
import numpy as np

# Define the color map
colors = [(1, 0, 0), (1, 1, 0), (0, 1, 0), (0, 1, 1), (0, 0, 1), (1, 0, 1), (1, 0, 0)]
cmap = mcolors.LinearSegmentedColormap.from_list("my_cmap", colors)

# Create a polar grid
r = np.linspace(0, 1, 100)
theta = np.linspace(0, 2*np.pi, 100)
R, Theta = np.meshgrid(r, theta)

# Calculate the distance from the center of the grid to each point
distance = np.sqrt((R - 0.5)**2 + (Theta - np.pi)**2)

# Plot the color map
plt.figure(figsize=(5,5))
plt.pcolormesh(Theta, R, distance, cmap=cmap)
plt.axis("equal")
plt.show()

Here we define colors list, which contains a sequence of RGB tuples that represent the colors in the gradient. The LinearSegmentedColormap.from_list() method is used to create a colormap from this list of colors.

Then, numpy functions linspace and meshgrid are used to create a polar grid of coordinates. The coordinates are given by the polar angle theta and the distance from the origin r.

Then, using these polar coordinates, the distance between each point in the grid and the center of the grid is calculated using the numpy.sqrt((R - 0.5)**2 + (Theta - np.pi)**2) expression. This distance is used as the input for the colormap.

Finally, the plt.pcolormesh method is used to plot the color map, and the plt.axis method is used to make sure that the aspect ratio of the plot is equal.

This will create a circular color gradient in a polar coordinate system. You can adjust the number of points in the grid by changing the parameters of the linspace function, and you can change the colors by modifying the colors list.

Output:

How to make circular color gradient in Python? [SOLVED]



Example-3: Using ImageDraw.pieslice() method

Here is an example of how to create a circular color gradient using the ImageDraw.pieslice() method of the PIL library:

from PIL import Image, ImageDraw

# Create an image
im = Image.new("RGB", (200,200), "white")

# Create a draw object
draw = ImageDraw.Draw(im)

# Define the color stops
color_stops = [(0, (255, 0, 0)), (0.5, (0, 255, 0)), (1, (0, 0, 255))]

# Draw the pie slice
for i, color_stop in enumerate(color_stops):
    if i == 0:
        start = 0
    else:
        start = color_stops[i-1][0]
    end = color_stop[0]
    draw.pieslice([50, 50, 150, 150], start*360, end*360, fill=color_stop[1])

# Show the image
im.show()
print("Circular gradient created")

In this example, an image of size 200x200 is created using the Image.new() method. Then, a draw object is created using the ImageDraw.Draw() method.

Then, I define the color stops, a list of tuples where each tuple represents a color and a position in the gradient (from 0 to 1), this is similar to the css linear gradient.

Then, the ImageDraw.pieslice() method is used to draw a pie-shaped area with a gradient, it takes four parameters that define the bounding box of the pie slice, and two angles that define the start and end of the slice in degrees. The fill parameter is used to specify the color of the slice. The method is called multiple times to draw the different slices, each slice representing a color stop.

Finally, im.show() is used to display the image.

This will create a circular color gradient with the defined color stops. You can adjust the size of the image by changing the parameters of the Image.new() method and you can adjust the position and colors of the color stops by modifying the color_stops list.

Output:

How to make circular color gradient in Python? [SOLVED]



Summary

Matplotlib is a multiplatform data visualization library built on NumPy arrays, and designed to work with the broader SciPy stack. We used the matplotlib.colors.LinearSegmentedColormap class to create a colormap from a list of colors and numpy to create a grid of coordinates, and the numpy function sqrt is used to calculate the distance from the center of the grid to each point in the grid.

The matplotlib.colors.CircularSegmentedColormap class is similar to the LinearSegmentedColormap, but it uses polar coordinates instead of cartesian coordinates to create the color gradient.



References

matplotlib.colors.LinearSegmentedColormap
matplotlib.colors.LinearSegmentedColormap
Plot circular gradients using numpy
