Configure OpenLDAP Indexes with olcDbIndex

OpenLDAP indexes allow the MDB backend to reduce the number of candidate entries examined during LDAP searches. Without the right index for a filter, slapd may walk far more of the database than necessary, which shows up as slow SSSD lookups, sluggish sudo rule retrieval, slow Apache LDAP authentication, and repeated mdb_equality_candidates messages in the server log.

This guide explains how to:

• map LDAP filters to the correct index types
• inspect existing olcDbIndex values on the live server
• identify repeated unindexed searches in logs
• add or modify indexes through cn=config
• monitor online index generation
• rebuild indexes offline with slapindex
• measure search speed, write overhead, and database growth
• apply index-cost trade-offs when choosing new indexes

The procedure applies to OpenLDAP 2.6 across the RHEL family: Red Hat Enterprise Linux, Rocky Linux, AlmaLinux, Oracle Linux, and CentOS Stream.

Tested on: Rocky Linux 10.2; OpenLDAP 2.6.10 from EPEL on ldap-server.example.com.

Complete these lessons first:

• Install and Configure OpenLDAP on the RHEL Family
• Secure OpenLDAP with TLS
• OpenLDAP cn=config and MDB explained
• Manage OpenLDAP users and groups
• OpenLDAP client authentication with SSSD
• OpenLDAP backup and restore

This article owns filter analysis, index-type choice, olcDbIndex changes, online indexing, slapindex, and performance measurement. General MDB sizing and safe cn=config editing stay in OpenLDAP cn=config and MDB. SSSD identity settings, sudo LDAP provider searches, and autofs map lookups are covered in the SSSD client guide and the dedicated sudo and NFS follow-on lessons.

Prerequisites and lab environment

The lab server in this walkthrough uses:

The timing examples use the sssd-reader service account over StartTLS, matching the SSSD client guide. The reader password must satisfy your directory password policy (15 characters on this lab) and pwdReset must be cleared or LDAP searches return Error 50 even when the bind succeeds.

Create ou=people, the jdoe POSIX account, and group membership through Manage OpenLDAP users and groups if they are not already present. Confirm the reader account can bind and search the people and groups subtrees:

ldapwhoami -x -ZZ -H ldap://ldap-server.example.com -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -W

Sample output:

dn:uid=sssd-reader,ou=service-accounts,dc=example,dc=com

Verify the user and group filters used later in the timing section:

ldapsearch -x -ZZ -H ldap://ldap-server.example.com -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -W -b "ou=people,dc=example,dc=com" -LLL "(uid=jdoe)" dn uid uidNumber

Sample output:

dn: uid=jdoe,ou=people,dc=example,dc=com
uid: jdoe
uidNumber: 10001

If the bind works but searches return Error 50, clear pwdReset on the reader account or complete the password change required by ppolicy.

Use this table as the initial filter-to-index decision guide:

Understand OpenLDAP index types

OpenLDAP stores the index configuration for each MDB database in the multi-valued olcDbIndex attribute under cn=config. The syntax is:

olcDbIndex: ATTRIBUTE INDEX_TYPE

A single line can list several attributes that share the same index types:

olcDbIndex: objectClass eq
olcDbIndex: uid,uidNumber,gidNumber eq
olcDbIndex: cn,sn eq,sub

The index types map to LDAP filter forms:

Most administrators only need eq, pres, sub, and occasionally approx. The advanced nosubtypes and nolang options control whether an index also applies to attribute subtypes; you can normally leave them unset.

Keep these rules in mind when you plan indexes:

• Indexes correspond to attributes used in the search filter, not attributes you only return in the result.
• Not every attribute supports every index type; the schema matching rules must allow the operation.
• OpenLDAP has no separate inequality-index keyword for filters such as (uidNumber>=1000). Depending on the attribute and its matching rules, some ordering filters may still use the equality index.
• An index on a superior attribute type also applies to its subtypes by default unless nosubtypes is configured.
• olcDbIndex: uid,mail eq creates separate indexes for uid and mail; it is not an SQL-style composite index.

Upstream OpenLDAP maintains no indexes by default. Distribution packages or existing configurations may already define indexes, so always inspect olcDbIndex before adding new values. The upstream default is no indexes, although OpenLDAP strongly recommends at least objectClass eq.

Avoid unnecessary indexes

Every index costs disk space and write-time maintenance. This is the main place to weigh those trade-offs before you add presence or substring indexes.

Presence indexes help when the attribute is uncommon and presence searches are frequent. Substring indexes belong on attributes that applications genuinely search with wildcards—not on every descriptive text field in the schema.

Identify filters used by your applications

Start by checking how your clients actually search the directory. Identify the filter and base DN used by SSSD, sudo, autofs, applications, or administrative tools.

Treat these as examples, not a ready-made index list. Your final indexes should match the filters that your clients send regularly. Use the dedicated SSSD, sudo, and autofs guides for provider settings, then return here to index the filters those clients actually send.

Detect unindexed equality searches

First inspect the current logs. OpenLDAP's stats log level normally records mdb_equality_candidates messages when an equality filter has no usable index. OpenLDAP 2.6 may report (attribute) not indexed, while older versions or log formats may show index_param failed (18). A more verbose trace level is not usually required. Check olcLogLevel and increase logging temporarily only when the relevant search filters are not visible:

sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=config -s base olcLogLevel

When stats is active, grep the journal for MDB candidate warnings after the filter runs:

sudo journalctl -u slapd --since "10 min ago" --no-pager | grep mdb_equality_candidates

Sample output when memberUid has no equality index on OpenLDAP 2.6.10:

<= mdb_equality_candidates: (memberUid) not indexed

The attribute name in parentheses is the one that lacked a usable equality index. A rare administrative query may not justify a new index; steady production traffic does.

Increase logging only when those messages do not appear and you still need evidence of unindexed traffic. Restore your normal olcLogLevel when the investigation is complete.

Inspect the current olcDbIndex configuration

Discover the MDB database by suffix instead of hard-coding a numbered DN such as olcDatabase={2}mdb,cn=config. Store the result in a shell variable:

MDB_DN=$(sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=config '(&(objectClass=olcMdbConfig)(olcSuffix=dc=example,dc=com))' dn | awk '/^dn: / {sub(/^dn: /, ""); print; exit}')

If the suffix does not exist on this host, stop before changing indexes:

if [[ -z "$MDB_DN" ]]; then
    echo "MDB database for dc=example,dc=com was not found." >&2
    exit 1
fi

Print the discovered DN so your LDIF targets the correct database entry:

printf 'MDB database DN: %s\n' "$MDB_DN"

Sample output:

MDB database DN: olcDatabase={2}mdb,cn=config

Query the database path, suffix, and current index rules:

sudo ldapsearch -Q -LLL -o ldif-wrap=no -Y EXTERNAL -H ldapi:/// -b "$MDB_DN" -s base olcSuffix olcDbDirectory olcDbIndex

Sample output:

dn: olcDatabase={2}mdb,cn=config
olcDbDirectory: /var/lib/ldap
olcSuffix: dc=example,dc=com
olcDbIndex: objectClass eq,pres
olcDbIndex: ou,cn,mail,surname,givenname eq,pres,sub

This is the existing lab configuration, not the recommended baseline. In particular, objectClass pres and broad pres,sub indexing should be reviewed against actual production filters.

The numbered {2} prefix is assigned at creation time on this server. Another host may use a different number even when the suffix is identical.

Plan the OpenLDAP index set

Start with a conservative RFC2307 baseline when those filters are confirmed in your environment:

olcDbIndex: objectClass eq
olcDbIndex: uid,uidNumber,gidNumber eq
olcDbIndex: memberUid eq

Add feature-specific indexes only when the feature exists and you have verified the filter:

• POSIX / RFC2307 clients: member, mail
• sudo rules: sudoUser, sudoHost
• autofs maps: automountMapName, automountKey
• syncrepl replication: entryUUID, entryCSN

Example olcDbIndex lines:

olcDbIndex: member eq
olcDbIndex: mail eq
olcDbIndex: sudoUser,sudoHost eq
olcDbIndex: automountMapName,automountKey eq
olcDbIndex: entryUUID eq
olcDbIndex: entryCSN eq

Add entryUUID and entryCSN only when the database participates in syncrepl replication; they are not part of the basic RFC2307-only baseline.

Add name substring indexes only when applications use wildcard name searches:

olcDbIndex: cn,sn eq,sub

Use a short review table before you apply changes:

Do not normally index userPassword, homeDirectory, loginShell, or description unless the attribute appears frequently in a search filter. Apply the index-cost trade-offs discussed earlier before you add presence or substring indexes to descriptive attributes.

Add or modify olcDbIndex online

Back up cn=config and the suffix data before you change indexes. The OpenLDAP backup and restore guide covers full retention policy; here is the minimum snapshot before index work:

sudo install -d -m 0700 /root/openldap-index-backup

Export the configuration database:

sudo slapcat -F /etc/openldap/slapd.d -n 0 -l /root/openldap-index-backup/cn-config-before-index.ldif

Export the application suffix:

sudo slapcat -F /etc/openldap/slapd.d -b "dc=example,dc=com" -l /root/openldap-index-backup/example-com-before-index.ldif

Both commands exit silently on success when slapd is running and the paths are correct.

Add new index values

Create add-openldap-indexes.ldif with the discovered $MDB_DN:

sudo tee /root/openldap-index-backup/add-openldap-indexes.ldif >/dev/null <<EOF
dn: $MDB_DN
changetype: modify
add: olcDbIndex
olcDbIndex: uid,uidNumber,gidNumber eq
-
add: olcDbIndex
olcDbIndex: memberUid eq
EOF

Apply the change over the local administrative socket:

sudo ldapmodify -Q -Y EXTERNAL -H ldapi:/// -f /root/openldap-index-backup/add-openldap-indexes.ldif

Sample output:

modifying entry "olcDatabase={2}mdb,cn=config"

OpenLDAP queues an internal indexing task after this ldapmodify succeeds. A service restart is not normally required.

If the same index line already exists, ldapmodify fails with a clear duplicate-value error:

ldap_modify: Type or value exists (20)
	additional info: modify/add: olcDbIndex: value #0 already exists

When this error appears, check the current olcDbIndex values before trying to add the index again.

Extend an existing index

Assume this value already exists on your server:

olcDbIndex: cn,sn eq

Copy the exact string from ldapsearch before you generate the LDIF. The value in the delete operation must match the current olcDbIndex value exactly:

cat > /root/openldap-index-backup/widen-cn-index.ldif <<EOF
dn: ${MDB_DN}
changetype: modify
delete: olcDbIndex
olcDbIndex: cn,sn eq
-
add: olcDbIndex
olcDbIndex: cn,sn eq,sub
EOF

Do not use replace: olcDbIndex with a partial list. olcDbIndex is multi-valued; a careless replace can drop unrelated index definitions.

Apply the LDIF the same way as an add operation:

sudo ldapmodify -Q -Y EXTERNAL -H ldapi:/// -f /root/openldap-index-backup/widen-cn-index.ldif

Verify the final values

Confirm the database entry now lists the indexes you intended:

sudo ldapsearch -Q -LLL -o ldif-wrap=no -Y EXTERNAL -H ldapi:/// -b "$MDB_DN" -s base olcDbIndex

Sample output after adding POSIX-related equality indexes:

dn: olcDatabase={2}mdb,cn=config
olcDbIndex: objectClass eq,pres
olcDbIndex: ou,cn,mail,surname,givenname eq,pres,sub
olcDbIndex: uid,uidNumber,gidNumber eq
olcDbIndex: memberUid eq

Monitor and verify the online index build

While slapd builds new index data in the background, use these checks to see progress and confirm normal searches still work:

Watch slapd logs first with journalctl while online indexing runs:

sudo journalctl -u slapd -f

Check database growth on the MDB path:

sudo du -sh /var/lib/ldap

Sample output on the lab host:

252K	/var/lib/ldap

Monitor disk throughput when CPU is high during indexing:

sudo iostat -xz 2

Run a representative search while indexing continues. Store the reader password in a mode-0600 file owned by the user who runs ldapsearch:

LDAP_PASS_FILE="$HOME/.ldap-reader.pass"
install -m 0600 /dev/null "$LDAP_PASS_FILE"
read -rsp "SSSD reader password: " LDAP_READER_PASSWORD
printf '\n'
printf '%s' "$LDAP_READER_PASSWORD" > "$LDAP_PASS_FILE"
unset LDAP_READER_PASSWORD

The password file must contain the reader password before running ldapsearch. Create it as the same operating-system user that runs the test commands and restrict it to mode 0600.

ldapsearch -x -ZZ -H ldap://ldap-server.example.com -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -y "$LDAP_PASS_FILE" -b "ou=people,dc=example,dc=com" -LLL "(uid=jdoe)" dn uid uidNumber

Sample output:

dn: uid=jdoe,ou=people,dc=example,dc=com
uid: jdoe
uidNumber: 10001

Remove the password file when you finish testing:

rm -f "$LDAP_PASS_FILE"
unset LDAP_PASS_FILE

Normal LDAP operations continue during an online build. Large directories may see extra CPU and disk load until the task finishes. Let the online indexing task finish before restarting slapd; an interruption may require an offline slapindex rebuild.

Rebuild OpenLDAP indexes with slapindex

Use slapindex when:

• an online index build was interrupted
• a controlled full rebuild is required during maintenance
• logs or testing indicate incomplete index data
• index configuration changed while slapd was offline

Schedule a maintenance window. Stop the service first:

sudo systemctl stop slapd

Confirm the daemon is not running:

systemctl is-active slapd

Sample output:

inactive

Rebuild all configured indexes for the suffix:

sudo slapindex -F /etc/openldap/slapd.d -b "dc=example,dc=com"

Rebuild selected attributes only when you want a narrower offline pass:

sudo slapindex -F /etc/openldap/slapd.d -b "dc=example,dc=com" uid uidNumber gidNumber memberUid

When you omit the attribute list, slapindex rebuilds every index type configured in olcDbIndex for that database.

If you name an attribute that is not present in olcDbIndex, the tool reports that no index is configured:

mdb_tool_entry_reindex: no index configured for memberUid

Because slapindex runs as root in this example, verify the database ownership and SELinux labels before restarting slapd:

sudo chown -R ldap:ldap /var/lib/ldap

sudo restorecon -Rv /var/lib/ldap

Validate the configuration offline:

sudo slaptest -F /etc/openldap/slapd.d -u

Sample output:

config file testing succeeded

Start the service:

sudo systemctl start slapd

Review recent startup messages:

sudo journalctl -u slapd -n 100 --no-pager

Measure search performance and index cost

Measure the same filter before and after you add or widen an index. Run each test several times on a quiet host; the first query after a cold start includes TLS session setup.

Interactive -W prompts include password-entry time and make the result unusable for index comparison. Store the reader password in a protected file, pass it with -y, redirect search output away from the terminal, and use GNU time to report end-to-end client latency:

LDAP_PASS_FILE="$HOME/.ldap-reader.pass"
install -m 0600 /dev/null "$LDAP_PASS_FILE"
read -rsp "SSSD reader password: " LDAP_READER_PASSWORD
printf '\n'
printf '%s' "$LDAP_READER_PASSWORD" > "$LDAP_PASS_FILE"
unset LDAP_READER_PASSWORD

The password file must contain the reader password before running ldapsearch. Create it as the same operating-system user that runs the test commands and restrict it to mode 0600.

This command measures complete client-side latency, including connection, TLS, bind, search, and result transfer. For server-side comparison, inspect the qtime and etime fields in OpenLDAP 2.6 SEARCH RESULT log records and compare the same filter, scope, base DN, and result count. OpenLDAP 2.5 and later include qtime and etime in result logging, making them more useful for server-side comparisons than interactive shell timing.

Repeat the same search several times and compare runs after the initial cold-cache request.

Before adding POSIX equality indexes

Time a user equality search:

/usr/bin/time -f 'Elapsed: %e seconds' ldapsearch -x -ZZ -H ldap://ldap-server.example.com \
  -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -y "$LDAP_PASS_FILE" -b "ou=people,dc=example,dc=com" -LLL "(uid=jdoe)" dn uid uidNumber >/dev/null

Sample output:

Elapsed: 0.06 seconds

Time a group membership search:

/usr/bin/time -f 'Elapsed: %e seconds' ldapsearch -x -ZZ -H ldap://ldap-server.example.com \
  -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -y "$LDAP_PASS_FILE" -b "ou=groups,dc=example,dc=com" -LLL "(memberUid=jdoe)" dn cn gidNumber >/dev/null

Sample output:

Elapsed: 0.03 seconds

After adding uid,uidNumber,gidNumber eq and memberUid eq

Repeat the user equality search after warming the server and operating-system caches:

/usr/bin/time -f 'Elapsed: %e seconds' ldapsearch -x -ZZ -H ldap://ldap-server.example.com \
  -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -y "$LDAP_PASS_FILE" -b "ou=people,dc=example,dc=com" -LLL "(uid=jdoe)" dn uid uidNumber >/dev/null

Sample output:

Elapsed: 0.04 seconds

Repeat the group membership search:

/usr/bin/time -f 'Elapsed: %e seconds' ldapsearch -x -ZZ -H ldap://ldap-server.example.com \
  -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -y "$LDAP_PASS_FILE" -b "ou=groups,dc=example,dc=com" -LLL "(memberUid=jdoe)" dn cn gidNumber >/dev/null

Sample output:

Elapsed: 0.07 seconds

Substring search when cn already has sub indexing

Time a wildcard name filter only when your applications use that pattern:

/usr/bin/time -f 'Elapsed: %e seconds' ldapsearch -x -ZZ -H ldap://ldap-server.example.com \
  -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -y "$LDAP_PASS_FILE" -b "ou=people,dc=example,dc=com" -LLL "(cn=*Doe*)" dn uid cn >/dev/null

Sample output:

Elapsed: 0.03 seconds

Remove the password file when timing is complete:

rm -f "$LDAP_PASS_FILE"
unset LDAP_PASS_FILE

Record before-and-after values in your change ticket:

These small-directory timings are too noisy to prove improvement on their own. The important validation in this lab is that the unindexed warning disappeared. On a production-sized directory, compare multiple runs and server-side qtime and etime values.

The goal is not the largest possible index set. The goal is faster frequent searches with acceptable storage and write overhead.

Troubleshoot OpenLDAP indexing problems

Useful diagnostics:

sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b "$MDB_DN" -s base olcDbIndex

Lists the current olcDbIndex rules on the live MDB database. Run this when the symptom table points to a missing or wrong index type.

sudo slaptest -F /etc/openldap/slapd.d -u

Validates the on-disk cn=config tree after an index change. Use it when slapd fails to start or before an offline slapindex run.

sudo journalctl -u slapd -n 200 --no-pager

Shows recent mdb_equality_candidates warnings, index build progress, and search timing. Check this when searches stay slow after adding an index.

sudo du -sh /var/lib/ldap

Reports current MDB storage use. Compare before and after index changes when evaluating disk overhead.

References

• OpenLDAP 2.6 Administrator Guide — Tuning
• OpenLDAP 2.6 Administrator Guide — Replication
• OpenLDAP 2.6 slapindex man page

Summary

You learned how to:

• map LDAP filters to OpenLDAP index types
• distinguish equality, presence, substring, and approximate indexes
• inspect current olcDbIndex values on the live MDB database
• identify repeated unindexed searches in server logs
• plan a workload-specific index set instead of copying a generic list
• add and modify indexes through cn=config with ldapmodify
• monitor online index generation while slapd stays up
• complete interrupted builds with offline slapindex
• measure search speed, storage growth, and write overhead
• troubleshoot missing and incomplete MDB indexes
