Configure LDAP Users with NFS Home Directories and autofs

This guide configures centralized home directories for OpenLDAP users.

OpenLDAP stores the user identity and automount maps, NFS stores the home-directory files, and autofs mounts the correct NFS directory only when the user accesses it.

You will learn how to:

• Prepare an NFS home-directory export
• Match NFS ownership with LDAP UID and GID values
• Load the OpenLDAP automount schema
• Create auto.master and auto.home maps in LDAP
• Grant SSSD read access to automount entries
• Configure the SSSD autofs provider
• Configure the automount NSS source
• Mount /home/USERNAME on demand
• Verify SSH login and file ownership
• Troubleshoot LDAP, SSSD, autofs, and NFS separately

The procedure applies to the RHEL family:

• Red Hat Enterprise Linux
• Rocky Linux
• AlmaLinux
• Oracle Linux
• CentOS Stream

Tested on: Rocky Linux 10.2 with OpenLDAP 2.6.10, SSSD 2.12.0, NFSv4, and autofs.

The lab uses:

In production, place LDAP and NFS on separate hosts when you prefer. This lab combines both roles on ldap-server.example.com so the export, schema, maps, and storage stay reproducible on one server.

Complete these guides first:

• Configure an OpenLDAP client with SSSD
• Manage OpenLDAP users and groups
• OpenLDAP ACL configuration
• Configure OpenLDAP TLS with StartTLS

This article owns NFS export, automount schema, LDAP maps, the SSSD autofs provider, and on-demand home mounting. User lookup, PAM authentication, and SSH client setup stay in OpenLDAP client authentication with SSSD. Routine homeDirectory and user creation stay in Manage OpenLDAP users and groups.

Understand the LDAP, NFS and autofs Architecture

When jdoe logs in or accesses /home/jdoe, the request crosses three layers:

1. SSSD resolves jdoe from OpenLDAP
2. autofs asks SSSD for auto.master
3. auto.master maps /home to auto.home
4. auto.home maps jdoe to the NFS export
5. autofs mounts ldap-server.example.com:/srv/nfs/home/jdoe
6. The user sees /home/jdoe on the client

Use this component table to keep the paths separate:

The most important path distinction is:

Do not store /srv/nfs/home/jdoe in the LDAP user's homeDirectory. That path exists only on the NFS server.

Creating automount entries does not create the NFS export, user directory, or permissions. Verify a manual NFS mount before you add autofs so NFS and automount failures stay easy to separate.

Prepare the LDAP User and NFS Home Directory

Start from a working LDAP client where POSIX lookups already succeed. Confirm the account with getent before you touch NFS exports or autofs maps:

getent passwd jdoe

id jdoe

Confirm the LDAP entry contains the expected POSIX attributes:

ldapsearch -x -ZZ -H ldap://ldap-server.example.com -D "cn=admin,dc=example,dc=com" -W -b "ou=people,dc=example,dc=com" -LLL "(uid=jdoe)" dn uid uidNumber gidNumber homeDirectory

Sample output:

dn: uid=jdoe,ou=people,dc=example,dc=com
uid: jdoe
uidNumber: 10001
gidNumber: 10001
homeDirectory: /home/jdoe

The client should resolve the same numeric identity through SSSD.

Configure the NFS server

On ldap-server.example.com, install the NFS server packages:

sudo dnf install -y nfs-utils

Create the export root and the user directory with numeric ownership that matches LDAP:

sudo install -d -m 0755 /srv/nfs/home

sudo install -d -m 0700 -o 10001 -g 10001 /srv/nfs/home/jdoe

Add the export in /etc/exports:

/srv/nfs/home 192.168.122.0/24(rw,sync,root_squash)

Use a subnet or host list that matches your client network. rw allows user writes, sync commits data synchronously, and root_squash maps remote root to an unprivileged NFS user.

Enable NFS and open the firewall:

sudo systemctl enable --now nfs-server

sudo firewall-cmd --permanent --add-service=nfs

sudo firewall-cmd --reload

Apply the export:

sudo exportfs -rav

Verify the active export:

sudo exportfs -v

Sample output:

/srv/nfs/home 192.168.122.0/24(sync,wdelay,hide,no_subtree_check,sec=sys,rw,secure,root_squash,no_all_squash)

Test NFS before autofs

On ldap-client.example.com, install the NFS client tools:

sudo dnf install -y nfs-utils

Create a temporary mount point:

sudo install -d -m 0755 /mnt/test-home

Mount the user's home directly over NFSv4:

sudo mount -t nfs4 ldap-server.example.com:/srv/nfs/home/jdoe /mnt/test-home

Confirm the mount source:

findmnt /mnt/test-home

Sample output:

TARGET         SOURCE                                     FSTYPE OPTIONS
/mnt/test-home ldap-server.example.com:/srv/nfs/home/jdoe nfs4   rw,relatime,vers=4.2,rsize=524288,wsize=524288,namlen=255,hard,proto=tcp,timeo=600,retrans=2,sec=sys,clientaddr=192.168.56.108,local_lock=none,addr=192.168.56.108

Check ownership and write access as the LDAP user:

ls -ldn /mnt/test-home

sudo -u jdoe touch /mnt/test-home/nfs-test

ls -ln /mnt/test-home/nfs-test

Unmount the test mount:

sudo umount /mnt/test-home

Do not continue to LDAP automount maps until this manual mount works.

Load the OpenLDAP automount Schema

Use the RFC2307bis-style automount schema in this guide:

• automountMap
• automount
• automountMapName
• automountKey
• automountInformation

Check whether the schema is already loaded:

sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=schema,cn=config '(&(objectClass=olcSchemaConfig)(olcObjectClasses=*automountMap*))' dn

When the search returns a schema entry such as cn=automount-rfc2307bis,cn=schema,cn=config, skip the import step.

The autofs package still ships /usr/share/doc/autofs/autofs.schema, but the package documentation marks that file as outdated. It also does not provide the automountMapName and automountKey attributes used here. Discover packaged documentation with:

rpm -ql autofs | grep -Ei 'README.*schema|autofs\.schema'

Sample output on Rocky Linux 10.2:

/usr/share/doc/autofs/README.autofs-schema
/usr/share/doc/autofs/autofs.schema

Back up cn=config before loading a new schema:

sudo install -d -m 0700 /root/openldap-autofs-backup

sudo slapcat -F /etc/openldap/slapd.d -n 0 -l /root/openldap-autofs-backup/cn-config-before-automount-schema.ldif

Create a direct cn=config schema LDIF. These definitions match the RFC2307bis draft automount model used in this guide:

sudo tee /root/automount-rfc2307bis.ldif >/dev/null <<'EOF'
dn: cn=automount-rfc2307bis,cn=schema,cn=config
objectClass: olcSchemaConfig
cn: automount-rfc2307bis
olcAttributeTypes: ( 1.3.6.1.1.1.1.31 NAME 'automountMapName'
 DESC 'automount Map Name'
 EQUALITY caseExactMatch
 SYNTAX 1.3.6.1.4.1.1466.115.121.1.15
 SINGLE-VALUE )
olcAttributeTypes: ( 1.3.6.1.1.1.1.32 NAME 'automountKey'
 DESC 'Automount Key value'
 EQUALITY caseExactMatch
 SYNTAX 1.3.6.1.4.1.1466.115.121.1.15
 SINGLE-VALUE )
olcAttributeTypes: ( 1.3.6.1.1.1.1.33 NAME 'automountInformation'
 DESC 'Automount information'
 EQUALITY caseExactMatch
 SYNTAX 1.3.6.1.4.1.1466.115.121.1.15
 SINGLE-VALUE )
olcObjectClasses: ( 1.3.6.1.1.1.2.16 NAME 'automountMap'
 SUP top STRUCTURAL
 MUST automountMapName
 MAY description )
olcObjectClasses: ( 1.3.6.1.1.1.2.17 NAME 'automount'
 SUP top STRUCTURAL
 DESC 'Automount information'
 MUST ( automountKey $ automountInformation )
 MAY description )
EOF

Protect the LDIF before you import it:

sudo chmod 600 /root/automount-rfc2307bis.ldif

Import the schema through the local cn=config socket:

sudo ldapadd -Q -Y EXTERNAL -H ldapi:/// -f /root/automount-rfc2307bis.ldif

A successful import prints adding new entry "cn=automount-rfc2307bis,cn=schema,cn=config".

Validate the offline configuration:

sudo slaptest -F /etc/openldap/slapd.d -u

Create LDAP auto.master and auto.home Maps

Use this directory structure:

dc=example,dc=com
└── ou=automount
    ├── automountMapName=auto.master
    │   └── automountKey=/home
    └── automountMapName=auto.home
        └── automountKey=*

Create automount-home-maps.ldif:

dn: ou=automount,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
ou: automount
description: Central autofs maps

dn: automountMapName=auto.master,ou=automount,dc=example,dc=com
objectClass: top
objectClass: automountMap
automountMapName: auto.master

dn: automountKey=/home,automountMapName=auto.master,ou=automount,dc=example,dc=com
objectClass: top
objectClass: automount
automountKey: /home
automountInformation: auto.home

dn: automountMapName=auto.home,ou=automount,dc=example,dc=com
objectClass: top
objectClass: automountMap
automountMapName: auto.home

dn: automountKey=*,automountMapName=auto.home,ou=automount,dc=example,dc=com
objectClass: top
objectClass: automount
automountKey: *
automountInformation: -fstype=nfs4,rw,hard,_netdev,nosuid,nodev ldap-server.example.com:/srv/nfs/home/&

The wildcard entry works like this:

User accesses:    /home/jdoe
* becomes:        jdoe
& becomes:        jdoe
NFS location:     ldap-server.example.com:/srv/nfs/home/jdoe

Add the entries over StartTLS:

ldapadd -x -ZZ -H ldap://ldap-server.example.com -D "cn=admin,dc=example,dc=com" -W -f automount-home-maps.ldif

Verify the master map:

ldapsearch -x -ZZ -H ldap://ldap-server.example.com -D "cn=admin,dc=example,dc=com" -W -b "automountMapName=auto.master,ou=automount,dc=example,dc=com" -LLL "(objectClass=automount)" automountKey automountInformation

Sample output:

dn: automountKey=/home,automountMapName=auto.master,ou=automount,dc=example,dc=com
automountKey: /home
automountInformation: auto.home

Verify the home map:

ldapsearch -x -ZZ -H ldap://ldap-server.example.com -D "cn=admin,dc=example,dc=com" -W -b "automountMapName=auto.home,ou=automount,dc=example,dc=com" -LLL "(objectClass=automount)" automountKey automountInformation

Sample output:

dn: automountKey=*,automountMapName=auto.home,ou=automount,dc=example,dc=com
automountKey: *
automountInformation: -fstype=nfs4,rw,hard,_netdev,nosuid,nodev ldap-server.example.com:/srv/nfs/home/&

Do not mix object classes and attributes across schema models. These combinations are invalid:

automountMap + nisMapEntry
nisMap + automountInformation
automount + cn

Grant SSSD Access to Automount Maps

The SSSD service account must be able to search and read ou=automount,dc=example,dc=com.

Recommended ACL direction:

to dn.subtree="ou=automount,dc=example,dc=com"
    by dn.exact="uid=sssd-reader,ou=service-accounts,dc=example,dc=com" read
    by group.exact="cn=directory-admins,ou=groups,dc=example,dc=com" write
    by * none

Place the rule before a broader deny rule. Use OpenLDAP ACL configuration for indexed replacement and rollback.

Test with the exact SSSD bind identity:

ldapsearch -x -ZZ -H ldap://ldap-server.example.com -D "uid=sssd-reader,ou=service-accounts,dc=example,dc=com" -W -b "ou=automount,dc=example,dc=com" -LLL "(|(objectClass=automountMap)(objectClass=automount))" automountMapName automountKey automountInformation

Interpret the result:

If the reader bind succeeds but searches fail after you enabled TLS hardening from Configure OpenLDAP TLS with StartTLS, confirm the client uses StartTLS or LDAPS before you change automount entries.

Configure SSSD and autofs on RHEL Family Clients

Install the required packages on ldap-client.example.com:

sudo dnf install -y autofs nfs-utils sssd sssd-ldap

Extend the existing /etc/sssd/sssd.conf from OpenLDAP client authentication with SSSD. Append autofs to the existing services value and preserve every responder that is already configured. Do not replace the working identity, authentication, TLS, or bind settings unless you are correcting them deliberately.

Example when the client already uses sudo and ssh:

[sssd]
# Before:
# services = nss, pam, sudo, ssh

# After:
services = nss, pam, sudo, ssh, autofs
domains = example.com

[autofs]

[domain/example.com]
autofs_provider = ldap
ldap_autofs_search_base = ou=automount,dc=example,dc=com

ldap_schema = rfc2307
ldap_autofs_map_master_name = auto.master
ldap_autofs_map_object_class = automountMap
ldap_autofs_map_name = automountMapName
ldap_autofs_entry_object_class = automount
ldap_autofs_entry_key = automountKey
ldap_autofs_entry_value = automountInformation

The lab client previously contained only nss and pam:

[sssd]
services = nss, pam, autofs
domains = example.com

Keep the existing id_provider, auth_provider, ldap_uri, search bases, bind account, and TLS settings from the SSSD client guide. Add only the [autofs] section and the autofs_provider plus ldap_autofs_* options shown above.

The explicit automount mappings matter because ldap_schema = rfc2307 otherwise defaults SSSD toward nisMap, nisObject, nisMapName, and nisMapEntry for automount lookups.

Protect and validate the configuration:

sudo chown root:root /etc/sssd/sssd.conf

sudo chmod 600 /etc/sssd/sssd.conf

sudo sssctl config-check

Sample output:

Issues identified by validators: 0

Verify that sss is present in the automount NSS database. Preserve the order generated by the active authselect profile rather than forcing a different order:

grep '^automount:' /etc/nsswitch.conf

Typical current RHEL-family output:

automount: sss files

When sss is missing:

• Inspect the active authselect profile.
• Update the custom profile when one is in use.
• Avoid directly editing an authselect-managed /etc/nsswitch.conf.

Check the selected profile and disable only the conflicting home-directory feature:

authselect current

When with-mkhomedir is listed, disable it so PAM does not create local /home/USERNAME directories:

sudo authselect disable-feature with-mkhomedir

Confirm that only with-mkhomedir was removed:

authselect current

Confirm that the active profile supports with-mkhomedir before you disable it. Do not replace a custom, IdM-generated, or domain-join-generated profile with the stock sssd profile solely for this article.

Restart SSSD and autofs:

sudo systemctl restart sssd

sudo systemctl enable --now autofs

sudo systemctl restart autofs

The automounter reads its master map at startup, so restart autofs after you change SSSD automount settings or LDAP master-map entries.

Verify On-Demand NFS Home Directories

Confirm the LDAP user still resolves:

getent passwd jdoe

The home path should remain the client mount point:

jdoe:*:10001:10001:Jane Doe:/home/jdoe:/bin/bash

Display the automount maps known to the client:

sudo automount -m

The output should include the LDAP-backed /home map:

Mount point: /home

source(s):

  instance type(s): sss
  map: auto.home

  * | -fstype=nfs4,rw,hard,_netdev,nosuid,nodev ldap-server.example.com:/srv/nfs/home/&

Before access, the path may not be mounted yet:

findmnt /home/jdoe

Trigger the mount:

ls -la /home/jdoe

Verify the mount source:

findmnt /home/jdoe

On a separate client host, expect an NFS source such as ldap-server.example.com:/srv/nfs/home/jdoe.

Test write access:

sudo -u jdoe touch /home/jdoe/autofs-test

Confirm the file on the NFS server:

ls -ln /srv/nfs/home/jdoe/autofs-test

Sample output:

-rw-r--r--. 1 10001 10001 0 Jul 14 21:54 /srv/nfs/home/jdoe/autofs-test

Test an end-to-end login:

ssh [email protected]

After login:

pwd

Expected result:

/home/jdoe

touch login-test

ls -ln login-test

A wildcard map can still attempt a mount for a path such as /home/nonexistent-user even when no LDAP account exists. Login authorization remains a separate SSSD identity and access decision.

Provision and Maintain Shared Home Directories

When you add a new LDAP user, complete both steps:

1. Create the posixAccount entry in OpenLDAP
2. Create the matching directory on the NFS server

Example NFS provisioning:

sudo install -d -m 0700 -o 10002 -g 10002 /srv/nfs/home/asmith

Recommended checks:

LDAP uidNumber matches NFS owner UID
LDAP gidNumber matches NFS owner GID
LDAP homeDirectory is /home/USERNAME
NFS directory is /srv/nfs/home/USERNAME
Directory mode is appropriate
User resolves on ldap-client
Manual NFS mount works
Autofs mount works

For a wildcard auto.home map, you do not need a separate LDAP automount entry for every user. Creating the LDAP account and the NFS directory is enough.

Use explicit map entries instead of * when:

• Users have different NFS servers
• Users have different export roots
• Some accounts must not receive shared homes
• Different mount options are required
• Storage is divided by department or location

Backup boundaries:

• LDAP backups preserve automount maps.
• NFS data requires a separate filesystem backup.
• Restoring LDAP alone does not restore user files.
• Restoring NFS files alone does not restore UID and GID identity definitions.

See OpenLDAP backup and restore for directory data protection.

Troubleshoot LDAP, SSSD, autofs and NFS

When a deleted or modified LDAP automount map still appears on the client, invalidate the SSSD autofs cache before you retest:

sudo systemctl stop autofs

Pauses the automounter so cached maps are not read while you clear SSSD state.

sudo sss_cache -A

Expires all SSSD caches, including autofs maps, after LDAP map changes.

To expire one map only:

sudo sss_cache -a auto.home

Targets a single map when other autofs data should stay cached.

Restart autofs and verify the current map:

sudo systemctl start autofs

Reloads the master map after the cache clear.

sudo automount -m

Lists active maps and mount points when getent works but the home path does not mount.

ls -la /home/jdoe

Confirms the home directory mounted with the expected ownership after autofs reports the map.

Restart SSSD separately only when its configuration or provider state changed. Restart autofs after master-map changes because the automounter reads that map during startup.

Useful client commands:

sudo automount -m

Lists active autofs maps and mount points when identity lookup works but the home path is missing.

findmnt -t nfs,nfs4

Shows whether the home path is actually an NFS mount or still a local directory.

sudo journalctl -u autofs -n 100 --no-pager

Recent automounter errors when map lookup or mount requests fail.

sudo journalctl -u sssd -n 100 --no-pager

SSSD autofs provider and LDAP reader errors when maps do not appear in automount -m.

When the SSSD log files exist, review:

sudo grep -iE 'autofs|automount|ldap|offline|error' /var/log/sssd/sssd_autofs.log /var/log/sssd/sssd_example.com.log

Focused autofs and LDAP messages when the journal output is too noisy.

Useful NFS-server commands:

sudo exportfs -v

Confirms the export path, client access, and options when manual mounts fail.

sudo journalctl -u nfs-server -n 100 --no-pager

NFS server startup and export errors when clients cannot reach the share.

sudo ss -ltnp | grep ':2049'

Verifies the NFS service is listening when connectivity or firewall issues are suspected.

Enable temporary autofs debugging through the supported distribution configuration when you need deeper traces. Restore the normal debug level afterward.

References

• Red Hat Enterprise Linux 10 — Mounting file systems on demand
• Red Hat Enterprise Linux 10 — Deploying an NFS server
• Red Hat Enterprise Linux 10 — Troubleshooting SSSD
• sssd-ldap(5) — upstream SSSD source
• sssd-ldap-attributes(5)
• sssd.conf(5)
• autofs(5)
• auto.master(5)
• exports(5)

Summary

You configured an LDAP POSIX user with /home/USERNAME, created an NFS-backed home directory with matching UID and GID, loaded the RFC2307bis automount schema, created LDAP auto.master and auto.home maps, granted the SSSD reader access to ou=automount, enabled the SSSD LDAP autofs provider with explicit attribute mappings, verified the automount NSS source includes sss, invalidated stale autofs map cache when needed, verified on-demand mounting through autofs, and separated LDAP identity backup from NFS file backup.
