Install and Configure OpenLDAP on RHEL-Based Linux

This walkthrough installs OpenLDAP 2.6 on RHEL-based Linux, configures the MDB backend through cn=config, and builds a small directory you can query locally and from another lab host. The commands below were run on the primary test host listed under Tested on, with real terminal output kept so you can compare your host.

This is the server-installation lesson in the OpenLDAP tutorial series.

Complete these lessons first:

• LDAP and OpenLDAP basics — if DN, suffix, or schema terms are new
• OpenLDAP vs 389 Directory Server — if you are still choosing between OpenLDAP and 389 DS on enterprise Linux

Repository names, vendor support boundaries, and distribution-specific package notes are in RHEL-Family Compatibility and Support Notes.

Tested on: Rocky Linux 10.2; OpenLDAP 2.6.10 from EPEL; SELinux Enforcing.

RHEL-Family Compatibility and Support Notes

This lesson targets RHEL-family 9 and 10 systems running OpenLDAP 2.6—RHEL, Rocky Linux, AlmaLinux, Oracle Linux, and CentOS Stream.

What stays the same

• cn=config configuration through ldapmodify
• LDIF structure, schema loading, and verification workflow

What differs by distribution

• commands to enable the repository that provides openldap-servers
• exact OpenLDAP RPM build from the matching EPEL or developer-EPEL branch

Package source

• base repositories ship OpenLDAP client libraries and command-line tools
• openldap-servers (slapd) is not in those base repositories—you obtain it from EPEL or a distribution-specific developer EPEL mirror

RHEL and vendor support

• Red Hat deprecated openldap-servers in RHEL 7.4 and removed it from RHEL 8 and 9.
• On RHEL, installing slapd from EPEL creates a community-maintained deployment—not a Red Hat-supported directory service.
• Organizations that need centralized Linux identity management should evaluate Red Hat Identity Management.
• Organizations that need a supported general-purpose LDAP directory should evaluate Red Hat Directory Server.

Before applying on another host

• verify the enabled repositories on your distribution
• confirm the installed OpenLDAP version and package NEVRA
• inspect the slapd systemd unit

Red Hat documents the RHEL 7.4 deprecation and confirms removal of openldap-servers from RHEL 8 and 9.

Target Server Configuration

When you finish the lab run, the server should look like this:

That is a working lab directory, but not a hardened one. Before production use, plan for:

• TLS on port 389 (StartTLS) or port 636 (LDAPS)—credentials and LDAP traffic stay plain until then
• explicit olcAccess ACL rules on the MDB database—the install leaves the default policy in place until you follow OpenLDAP ACL Configuration with Practical Examples
• backup, monitoring, and replication in later lessons

Lab Environment and Naming Plan

The layout below was used on the lab VM so hostname, IP, and DIT names stayed aligned across LDIF files. Match the values on your host, or keep the same pattern with your own names.

Plain LDAP can work by IP address, but a stable FQDN matters once TLS and remote clients enter the picture. Set the hostname early so later lessons stay consistent.

The lab uses a host-only virtual network (192.168.56.0/24 here). Put LDAP hostnames on the host-only adapter address—not the NAT interface (for example 10.0.2.15).

Set the LDAP server hostname with hostnamectl so later TLS and client lessons stay consistent:

sudo hostnamectl set-hostname ldap-server.example.com

Add these lines to /etc/hosts on the LDAP server:

192.168.56.108 ldap-server.example.com ldap-server
192.168.56.109 ldap-client.example.com ldap-client

Adjust the address if your lab network differs. Then confirm the FQDN, name resolution, and SELinux mode:

hostname -f

Sample output:

ldap-server.example.com

getent hosts ldap-server.example.com

Sample output:

192.168.56.108 ldap-server.example.com ldap-server

getenforce

Sample output:

Enforcing

Install OpenLDAP Server on RHEL-Based Linux

Enable the repository appropriate to your distribution (table below), then install openldap-servers.

The EPEL openldap-servers package can require an exact version of the OpenLDAP libraries supplied by the corresponding Enterprise Linux branch. When EPEL moves ahead of the base packages on a minor release, dnf can fail with an exact-version dependency.

When that happens:

• do not force-install mismatched RPMs
• wait until EPEL and the base repositories target the same Enterprise Linux branch
• update the system and retry

Enable the appropriate package repository

EPEL carries openldap-servers for EL9 and EL10, but the commands to enable it differ by distribution:

Oracle officially lists both ol9_developer_EPEL and ol10_developer_EPEL as mirrors of selected EPEL packages.

For EPEL enablement, see Install EPEL on RHEL, Rocky Linux, AlmaLinux, CentOS Stream, and Oracle Linux. Use that guide for the exact repository commands on your distribution.

After EPEL or the equivalent repository is enabled on your host, refresh metadata and install the server packages. Package installs use sudo and dnf on this lab host:

sudo dnf upgrade --refresh -y

sudo dnf install -y openldap openldap-clients openldap-servers

Confirm the installed package NEVRAs with rpm -q; the rpm command covers -qa, -qf, and version checks on RPM-based hosts. Build numbers differ between EL9, EL10, distribution releases, and EPEL branches—the sample output below is from the primary test host:

rpm -q openldap openldap-clients openldap-servers

Sample output:

openldap-2.6.10-1.el10.x86_64
openldap-clients-2.6.10-1.el10.x86_64
openldap-servers-2.6.10-1.el10_2.x86_64

dnf repolist --enabled

Confirm that the appropriate EPEL, EPEL-derived, or Oracle developer EPEL repository for your distribution is enabled. The Fedora package index lists different OpenLDAP server builds for EPEL 9, EPEL 10.2, and EPEL 10.3, so do not assume one build number applies to every system.

On the primary test host, the enabled repository included:

epel    Extra Packages for Enterprise Linux 10 - x86_64

slapd -VV 2>&1 | head

Sample output:

@(#) $OpenLDAP: slapd 2.6.10 (Jan 28 2026 00:00:00) $
	openldap

The el10_2 suffix on openldap-servers shows the package came from the Enterprise Linux 10.2 EPEL branch on the test host.

Start slapd and Inspect cn=config

Enable and start slapd with systemctl, then confirm port 389 is listening:

sudo systemctl enable --now slapd

sudo systemctl status slapd --no-pager

Sample output:

● slapd.service - OpenLDAP Server Daemon
     Loaded: loaded (/usr/lib/systemd/system/slapd.service; enabled; preset: disabled)
     Active: active (running) since Mon 2026-07-13 21:50:50 IST; 262ms ago
       Docs: man:slapd
             man:slapd-config
             man:slapd-mdb
    Process: 17006 ExecStartPre=/usr/libexec/openldap/check-config.sh (code=exited, status=0/SUCCESS)
    Process: 17038 ExecStart=/usr/sbin/slapd -u ldap -h ldap:/// ldaps:/// ldapi:/// (code=exited, status=0/SUCCESS)
   Main PID: 17046 (slapd)

On the primary test host, the packaged unit started slapd with LDAP, LDAPS, and local LDAPI listener URLs. Check your own ExecStart line because listener defaults can differ between package builds or local systemd overrides. At this stage only plain LDAP and the local LDAPI socket are in use. Seeing ldaps:/// in the unit file does not mean certificate-based TLS is ready yet.

List listeners on port 389 with ss:

sudo ss -ltnp 'sport = :389'

Sample output:

State  Recv-Q Send-Q Local Address:Port Peer Address:PortProcess
LISTEN 0      2048         0.0.0.0:389       0.0.0.0:*    users:(("slapd",pid=17046,fd=7))
LISTEN 0      2048            [::]:389          [::]:*    users:(("slapd",pid=17046,fd=8))

If slapd fails to start, inspect the unit log with journalctl first:

sudo journalctl -u slapd -n 30 --no-pager

The EPEL package initializes the dynamic slapd.d tree under /etc/openldap/slapd.d/. Make configuration changes through the cn=config database with LDAP tools such as ldapmodify instead of editing files under slapd.d/ while slapd is running. Upstream still documents slapd.conf, although it is deprecated in favor of cn=config—see the OpenLDAP 2.6 Administrator's Guide.

Discover the MDB database DN dynamically

Hard-coding olcDatabase={2}mdb,cn=config is a common mistake. Database index numbers differ between installations and often produce ldap_modify: No such object (32).

Query the running server for the MDB backend:

sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=config '(objectClass=olcMdbConfig)' dn olcSuffix olcDbDirectory

Sample output:

dn: olcDatabase={2}mdb,cn=config
olcDbDirectory: /var/lib/ldap
olcSuffix: dc=my-domain,dc=com

Store the returned DN in a shell variable for the LDIF work in the next section:

MDB_DN=$(sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=config '(objectClass=olcMdbConfig)' dn | awk '/^dn: / {sub(/^dn: /, ""); print; exit}')

if [[ -z "$MDB_DN" ]]; then echo "No MDB database was found under cn=config." >&2; exit 1; fi

printf 'MDB database DN: %s\n' "$MDB_DN"

Sample output:

MDB database DN: olcDatabase={2}mdb,cn=config

OpenLDAP assigns numeric prefixes to maintain ordering, so do not assume database or schema indices are identical across hosts.

Configure the MDB Directory Database

MDB is OpenLDAP's primary storage backend. It uses LMDB and replaced the older BDB and HDB backends removed from OpenLDAP 2.5.

Generate the administrator password

olcRootDN is the database superuser for binds against your suffix. It does not need to exist as an entry inside the directory tree—a detail that often trips up new administrators.

Generate a password hash with:

sudo slappasswd

Enter and confirm a strong password, then copy the {SSHA} hash into configure-mdb.ldif using the discovered $MDB_DN:

umask 077

The restrictive umask creates the LDIF with owner-only permissions because it contains a password hash.

cat > configure-mdb.ldif <<EOF
dn: $MDB_DN
changetype: modify
replace: olcSuffix
olcSuffix: dc=example,dc=com
-
replace: olcRootDN
olcRootDN: cn=admin,dc=example,dc=com
-
replace: olcRootPW
olcRootPW: {SSHA}REPLACE_WITH_GENERATED_HASH
EOF

The shell expands $MDB_DN while creating the file, so the LDIF targets the MDB database discovered on the server instead of assuming a fixed numeric index.

These MDB settings serve different roles:

• olcSuffix — directory subtree served by this database
• olcRootDN — administrative identity that can manage that subtree
• olcRootPW — hashed password for that administrator

They affect the data database and are separate from the local SASL EXTERNAL identity used to manage cn=config. The olcRootDN does not need a matching entry under the suffix.

Apply the change over the local LDAPI socket as root. cn=config modifications use SASL EXTERNAL on ldapi:///—not the administrator simple bind used later for directory data:

sudo ldapmodify -Q -Y EXTERNAL -H ldapi:/// -f configure-mdb.ldif

Sample output:

modifying entry "olcDatabase={2}mdb,cn=config"

Verify the suffix, root DN, and data directory immediately:

sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b "$MDB_DN" -s base olcSuffix olcRootDN olcDbDirectory

Sample output:

dn: olcDatabase={2}mdb,cn=config
olcDbDirectory: /var/lib/ldap
olcSuffix: dc=example,dc=com
olcRootDN: cn=admin,dc=example,dc=com

At that point slapd knew which subtree it would serve and which DN could bootstrap the directory.

Load Schemas and Create the Base DIT

The default core schema does not define Linux-style user entries. Load these additional schemas before adding POSIX users:

• cosine — commonly used mail and networking attributes
• nis — posixAccount and posixGroup object classes
• inetorgperson — person-oriented attributes for user entries

Check what is already loaded:

sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=schema,cn=config dn

On the primary test host only the core schema was loaded at first. Check your server before loading more because package defaults can differ:

dn: cn=schema,cn=config

dn: cn={0}core,cn=schema,cn=config

Load the remaining standard schemas one at a time:

sudo ldapadd -Q -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/cosine.ldif

Sample output:

adding new entry "cn=cosine,cn=schema,cn=config"

sudo ldapadd -Q -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/nis.ldif

Sample output:

adding new entry "cn=nis,cn=schema,cn=config"

sudo ldapadd -Q -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/inetorgperson.ldif

Sample output:

adding new entry "cn=inetorgperson,cn=schema,cn=config"

If a schema is already loaded, ldapadd returns Already exists (68). Skip files that are already present.

For schema theory on attributes and object classes, return to the LDAP and OpenLDAP basics lesson linked in the introduction.

Create the base entry and organizational units

The parent dc=example,dc=com entry has to exist before ou=people and ou=groups can be added. Keep the tree shallow for the lab and put accounts and groups in separate OUs.

Combine the domain root and both OUs in one base-dit.ldif file:

dn: dc=example,dc=com
objectClass: top
objectClass: dcObject
objectClass: organization
o: Example Organization
dc: example

dn: ou=people,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
ou: people

dn: ou=groups,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
ou: groups

Add the entries with a simple bind to the administrator DN. Data under the suffix uses olcRootDN and the password hash stored in olcRootPW—a different path from the LDAPI socket used for cn=config changes:

ldapadd -x -H ldap://localhost -D "cn=admin,dc=example,dc=com" -W -f base-dit.ldif

Sample output:

adding new entry "dc=example,dc=com"

adding new entry "ou=people,dc=example,dc=com"

adding new entry "ou=groups,dc=example,dc=com"

Confirm the tree:

ldapsearch -x -H ldap://localhost -D "cn=admin,dc=example,dc=com" -W -b "dc=example,dc=com" -LLL dn objectClass

Sample output:

dn: dc=example,dc=com
objectClass: top
objectClass: dcObject
objectClass: organization

dn: ou=people,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit

dn: ou=groups,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit

Open the Firewall and Verify the Server

Open the standard LDAP service for remote lab tests with firewalld firewall-cmd. This lesson needs only port 389; LDAPS and StartTLS belong in the TLS lesson:

sudo firewall-cmd --permanent --add-service=ldap

sudo firewall-cmd --reload

Confirm the LDAP service is allowed:

sudo firewall-cmd --query-service=ldap

Sample output:

yes

Local verification sequence

Run these checks on the LDAP server in order:

• read the Root DSE to confirm the advertised naming context
• confirm the administrator password with ldapwhoami
• query the organizational units to confirm the data database and schemas accept the DIT skeleton
• run slaptest to validate that the on-disk configuration parses cleanly
• review journalctl for bind or schema errors if any earlier step failed

Add POSIX users and groups in Manage OpenLDAP users and groups with LDIF after TLS is in place.

Read the Root DSE:

ldapsearch -x -H ldap://localhost -b "" -s base -LLL namingContexts supportedLDAPVersion

Sample output:

dn:
namingContexts: dc=example,dc=com
supportedLDAPVersion: 3

Confirm the administrator password works:

ldapwhoami -x -H ldap://localhost -D "cn=admin,dc=example,dc=com" -W

Sample output:

dn:cn=admin,dc=example,dc=com

Query the organizational units to confirm the data database accepts the DIT skeleton:

ldapsearch -x -H ldap://localhost -D "cn=admin,dc=example,dc=com" -W -b "dc=example,dc=com" -LLL "(|(ou=people)(ou=groups))" dn ou objectClass

Sample output:

dn: ou=people,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
ou: people

dn: ou=groups,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
ou: groups

Both OUs are present under the suffix—the directory is ready for user and group entries in the management lesson.

Run slaptest to validate that the on-disk configuration parses cleanly as the ldap service user. It checks configuration syntax and file readability—it does not prove network listeners or live directory data are correct:

sudo slaptest -u

Sample output:

config file testing succeeded

sudo journalctl -u slapd --since "10 minutes ago" --no-pager

Review the journal for bind or schema errors if any earlier step failed.

Remote connectivity test

From the LDAP client host (ldap-client.example.com in this lab), query the Root DSE by hostname. The query is anonymous and sends no password—safe for a plain ldap:// check. Add the host-only ldap-server.example.com entry to that host's /etc/hosts file first. A minimal client may not include ldapsearch yet:

sudo dnf install -y openldap-clients

ldapsearch -x -H ldap://ldap-server.example.com -b "" -s base -LLL namingContexts supportedLDAPVersion

Sample output:

dn:
namingContexts: dc=example,dc=com
supportedLDAPVersion: 3

Running this from a second machine verifies:

• hostname resolution on the client
• TCP port 389 reachability
• the firewall rule on the LDAP server
• the external LDAP listener

Do not perform a remote administrator simple bind until TLS is configured.

Troubleshoot OpenLDAP Installation on RHEL-Based Linux

When a package-version mismatch appears, compare what your distribution and EPEL currently offer:

cat /etc/os-release

Identifies the distribution name and version string shown in repository metadata.

rpm -E '%{rhel}'

Prints the Enterprise Linux major release number used by EPEL package branches.

dnf --showduplicates list openldap openldap-clients openldap-servers

Lists installed and available OpenLDAP package versions when dnf install reports a dependency conflict.

dnf repolist --enabled

Confirms EPEL or the developer EPEL repository is enabled before retrying the install.

On the primary test host the output looked like this:

# cat /etc/os-release
NAME="Rocky Linux"
VERSION="10.2 (Red Quartz)"
ID="rocky"
ID_LIKE="rhel centos fedora"
# rpm -E '%{rhel}'
10
# dnf --showduplicates list openldap openldap-clients openldap-servers
Installed Packages
openldap.x86_64          2.6.10-1.el10       @anaconda
openldap-clients.x86_64  2.6.10-1.el10       @baseos
openldap-servers.x86_64  2.6.10-1.el10_2     @epel
Available Packages
openldap-servers.x86_64  2.6.10-1.el10_2     epel
# dnf repolist --enabled
repo id    repo name
epel       Extra Packages for Enterprise Linux 10 - x86_64

Do not use --allowerasing, download unrelated RPMs manually, or force the package with rpm --nodeps. Update the operating system when the matching Enterprise Linux minor release becomes available, or wait for the repositories to synchronize.

These errors can show up temporarily when an EPEL branch publishes a build that needs base-library versions your enabled repositories do not yet ship. SSSD login failures and LDAPS certificate errors belong in the client and TLS lessons—not here.

Next Steps

Later lessons in the OpenLDAP series cover:

1. OpenLDAP cn=config and MDB explained with ldapmodify — discover numbered database DNs and change server settings safely
2. Configure OpenLDAP TLS on RHEL-based Linux — StartTLS, LDAPS, and encrypted password binds
3. Manage OpenLDAP users and groups with LDIF — add, modify, rename, reset passwords, and delete POSIX accounts
4. Configure OpenLDAP client with SSSD on RHEL-based Linux
5. OpenLDAP backup and restore — recurring slapcat backups, retention, and disaster recovery
6. Migrate OpenLDAP to a new server and migrate Linux users into LDAP
7. OpenLDAP master-slave replication for availability
8. OpenLDAP indexing and performance — map real search filters to olcDbIndex

References

• OpenLDAP 2.6 Administrator's Guide — official configuration reference
• OpenLDAP 2.6 quick start — upstream install overview
• RFC 4511 — LDAP protocol
• Fedora EPEL documentation — enabling and using EPEL on Enterprise Linux
• openldap-servers in Fedora Packages — OpenLDAP server builds available through EPEL

Summary

This walkthrough installed OpenLDAP 2.6 on a RHEL-family system and left:

• the live MDB database DN discovered dynamically
• suffix and administrator credentials configured through cn=config
• required schemas loaded and the base DIT created
• local and remote LDAP searches verified

The procedure was validated on Rocky Linux 10.2. Configure TLS, access-control rules, backup, and client integration before using the directory in production.
