Create a Custom Schema in 389 Directory Server

In this guide, I'll add employeeBadgeNumber through a custom auxiliary object class named glcEmployee, using dsconf schema on instance ldap1 under dc=example,dc=com.

Extend the directory schema only when existing standard attributes and object classes cannot represent the required data. Many deployments already have employeeNumber on inetOrgPerson-style entries. Search the loaded schema before you allocate new OIDs.

Before you start:

• Install 389 Directory Server — running instance with Directory Manager or equivalent dsconf access
• 389 Directory Server architecture — how schema fits outside suffix data
• Manage users and groups — sample user1 entry under ou=people
• dsconf command cheat sheet — flag reference for dsconf schema

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

Understand attributes and object classes

LDAP schema defines what directory entries may contain. Attribute types describe individual fields; object classes group those fields into entry shapes.

This guide uses an auxiliary class so you can extend user1 without replacing its existing posixAccount and nsPerson classes.

Plan the custom schema

Every custom attribute and object class needs a globally unique numeric OID. Production deployments must request or use an OID beneath your organization's IANA private enterprise number. Document your allocation range in an internal registry so two administrators do not publish the same number with different meanings.

This lab uses IANA's documentation-only PEN 32473 from RFC 5612. Do not use this branch in a production schema. Replace it with an OID beneath your organization's assigned PEN.

Inspect the existing schema

Search for an existing definition before you create a duplicate. A missing attribute query returns no definition line on this version. dsconf may also print a client-side error when the name is unknown:

dsconf ldap1 schema attributetypes query employeeBadgeNumber

Sample output:

Error: 'NoneType' object has no attribute 'names'

Query a standard attribute to confirm what is already available. employeeNumber on inetOrgPerson is a common alternative to inventing a badge field:

dsconf ldap1 schema attributetypes query employeeNumber

( 2.16.840.1.113730.3.1.3 NAME 'employeeNumber' DESC 'numerically identifies an employee within an organization' EQUALITY caseIgnoreMatch SUBSTR caseIgnoreSubstringsMatch SYNTAX 1.3.6.1.4.1.1466.115.121.1.15 SINGLE-VALUE X-ORIGIN 'RFC 2798' )

MUST

MAY
( 2.16.840.1.113730.3.2.2 NAME 'inetOrgPerson' SUP organizationalPerson STRUCTURAL MAY ( audio $ businessCategory $ carLicense $ departmentNumber $ displayName $ employeeNumber $ employeeType $ givenName $ homePhone $ homePostalAddress $ initials $ jpegPhoto $ labeledURI $ mail $ manager $ mobile $ o $ pager $ photo $ roomNumber $ secretary $ uid $ userCertificate $ x500uniqueIdentifier $ preferredLanguage $ userSMIMECertificate $ userPKCS12 ) X-ORIGIN 'RFC 2798' )

dsconf prints separate MUST and MAY headings. Because employeeNumber is optional on inetOrgPerson, that object class appears under the MAY section. This lab still adds employeeBadgeNumber to demonstrate a controlled custom extension when your application needs a separate field.

Confirm the object class name is unused:

dsconf ldap1 schema objectclasses query glcEmployee

None

None means no glcEmployee definition is loaded yet.

Create a custom attribute type

Directory String syntax (1.3.6.1.4.1.1466.115.121.1.15) stores UTF-8 text and is appropriate for badge identifiers such as GLC-1001. Syntax alone does not define how equality searches compare values. You also need an EQUALITY matching rule when applications filter on the attribute or when you build an eq index.

List available syntax OIDs when you need integers, booleans, or distinguished names:

dsconf ldap1 schema attributetypes get_syntaxes

The command prints the full catalog; the Directory String line is Directory String (1.3.6.1.4.1.1466.115.121.1.15).

Add the attribute with caseIgnoreMatch for case-insensitive badge lookups. Use caseExactMatch instead when capitalization must be significant. Do not add a substring matching rule unless applications genuinely need partial badge searches:

dsconf ldap1 schema attributetypes add employeeBadgeNumber --oid 1.3.6.1.4.1.32473.1.1.1 --desc "Employee badge identifier" --syntax 1.3.6.1.4.1.1466.115.121.1.15 --equality caseIgnoreMatch --single-value --x-origin "GoLinuxCloud lab schema"

Successfully added the attributeType

Verify the definition:

dsconf ldap1 schema attributetypes query employeeBadgeNumber

( 1.3.6.1.4.1.32473.1.1.1 NAME 'employeeBadgeNumber' DESC 'Employee badge identifier' EQUALITY caseIgnoreMatch SYNTAX 1.3.6.1.4.1.1466.115.121.1.15 SINGLE-VALUE X-ORIGIN ( 'GoLinuxCloud lab schema' 'user defined' ) )

MUST

MAY

SINGLE-VALUE tells the server to reject a second value on the same entry. EQUALITY caseIgnoreMatch enables (employeeBadgeNumber=…) filters.

Create a custom object class

Define the auxiliary class after the attribute exists. Auxiliary classes extend entries without replacing their structural class:

dsconf ldap1 schema objectclasses add glcEmployee --oid 1.3.6.1.4.1.32473.1.2.1 --desc "GoLinuxCloud employee extension" --kind AUXILIARY --sup top --may employeeBadgeNumber --x-origin "GoLinuxCloud lab schema"

Successfully added the objectClass

Verify:

dsconf ldap1 schema objectclasses query glcEmployee

( 1.3.6.1.4.1.32473.1.2.1 NAME 'glcEmployee' DESC 'GoLinuxCloud employee extension' SUP top AUXILIARY MAY employeeBadgeNumber X-ORIGIN ( 'GoLinuxCloud lab schema' 'user defined' ) )

Schema changes made through dsconf are persisted in /etc/dirsrv/slapd-ldap1/schema/99user.ldif on the tested host. Interactive adds take effect immediately for new LDAP operations on this instance.

Apply the custom schema to an LDAP entry

I'll add the auxiliary class and attribute to an existing user with ldapmodify. The DN must match the stored entry. This lab uses ou=people (lowercase) as created by dsidm:

cat > /tmp/glc-user1.ldif << 'EOF'
dn: uid=user1,ou=people,dc=example,dc=com
changetype: modify
add: objectClass
objectClass: glcEmployee
-
add: employeeBadgeNumber
employeeBadgeNumber: GLC-1001
EOF

Apply the change over LDAPI as root:

ldapmodify -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -f /tmp/glc-user1.ldif

modifying entry "uid=user1,ou=people,dc=example,dc=com"

The operation completes without an LDAP error when the schema and DN are correct. Depending on the client options, ldapmodify may print only the entry being modified.

Confirm the entry with ldapsearch:

ldapsearch -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -b "uid=user1,ou=people,dc=example,dc=com" "(objectClass=*)" objectClass employeeBadgeNumber

# user1, people, example.com
dn: uid=user1,ou=people,dc=example,dc=com
objectClass: top
objectClass: nsPerson
objectClass: nsAccount
objectClass: nsOrgPerson
objectClass: posixAccount
objectClass: glcEmployee
employeeBadgeNumber: GLC-1001

# search result
search: 2
result: 0 Success

# numResponses: 2
# numEntries: 1

glcEmployee appears alongside the existing person classes, and the badge value is stored on the entry.

Search by badge number to confirm the equality rule works:

ldapsearch -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -b "ou=people,dc=example,dc=com" "(employeeBadgeNumber=GLC-1001)" dn employeeBadgeNumber

# user1, people, example.com
dn: uid=user1,ou=people,dc=example,dc=com
employeeBadgeNumber: GLC-1001

# search result
search: 2
result: 0 Success

# numResponses: 2
# numEntries: 1

The filter returns user1. That shows the custom field can be searched, not merely displayed.

EQUALITY caseIgnoreMatch defines how Directory Server compares badge values. It does not create a database index. Create an eq index separately only when the attribute is searched frequently enough to justify one. See index design and maintenance when that chapter is available. An equality matching rule is required to support equality filters and equality indexes, but the index itself is a separate backend configuration.

Test a schema violation

Attributes are permitted only when an entry's object classes allow them. Remove glcEmployee from the entry, then try to add the badge value alone:

cat > /tmp/glc-strip.ldif << 'EOF'
dn: uid=user1,ou=people,dc=example,dc=com
changetype: modify
delete: objectClass
objectClass: glcEmployee
-
delete: employeeBadgeNumber
employeeBadgeNumber: GLC-1001
EOF

I'll remove the auxiliary class and stored badge value so I can test schema enforcement on a plain user entry:

ldapmodify -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -f /tmp/glc-strip.ldif

Re-add only the attribute without the auxiliary class:

cat > /tmp/glc-bad-attr.ldif << 'EOF'
dn: uid=user1,ou=people,dc=example,dc=com
changetype: modify
add: employeeBadgeNumber
employeeBadgeNumber: GLC-1001
EOF

This modify should fail because employeeBadgeNumber is not allowed until glcEmployee is present on the entry:

ldapmodify -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -f /tmp/glc-bad-attr.ldif

ldap_modify: Object class violation (65)
	additional info: attribute "employeeBadgeNumber" not allowed
modifying entry "uid=user1,ou=people,dc=example,dc=com"

The server rejects the attribute because no object class on the entry permits employeeBadgeNumber. Restore the working combination before you continue:

ldapmodify -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -f /tmp/glc-user1.ldif

Add a second badge value to see single-value enforcement:

cat > /tmp/glc-dup.ldif << 'EOF'
dn: uid=user1,ou=people,dc=example,dc=com
changetype: modify
add: employeeBadgeNumber
employeeBadgeNumber: GLC-2002
EOF

Directory Server should reject a second value because the attribute is marked SINGLE-VALUE:

ldapmodify -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -f /tmp/glc-dup.ldif

ldap_modify: Object class violation (65)
	additional info: single-valued attribute "employeeBadgeNumber" has multiple values

modifying entry "uid=user1,ou=people,dc=example,dc=com"

For deeper syntax checking across many entries, use schema validation and repair. This guide stops at one illustrative modify failure.

Update or remove custom schema definitions

dsconf schema exposes matching command families for maintenance:

dsconf schema attributetypes replace
dsconf schema attributetypes remove
dsconf schema objectclasses replace
dsconf schema objectclasses remove

Follow this order when you retire a custom extension:

1. Stop using the attribute in directory entries. Remove values and auxiliary classes from affected entries.
2. Remove the attribute from dependent object-class MUST and MAY lists (or delete the object class).
3. Update or remove the object-class definition.
4. Remove the attribute-type definition.

The server blocks removal while schema elements still reference each other. Removing employeeBadgeNumber while glcEmployee still lists it in MAY fails:

dsconf ldap1 schema attributetypes remove employeeBadgeNumber

Error: Server is unwilling to perform(53) - attribute type employeebadgenumber: Is included in the MAY list for object class glcEmployee.  Cannot delete.

After you clear entry data, remove the auxiliary class and attribute from user1:

cat > /tmp/glc-cleanup-user.ldif << 'EOF'
dn: uid=user1,ou=people,dc=example,dc=com
changetype: modify
delete: employeeBadgeNumber
-
delete: objectClass
objectClass: glcEmployee
EOF

Clear the badge value and auxiliary class from user1 before I remove the schema definitions:

ldapmodify -Y EXTERNAL -H ldapi://%2Fvar%2Frun%2Fslapd-ldap1.socket -f /tmp/glc-cleanup-user.ldif

Remove the schema definitions in dependency order:

dsconf ldap1 schema objectclasses remove glcEmployee

Successfully removed the objectClass

After the object class is gone, I can remove the attribute type it referenced:

dsconf ldap1 schema attributetypes remove employeeBadgeNumber

Successfully removed the attributetype

Confirm both definitions are gone:

dsconf ldap1 schema objectclasses query glcEmployee

None

The attribute query should also fail once the definition has been removed:

dsconf ldap1 schema attributetypes query employeeBadgeNumber

Error: 'NoneType' object has no attribute 'names'

Do not delete schema definitions that entries still use. Clear entry data first, then shrink the schema.

Create a reusable custom schema file

The previous cleanup removed these definitions from 99user.ldif. The following file therefore becomes their only managed schema source on this lab instance.

Schema changes made through dsconf are persisted in 99user.ldif. The server can rewrite schema data in that file; treat it as the live store for interactive changes, not a simple append-only log.

For repeatable deployments across several instances, maintain a separate file under the instance schema directory:

/etc/dirsrv/slapd-ldap1/schema/99glc-custom.ldif

Directory Server loads schema files alphabetically. A custom filename must begin with two digits and sort before 99user.ldif. Use a name that also loads after every schema file containing definitions on which your custom schema depends. In this lab, 99glc-custom.ldif loads after the distribution schema files and before 99user.ldif.

Keep custom definitions in your own numeric prefix and leave distribution-managed files untouched. The file begins with the schema entry DN and carries RFC 4512 definitions:

dn: cn=schema
attributeTypes: ( 1.3.6.1.4.1.32473.1.1.1 NAME 'employeeBadgeNumber' DESC 'Employee badge identifier' EQUALITY caseIgnoreMatch SYNTAX 1.3.6.1.4.1.1466.115.121.1.15 SINGLE-VALUE X-ORIGIN 'GoLinuxCloud lab schema' )
objectClasses: ( 1.3.6.1.4.1.32473.1.2.1 NAME 'glcEmployee' DESC 'GoLinuxCloud employee extension' SUP top AUXILIARY MAY employeeBadgeNumber X-ORIGIN 'GoLinuxCloud lab schema' )

Define the attribute before the object class that references it. You can publish the same file through configuration management to every supplier before entries that depend on the schema are written.

Directory Server accepts custom schema through dsconf, the web console, or manually maintained LDIF files. The method should match how your team versions infrastructure.

Reload and verify schema files

After you edit schema LDIF on disk, reload the running server and wait for the task to finish:

dsconf ldap1 schema reload --wait

Attempting to add task entry... This will fail if Schema Reload plug-in is not enabled.
Schema reload task (cn=schema_reload_2026-07-15T16:24:29.356062,cn=schema reload task,cn=tasks,cn=config) successfully finished.

--wait blocks until the reload task completes instead of returning while the asynchronous job is still running. If the Schema Reload plug-in is disabled, the task fails. Enable the plug-in before you rely on file-based updates, and check the instance error log when a reload does not finish.

Confirm the definitions are visible to clients:

dsconf ldap1 schema attributetypes query employeeBadgeNumber

I'll query the auxiliary object class as well to confirm the file reload picked up both definitions:

dsconf ldap1 schema objectclasses query glcEmployee

Both commands should print the employeeBadgeNumber and glcEmployee definitions after reload. If ldapmodify reports unknown object class immediately after a file-only change, run dsconf INSTANCE schema reload --wait before retrying the modify.

Maintain schema across replicated servers

Schema added through dsconf is persisted in 99user.ldif with an nsSchemaCSN. Directory Server does not send the change immediately. When the next data update is replicated, the supplier compares schema CSNs and can transfer its compatible schema before sending entries that depend on it.

For reliable schema management, choose one approach:

• Manage the schema through dsconf and 99user.ldif, allowing compatible schema updates to propagate through replication.
• Maintain a separate file such as 99glc-custom.ldif, deploy the identical file to every server, and reload it everywhere before writing dependent entries.

Schema definitions kept outside 99user.ldif remain local files and should be deployed consistently to every applicable server; only 99user.ldif participates in normal schema-CSN-based automatic propagation.

Files other than 99user.ldif remain local and are not automatically copied to replication partners. Automatic schema propagation requires every relevant attribute type and object class on the supplier to be a compatible superset of the corresponding definition on the consumer. If the supplier definition is a subset, or the two definitions would need to be merged, Directory Server does not automatically propagate the schema. Avoid making independent, conflicting schema changes on different suppliers.

Confirm schema parity on every supplier before production writes when you add custom attributes that clients depend on. Supplier and consumer configuration lives in replication overview and the dedicated replication chapters. Schema mismatch between peers often appears as replication errors or object class violation on the consumer. Compare dsconf schema output on each supplier when that happens.

Troubleshoot custom schema errors

Summary

1. Reuse standard schema whenever an existing attribute such as employeeNumber fits the requirement.
2. Allocate unique OIDs from your organization's PEN branch, or RFC 5612 32473 for documentation labs only.
3. Define the attribute type with syntax and equality matching before the object class that references it.
4. Prefer an auxiliary class when you extend existing person entries.
5. Test adds, equality searches, and intentional violations on sample entries before production rollout.
6. Keep schema definitions consistent on every supplier that will hold or replicate the data.
