Create Virtual Directory Views in 389 Directory Server

Create virtual directory tree views in 389 Directory Server with nsView and nsViewFilter, nested filters, LDAP search verification, indexing, limitations, and troubleshooting.

Published

Updated

Read time 11 min read

Reviewed byDeepak Prasad

389 Directory Server virtual directory view with nsViewFilter selecting users from a flat physical DIT into a department hierarchy

A physical directory tree stores each entry in one place. When managers browse by department, location, or employment type, a flat ou=People subtree forces every application to build its own filters instead of navigating folders.

text
dc=example,dc=com
└── ou=People
    ├── uid=user1
    ├── uid=user2
    └── uid=user3

Virtual directory views solve that layout problem. A view entry carries the nsView object class and an nsViewFilter attribute. Clients that search from the view DN see matching users grouped under ou=Views even though those users remain under ou=people in the physical DIT. The same user can appear in several views when several filters match.

Before you start:

IMPORTANT
This guide covers virtual DIT views built with nsView and nsViewFilter. It does not cover suffix and backend creation, generic LDAP filter tutorials, full index management, roles or Class of Service configuration, or Virtual List View (VLV) controls. VLV is an unrelated paging feature.

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

How virtual directory views work

A view is a normal directory entry, often an organizationalUnit, with the auxiliary nsView object class and, on leaf views, an nsViewFilter LDAP filter.

Component Purpose
nsView Marks an entry as part of a virtual hierarchy
nsViewFilter Selects which physical entries appear through this view
View entry Acts as the LDAP search base for the virtual subtree
Nested view Adds another filter below a parent view
Physical entry Stays at its original DN; the view does not move it
text
Search base: ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com
                           |
                           v
nsViewFilter: (departmentNumber=Engineering)
                           |
                           v
Matching users returned from ou=people (real DNs preserved)

Directory Server evaluates view filters against the physical tree. The views plug-in must be enabled. It is on by default in 3.2.0. View processing runs only when the client search base is inside a view hierarchy. Searching dc=example,dc=com alone does not surface virtual groupings.

Views vs physical directory containers

Physical OU Virtual view
Entry DN determines placement Entry attributes determine placement
Moving an entry changes its DN Changing an attribute changes view membership
Entry has one physical location Entry can appear in several views
Child entries are stored below the OU Matching entries remain elsewhere in the DIT

Views do not create duplicate user entries. A search through ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com returns uid=user1,ou=people,dc=example,dc=com. That is the physical DN, not a copy under the view branch.

Plan the virtual hierarchy

This lab keeps users in ou=people and builds department views under ou=Views:

text
dc=example,dc=com
├── ou=People
│   ├── uid=user1  [departmentNumber=Engineering, employeeType=employee]
│   ├── uid=user2  [departmentNumber=Engineering, employeeType=contractor]
│   └── uid=user3  [departmentNumber=Sales, employeeType=employee]
└── ou=Views
    └── ou=Departments
        ├── ou=Engineering
        │   └── ou=Contractors   (nested view)
        └── ou=Sales

Confirm the filter attributes exist on the target entries before you create views with ldapsearch:

bash
ldapsearch -LLL -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=people,dc=example,dc=com" "(uid=user*)" dn departmentNumber employeeType

Sample output:

output
dn: uid=user1,ou=people,dc=example,dc=com
departmentNumber: Engineering
employeeType: employee

dn: uid=user2,ou=people,dc=example,dc=com
departmentNumber: Engineering
employeeType: contractor

dn: uid=user3,ou=people,dc=example,dc=com
departmentNumber: Sales
employeeType: employee

Users created with dsidm in this lab carry nsOrgPerson, not inetOrgPerson. Match nsViewFilter to attributes and object classes that actually exist on the entries, or use attribute-only filters such as (departmentNumber=Engineering).

Create the parent view containers

Parent containers in a view tree also need the nsView object class, even when they do not define an nsViewFilter. The shipped Example-views.ldif follows that pattern for ou=Location Views and similar branches.

I'll write the parent containers to a file:

bash
cat > /tmp/views-parents.ldif <<'EOF'
dn: ou=Views,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
objectClass: nsView
ou: Views
description: Virtual directory view containers

dn: ou=Departments,ou=Views,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
objectClass: nsView
ou: Departments
description: Department-based virtual views
EOF

Add both entries with ldapadd:

bash
ldapadd -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/views-parents.ldif

Sample output:

output
adding new entry "ou=Views,dc=example,dc=com"

adding new entry "ou=Departments,ou=Views,dc=example,dc=com"

Both parent containers now carry nsView, which nested views require on every ancestor in the chain.

Create a filtered view

I'll create the Engineering department view with a filter on departmentNumber:

bash
cat > /tmp/engineering-view.ldif <<'EOF'
dn: ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
objectClass: nsView
ou: Engineering
description: Engineering department view
nsViewFilter: (departmentNumber=Engineering)
EOF

Add the Engineering view:

bash
ldapadd -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/engineering-view.ldif

Sample output:

output
adding new entry "ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com"

Add the Sales view with the same object classes and a different filter:

bash
cat > /tmp/sales-view.ldif <<'EOF'
dn: ou=Sales,ou=Departments,ou=Views,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
objectClass: nsView
ou: Sales
description: Sales department view
nsViewFilter: (departmentNumber=Sales)
EOF

Load the Sales view, then add the entry:

bash
ldapadd -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/sales-view.ldif

Sample output:

output
adding new entry "ou=Sales,ou=Departments,ou=Views,dc=example,dc=com"

Search entries through a view

Use the view DN as the search base. Returned DNs point at the physical location under ou=people:

bash
ldapsearch -LLL -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com" -s sub "(objectClass=nsOrgPerson)" dn uid departmentNumber

Sample output:

output
dn: uid=user1,ou=people,dc=example,dc=com
uid: user1
departmentNumber: Engineering

dn: uid=user2,ou=people,dc=example,dc=com
uid: user2
departmentNumber: Engineering

The DNs remain under ou=people. The view only changes how clients discover those entries. A subtree search from dc=example,dc=com does not present this virtual hierarchy. You must search from the view branch.

If you filter on inetOrgPerson while entries carry only nsOrgPerson, the view search returns no users even when departmentNumber matches. Align the client filter with the stored object classes or search with (uid=*) when verifying membership.

Create nested views

I'll add a child view under Engineering for contractors. The child filter combines with every ancestor nsViewFilter, so the effective selection is conceptually (&(departmentNumber=Engineering)(employeeType=contractor)).

bash
cat > /tmp/contractors-view.ldif <<'EOF'
dn: ou=Contractors,ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com
objectClass: top
objectClass: organizationalUnit
objectClass: nsView
ou: Contractors
description: Engineering contractors
nsViewFilter: (employeeType=contractor)
EOF

Add the nested view:

bash
ldapadd -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/contractors-view.ldif

Sample output:

output
adding new entry "ou=Contractors,ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com"

Search from the nested view base:

bash
ldapsearch -LLL -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=Contractors,ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com" -s sub "(uid=*)" dn employeeType departmentNumber

Sample output:

output
dn: uid=user2,ou=people,dc=example,dc=com
employeeType: contractor
departmentNumber: Engineering

Only user2 matches both the Engineering parent filter and the contractor child filter.

Update view membership

View membership follows attribute values. Change a user department and the entry moves between views without a DN change.

I'll modify user2 from Engineering to Sales:

bash
ldapmodify -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw <<'EOF'
dn: uid=user2,ou=people,dc=example,dc=com
changetype: modify
replace: departmentNumber
departmentNumber: Sales
EOF

Confirm the user no longer appears under Engineering:

bash
ldapsearch -LLL -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com" -s sub "(uid=user2)" dn

An empty result means the Engineering view no longer lists user2.

Search the Sales view:

bash
ldapsearch -LLL -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=Sales,ou=Departments,ou=Views,dc=example,dc=com" -s sub "(uid=user2)" dn departmentNumber

Sample output:

output
dn: uid=user2,ou=people,dc=example,dc=com
departmentNumber: Sales

The physical DN is unchanged; only view membership moved with the attribute update.

Index attributes used by views

View searches rely on operational attributes entryid and parentid, plus every attribute referenced in nsViewFilter. Missing indexes can force partially unindexed scans.

List existing indexes on the userroot backend:

bash
dsconf ldap1 backend index list userroot

Add an equality index for departmentNumber when your views filter on that attribute:

bash
dsconf ldap1 backend index add --attr departmentNumber --index-type eq userroot

Add an equality index for entryid when it is not already present:

bash
dsconf ldap1 backend index add --attr entryid --index-type eq userroot

Reindex the backend after adding indexes:

bash
dsconf ldap1 backend index reindex userroot --wait

Match the index type to the filter operator:

Filter pattern Suggested index
(attribute=value) Equality (eq)
(attribute=*) Presence (pres)
(attribute=value*) Substring (sub)
(attribute~=value) Approximate (approx)

parentid is indexed by default. For nested views that filter on employeeType, add an equality index for that attribute as well. Full index planning belongs in the dedicated indexing chapter.

Check whether a view search is indexed

Run the equivalent filter against the physical suffix and read the access log on instance ldap1:

bash
ldapsearch -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "dc=example,dc=com" "(departmentNumber=Engineering)" dn >/dev/null

Inspect the latest search result line:

bash
tail -3 /var/log/dirsrv/slapd-ldap1/access | grep RESULT

Sample output:

output
[15/Jul/2026:18:32:39 +0530] conn=800 op=1 RESULT err=0 tag=101 nentries=3 wtime=0.000396511 optime=0.002996513 etime=0.003389623 notes=U details="Partially Unindexed Filter"

notes=U with Partially Unindexed Filter means Directory Server could not use indexes for part of the filter and may scan a large portion of the backend. Add the missing indexes, reindex, and repeat the search until the note disappears or the remaining cost is acceptable for your data size.

Understand view limitations

Keep these constraints in mind when you design client integrations:

  • A view search is limited to one backend. All returned entries must live in the same suffix and backend as the view container.
  • Clients must use the view DN as the search base; the virtual hierarchy does not appear when browsing only the physical tree.
  • Returned entries keep their real DNs. Applications that walk up the DN by stripping components may not match view navigation expectations.
  • numSubordinates on a view entry may not reflect virtual children the way a physical OU would.
  • Prefer stable, administrator-controlled attributes in nsViewFilter. Frequently changing or multi-valued attributes make membership harder to predict.

Views require careful access-control design. Directory Server does not provide explicit view-specific ACL handling. When permissions must follow a virtual hierarchy, Red Hat recommends using role-based access control at the view parent and assigning roles to the appropriate parts of the view tree. Test access using the same search base and bind identities that applications will use.

IMPORTANT
A view cannot combine entries from separate backends. If ou=People and another subtree live in different backends, one view hierarchy cannot present both. Plan separate view trees per backend or keep related entries under one suffix.

Views with roles and Class of Service

Roles and Class of Service can be defined within a view hierarchy. Entries that are both logically included by the view and physically within the applicable scope are affected. The resulting role assignments or CoS-generated values can also be visible when clients query the same entries through the flat physical DIT. This guide does not configure those features. See roles vs groups and Class of Service when you need managed roles or virtual attributes alongside views.

Modify or remove a view

To change membership rules, update nsViewFilter with ldapmodify:

bash
ldapmodify -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw <<'EOF'
dn: ou=Engineering,ou=Departments,ou=Views,dc=example,dc=com
changetype: modify
replace: nsViewFilter
nsViewFilter: (departmentNumber=Eng)
EOF

Search the view again to confirm the new membership. Delete child views before removing a parent view when nested branches exist. Removing a view entry does not delete the physical users displayed through it. It only removes the virtual grouping.

Remove an index only after you confirm no other filter or application still needs that attribute on the backend.

Troubleshoot virtual directory views

Symptom Likely cause Fix
View returns no user entries Parent container missing nsView, wrong filter syntax, or filter uses object class or attributes the entries do not carry Add objectClass: nsView on every ancestor view container; test nsViewFilter with a physical-DIT ldapsearch under the suffix
Only child view entries appear Client filter excludes target object class, or one-level search at a parent that delegates members to child views Use subtree scope from the leaf view DN; match filters to nsOrgPerson or attribute-only tests
Entries from another backend missing View cannot span backends Keep all filtered entries in the same backend and suffix
Wrong entries appear nsViewFilter too broad or typo in attribute value Test the filter directly: ldapsearch -b dc=example,dc=com "(your-filter)"
Search is slow Missing entryid, parentid, or filter-attribute indexes Add indexes with dsconf ldap1 backend index add, reindex, and recheck the access log for notes=U
View works in ldapsearch but not in an application Application search base still points at the physical OU, or the app relies on DN traversal or numSubordinates Point the app base DN at the view entry and test navigation behaviour

Summary

  1. Virtual views group existing entries by attribute filter without moving or copying them.
  2. nsView marks view containers; nsViewFilter on leaf views selects members from the physical DIT.
  3. Nested views combine parent and child filters into one effective selection.
  4. Clients must search from the view DN; returned entries keep their real DNs under ou=people.
  5. All entries in a view must reside in the same backend. Views cannot span backends.
  6. Index entryid, parentid, and every attribute used in nsViewFilter to avoid partially unindexed scans.

What's Next

References

Frequently Asked Questions

1. What is the difference between virtual DIT views and Virtual List View in 389 Directory Server?

Virtual DIT views use nsView entries and nsViewFilter to present a virtual hierarchy over existing entries. Virtual List View (VLV) is a separate paged-search control for large result sets. They solve different problems and are not interchangeable.

2. Can a view return entries from multiple backends?

No. A view search is limited to one backend. Every entry returned through a view must reside under the same suffix and backend as the view container.

3. Do virtual views duplicate LDAP entries in the DIT?

No. Views select existing entries by attribute filter. The server returns the real entry DN; nothing is copied or moved under the view container.

4. Why does my view return only child view entries and no users?

Check that every ancestor container in the view tree carries the nsView object class, that nsViewFilter matches attributes stored on the target entries, and that entryid and filter attributes are indexed. Parent OUs without nsView break nested view resolution.

5. What happens when I change an attribute used in nsViewFilter?

View membership updates immediately. The entry appears in views whose combined filters match the new attribute values and disappears from views that no longer match, without changing the entry physical DN.
Deepak Prasad

R&D Engineer

Founder of GoLinuxCloud with more than 15 years of expertise in Linux, Python, Go, Laravel, DevOps, Kubernetes, Git, Shell scripting, OpenShift, AWS, Networking, and Security. With extensive …

Related Articles

system-administration

Disable, Reactivate, and Automatically Inactivate User Accounts in 389 Directory Server

Disable and reactivate LDAP user accounts in 389 Directory Server with dsidm account lock, nsAccountLock, role …

17 min readsystem-administration

Configure Account Lockout in 389 Directory Server

Enable password-based account lockout in 389 Directory Server, set failure thresholds and unlock behaviour, …

14 min readsystem-administration

Configure Global, Subtree and User Password Policies in 389 Directory Server

Configure global, subtree, and user password policies in 389 Directory Server with dsconf pwpolicy and …

22 min read
