Create and Manage Suffixes and Backends in 389 Directory Server

One 389 Directory Server instance can host multiple directory trees. Each suffix is the root DN of a subtree. That suffix maps to a backend that logically owns the entries and indexes for that namespace inside the instance's LMDB environment.

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

Directory suffix
dc=example,dc=com
        |
        v
Backend name
userroot
        |
        v
Instance-wide LMDB environment
(data.mdb, INFO.mdb, lock.mdb)

The suffix DN and backend name are different values. Commands such as dsconf ldap1 backend suffix get userroot use the backend name; LDAP clients bind and search using the suffix DN. The instance name (ldap1) selects which server you talk to. That third identifier is easy to confuse with suffix and backend when several instances run on one host.

Before you start:

• Install 389 Directory Server — a running instance with dsconf access (lab instance: ldap1)
• 389 Directory Server architecture — suffix vs instance vs backend terminology
• Directory Manager credentials in a protected password file (chmod 600 /root/dm.pw) or use -W to prompt at the terminal
• Optional: dsconf commands cheat sheet — flag reference for dsconf backend subcommands

OpenLDAP client tools read a password file with -y PATH. The -w flag takes the literal password string on the command line, not a file path. I'll set mode 600 on /root/dm.pw with the chmod command before I bind:

chmod 600 /root/dm.pw

Understand suffixes, backends, and databases

Three layers appear in almost every suffix operation:

On the tested LMDB instance, all backends use the instance-wide LMDB environment under /var/lib/dirsrv/slapd-ldap1/db/. The principal files are data.mdb, INFO.mdb, and lock.mdb. Backend names still separate directory data logically and allow per-backend export, import, indexing, cache, and replication configuration. Older Berkeley DB deployments use a different on-disk layout.

dscreate provisions the first backend when you install an instance. Everything in this guide adds more suffixes inside the same ns-slapd process with dsconf backend create.

Per-backend vs instance-wide operations

Root suffix, sub-suffix, or another instance?

All suffixes and backends inside one instance share the same ns-slapd process, listeners, Directory Manager, global schema, plug-ins, TLS configuration, and server-level settings. Separate backends isolate directory data and backend-specific operations; create another instance when those server-level settings must differ.

A backend without a suffix entry is only half-provisioned: dsconf backend suffix list may show the suffix DN, but ldapsearch returns No such object until you create the root entry with --create-suffix or ldapadd.

Inspect existing suffixes and backends

List suffix DNs and backend names for the instance:

dsconf ldap1 backend suffix list

Sample output:

dc=example,dc=com (userroot)

The suffix DN appears first; the backend name is in parentheses. This lab starts with one root suffix before you add more.

Inspect one backend:

dsconf ldap1 backend suffix get userroot

Sample output:

dn: cn=userroot,cn=ldbm database,cn=plugins,cn=config
nsslapd-cachememsize: 939524096
nsslapd-cachesize: -1
nsslapd-dncachememsize: 134217728
nsslapd-readonly: off
nsslapd-require-index: off
nsslapd-state: backend
nsslapd-suffix: dc=example,dc=com

nsslapd-suffix is the LDAP namespace; cn=userroot in the DN is the backend configuration entry, not the same string. The cache sizes are per-backend; tuning them is covered in the LMDB tuning chapter.

Show the suffix hierarchy when sub-suffixes exist:

dsconf ldap1 backend get-tree

Sample output with one root suffix:

- dc=example,dc=com

After you add backends later in this guide, this command indents sub-suffixes under their parent. Use it before creating a sub-suffix to confirm the parent DN exists and is spelled correctly.

Plan an additional root suffix

Pick a suffix DN and backend name before you run dsconf. Backend names must be unique within the instance; suffix DNs must not overlap with an existing tree unless you intend a sub-suffix with --parent-suffix.

A separate root suffix helps when you need:

• An independent application directory namespace
• Different access policies or ACIs at the tree root
• Separate export, import, indexing, replication, and maintenance boundaries
• Data that should not live under the existing suffix

This adds a tree inside the same instance. It is not the same as running another instance on the host. Applications connect to the same LDAP port; they choose the correct suffix DN or naming context in their search base.

Create a root suffix and backend

dsconf backend create registers the backend in cn=config, creates the mapping tree entry, and adds the suffix to the instance LMDB environment under /var/lib/dirsrv/slapd-ldap1/db/. With --create-suffix, it also adds the root LDAP object so clients can search immediately.

I'll create the backend, suffix configuration, and root domain entry in one step:

dsconf ldap1 backend create --suffix="dc=application,dc=example" --be-name="applicationroot" --create-suffix

Sample output:

The database was sucessfully created

Flag roles:

• --suffix — LDAP namespace (root DN)
• --be-name — unique backend name for dsconf commands
• --create-suffix — creates the suffix root entry (domain object for dc= suffixes)

Confirm the new suffix appears:

dsconf ldap1 backend suffix list

Sample output:

dc=application,dc=example (applicationroot)
dc=example,dc=com (userroot)

dsconf lists backend names in lowercase in parentheses. Use the same lowercase name in dsconf commands for consistency. The new suffix is live immediately. No instance restart is required for backend creation on a running server.

Create the suffix entry manually

Backend configuration and the suffix LDAP entry are separate steps when you omit --create-suffix. Use this path when:

• The suffix root needs an object class --create-suffix does not handle
• You are importing a prepared LDIF as part of a migration
• You want to review backend registration before adding directory data

Create only the backend:

dsconf ldap1 backend create --suffix="dc=manual,dc=example" --be-name="manualroot"

Sample output:

The database was sucessfully created

Add the root entry with LDIF:

cat > /tmp/manual-suffix.ldif <<'EOF'
dn: dc=manual,dc=example
objectClass: top
objectClass: domain
dc: manual
EOF

Import the suffix entry with ldapadd:

ldapadd -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/manual-suffix.ldif

Sample output:

adding new entry "dc=manual,dc=example"

--create-suffix supports common RDN types (dc, o, ou, cn, c). Suffix roots that need a different object class must be created manually like this. Until ldapadd succeeds, the backend exists in configuration but the namespace is empty for LDAP clients.

Verify the new root suffix

Confirm both automated and manual suffixes are registered:

dsconf ldap1 backend suffix list

Sample output after creating applicationroot and manualroot:

dc=application,dc=example (applicationroot)
dc=example,dc=com (userroot)
dc=manual,dc=example (manualroot)

Three lines mean three backends. Each suffix DN maps to its own database even though all share the same instance and LDAP port.

Search the new suffix base entry with ldapsearch:

ldapsearch -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "dc=application,dc=example" -s base

Sample output:

dn: dc=application,dc=example
objectClass: top
objectClass: domain
dc: application
description: dc=application,dc=example

The domain object class and dc attribute confirm --create-suffix created a searchable root entry, not just backend metadata.

Read advertised naming contexts from the root DSE:

ldapsearch -x -H ldap://127.0.0.1:389 -b "" -s base namingContexts

Sample output:

dn:
namingContexts: dc=application,dc=example
namingContexts: dc=example,dc=com
namingContexts: dc=manual,dc=example

Each root suffix is listed. Sub-suffixes remain part of their parent naming context and do not appear as separate namingContexts values. Clients discover ou=Archive,dc=example,dc=com by searching under dc=example,dc=com, not from an extra root DSE line.

Create a sub-suffix in a separate backend

By default, every entry under dc=example,dc=com lives in the userroot backend. A sub-suffix creates a new backend and mapping-tree entry for a branch. It does not migrate an existing subtree from the parent backend.

This guide uses an unused branch so it does not conflict with the install lab:

Common reasons to split a branch:

• Large ou=People or ou=Groups trees that need separate export/import or reindexing
• Different index or cache policy on one branch
• Replication that should cover only part of the tree (configured in later chapters)

Store a branch in its own backend while keeping one DIT path for clients:

dc=example,dc=com
└── ou=Archive,dc=example,dc=com
    stored in a separate backend

I'll create the sub-suffix:

dsconf ldap1 backend create --suffix="ou=Archive,dc=example,dc=com" --be-name="archiveroot" --parent-suffix="dc=example,dc=com" --create-suffix

Sample output:

The database was sucessfully created

--parent-suffix links the sub-suffix to the existing tree. --create-suffix creates the new branch root entry; it does not relocate entries that already live under userroot. The parent suffix must already exist. dsconf does not create dc=example,dc=com when you add a sub-suffix.

View the hierarchy:

dsconf ldap1 backend get-tree

Sample output:

- dc=application,dc=example
 - dc=example,dc=com
   - ou=archive,dc=example,dc=com

The indented line shows the parent/child relationship in the mapping tree. LDAP is case-insensitive for DN matching; the list may lowercase the attribute value even when you created ou=Archive.

Sub-suffixes can have their own export/import, indexing, cache, and replication configuration. Instance-wide backup commands such as dsconf backup create and dsctl db2bak still cover all backends in the instance.

Verify the sub-suffix entry with an authenticated search so ACIs cannot mask a missing branch root:

ldapsearch -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=Archive,dc=example,dc=com" -s base dn

Sample output:

dn: ou=Archive,dc=example,dc=com

# numEntries: 1

One entry at the sub-suffix DN confirms the branch root exists. New entries you add under this OU land in the archiveroot database, not userroot.

Configure the default naming context

When multiple root suffixes exist, some clients read the root DSE instead of a configured search base. nsslapd-defaultnamingcontext tells those clients which suffix to prefer.

Set this only when:

• Several root suffixes are advertised and a client should default to one of them
• Legacy applications expect a single primary naming context

Well-configured applications pass an explicit base DN and may ignore this setting.

Read the current value:

dsconf ldap1 config get nsslapd-defaultnamingcontext

Sample output:

nsslapd-defaultnamingcontext: dc=example,dc=com

Change it when a different root suffix should be preferred:

dsconf ldap1 config replace nsslapd-defaultnamingcontext=dc=application,dc=example

Sample output:

Successfully replaced value(s) for 'nsslapd-defaultnamingcontext': 'dc=application,dc=example'

Clients that read the root DSE can discover nsslapd-defaultnamingcontext when they do not already know which base DN to use. The change takes effect without restarting ns-slapd. Restore the original value in the lab when you finish:

dsconf ldap1 config replace nsslapd-defaultnamingcontext=dc=example,dc=com

Manage backend state

Use backend state controls during maintenance, not as a long-term security boundary. Read-only and disabled modes affect one backend; other suffixes in the same instance keep serving requests.

Read-only mode

Read-only keeps searches available but rejects normal modifications:

dsconf ldap1 backend suffix set --enable-readonly applicationroot

Sample output:

The backend configuration was successfully updated

Try a modify against the suffix:

ldapmodify -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw <<'EOF'
dn: dc=application,dc=example
changetype: modify
replace: description
description: readonly test
EOF

Sample output:

ldap_modify: Server is unwilling to perform (53)
additional info: database is read-only
modifying entry "dc=application,dc=example"

Searches still work; only writes are blocked. Clear read-only mode:

dsconf ldap1 backend suffix set --disable-readonly applicationroot

Do not place a replicated backend into read-only mode without planning the impact. Red Hat documents that enabling database read-only mode disables replication for that backend.

Disable and enable

Disable takes the backend offline for LDAP clients. Use it when you need the suffix completely unavailable, not just protected from writes.

dsconf ldap1 backend suffix set --disable applicationroot

Sample output:

The backend configuration was successfully updated

Verify that the suffix is unavailable with an authenticated base search:

ldapsearch -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "dc=application,dc=example" -s base dn

Sample output:

ldap_search_ext: Operations error (1)

--disable makes the selected suffix unavailable to LDAP clients without stopping the other backends in the instance. Authenticate the verification search so a failure reflects backend state rather than anonymous-access policy. --disable and --enable are the supported controls for making a selected backend unavailable or available.

Re-enable the backend:

dsconf ldap1 backend suffix set --enable applicationroot

Confirm the authenticated base search succeeds again:

ldapsearch -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "dc=application,dc=example" -s base dn

Sample output:

dn: dc=application,dc=example

# numEntries: 1

Cache sizing and index design belong in the dedicated indexing and LMDB tuning chapters, not here.

Safely delete a suffix and backend

dsconf backend delete removes the backend configuration, its mapping-tree entry, and all directory data and indexes belonging to that backend from the shared LMDB environment. It does not uninstall the instance or remove unrelated backends. The steps below use applicationroot from earlier in this guide; the same workflow applies to any backend you plan to retire.

Check sub-suffixes and dependencies

Confirm the backend name and review the mapping tree before you export or delete anything. Deleting a parent backend can remove child sub-suffix backends when --do-it runs.

List every suffix and backend on the instance:

dsconf ldap1 backend suffix list

Sample output before deleting applicationroot:

dc=application,dc=example (applicationroot)
dc=example,dc=com (userroot)
dc=manual,dc=example (manualroot)
ou=archive,dc=example,dc=com (archiveroot)

Show parent and child relationships:

dsconf ldap1 backend get-tree

Sample output:

- dc=application,dc=example
 - dc=manual,dc=example
 - dc=example,dc=com
   - ou=archive,dc=example,dc=com

applicationroot and manualroot are root suffixes with no indented children. archiveroot is a sub-suffix under userroot. Deleting userroot would also remove archiveroot, but deleting applicationroot does not affect the other backends.

Export or back up the backend

Export the backend to LDIF when you need a suffix-specific recovery file before removal. The export path must be writable by the dirsrv user. The instance ldif directory is a reliable choice:

dsconf ldap1 backend export applicationroot -l /var/lib/dirsrv/slapd-ldap1/ldif/applicationroot-export.ldif

Sample output:

The export task has finished successfully

The LDIF file contains every entry stored in that backend, including the suffix root object.

An LDIF export preserves directory entries, but it is not a complete copy of the backend configuration. It does not preserve backend cache settings, index definitions, replication configuration, or other settings stored under cn=config. To recover after deleting the backend, recreate the backend with the same suffix, import the LDIF, and then restore any backend-specific indexes and replication settings.

For whole-instance recovery, use backup and restore instead of, or in addition to, a per-backend export.

Remove replication and application dependencies

List suffixes for which replication is enabled:

dsconf ldap1 replication list

This command lists suffixes for which replication is enabled. It does not list individual replication agreements.

A lab instance with no replicated suffixes returns:

There are no replicated suffixes

When the suffix you plan to delete appears in that list, inspect its local agreements:

dsconf ldap1 repl-agmt list --suffix="dc=application,dc=example"

Before deleting the backend, remove the suffix from the replication topology. First remove or reconfigure agreements on other servers that point to this replica. Then disable replication locally:

dsconf ldap1 replication disable --suffix="dc=application,dc=example"

Disabling replication removes the replica configuration and local replication agreements for that suffix. In a multi-server topology, also remove agreements on remote suppliers that still target this server before deleting the backend.

Replication design is covered in later tutorial chapters. Also confirm applications, ACIs, and automation no longer depend on the suffix DN. If you changed nsslapd-defaultnamingcontext to point at the suffix being removed, set it to a remaining root suffix first. See Configure the default naming context earlier in this guide.

Delete the backend

The command refuses to delete anything unless you add the mandatory --do-it safety flag:

dsconf ldap1 backend delete applicationroot

Sample output:

Not removing backend: if you are really sure add: --do-it

Without --do-it, the command acts as a safety gate and refuses deletion. The output does not inspect or validate dependencies for you.

Before adding --do-it, verify the instance, backend name, suffix DN, sub-suffix hierarchy, export file, default naming context, and replication configuration.

On the tested Rocky Linux 10.2 package, deletion with --do-it also prompts for explicit confirmation. Check dsconf ldap1 backend delete -h on other versions before scripting deletion.

Add --do-it only when you intend to destroy that backend and all of its data. Run the command interactively and type Yes I am sure when prompted:

dsconf ldap1 backend delete applicationroot --do-it

Sample output:

Deleting Backend cn=applicationroot,cn=ldbm database,cn=plugins,cn=config :
Type 'Yes I am sure' to continue: Yes I am sure
The database, and any sub-suffixes, were successfully deleted

You can pass either the backend name or suffix DN to backend delete. The message about sub-suffixes applies when the backend being deleted is a parent that owns child backends in the mapping tree. Piping the confirmation is suitable only in carefully controlled automation where the backend has already been independently validated. It is not the primary approach in this guide.

Verify the suffix is no longer advertised

Confirm the backend no longer appears in the suffix list:

dsconf ldap1 backend suffix list

Sample output:

dc=example,dc=com (userroot)
dc=manual,dc=example (manualroot)
ou=archive,dc=example,dc=com (archiveroot)

dc=application,dc=example is gone. Read naming contexts from the root DSE to confirm clients no longer discover that root suffix:

ldapsearch -LLL -x -H ldap://127.0.0.1:389 -b "" -s base namingContexts

Sample output:

dn:
namingContexts: dc=manual,dc=example
namingContexts: dc=example,dc=com

A base search against the removed suffix should fail:

ldapsearch -x -H ldap://127.0.0.1:389 -D "cn=Directory Manager" -y /root/dm.pw -b "dc=application,dc=example" -s base dn

Sample output:

ldap_search_ext: No such object (32)

No such object confirms the namespace is no longer served. Other backends in the same instance continue to operate.

Remove the remaining lab backends when you created them only for this guide. Run each command interactively and confirm the backend name at the prompt:

dsconf ldap1 backend delete manualroot --do-it

Sample output:

Deleting Backend cn=manualroot,cn=ldbm database,cn=plugins,cn=config :
Type 'Yes I am sure' to continue: Yes I am sure
The database, and any sub-suffixes, were successfully deleted

Delete the sub-suffix backend next:

dsconf ldap1 backend delete archiveroot --do-it

Sample output:

Deleting Backend cn=archiveroot,cn=ldbm database,cn=plugins,cn=config :
Type 'Yes I am sure' to continue: Yes I am sure
The database, and any sub-suffixes, were successfully deleted

After cleanup, only userroot should remain:

dsconf ldap1 backend suffix list

Sample output:

dc=example,dc=com (userroot)

Backend deletion is destructive. It removes backend configuration, mapping-tree entries, and all directory data and indexes for that backend from the shared LMDB environment, including any sub-suffixes owned by a deleted parent. Export or back up first when you might need the data again.

Troubleshoot suffix and backend problems

Summary

• A suffix defines the LDAP namespace; a backend connects that namespace to logical storage inside the instance LMDB environment.
• Root suffixes add separate directory trees inside one instance.
• Sub-suffixes store branches in separate backends under an existing DIT.
• Use --create-suffix for common root entry types, or add the suffix entry with LDIF (ldapadd with -y for a password file).
• Read-only, disable, and enable control maintenance windows without removing data.
• Follow the delete workflow: check sub-suffixes, export or back up, clear replication and client dependencies, then dsconf backend delete --do-it and verify namingContexts.

What's Next

• Manage users and groups — create entries under your suffix
• Read-only database mode — freeze a backend or entire instance for maintenance
• LDAP referrals — redirect a suffix subtree to another server

References

• 389 Directory Server documentation — upstream project documentation
• Red Hat Directory Server 13 — Management, configuration, and operations — backends, suffixes, and .dsrc
• Red Hat Directory Server 13 — Configuration and schema reference — nsslapd-suffix and backend attributes
• dsconf(8) man page — backend create, backend delete, and suffix subcommands
