Configure Database Chaining in 389 Directory Server

A database link lets one 389 Directory Server present a remote suffix through the local namespace. The client connects only to the local server; the chaining backend opens a server-to-server connection, binds with a dedicated proxy account, and forwards the operation. Unlike LDAP referrals, the client never receives a referral URL or opens a second connection itself.

LDAP client
     |
     | Searches ou=Customers,dc=example,dc=com
     v
Local Directory Server (ldap1)
     |
     | Database link (proxy bind + proxied authorization)
     v
Remote Directory Server (ldap2)
     |
     v
Remote suffix data

Before you start:

• Install 389 Directory Server — local instance ldap1 on ldap1.example.com port 389
• Second host with instance ldap2 on ldap2.example.com port 1389 (see multiple instances when both run on one host)
• Suffixes and backends — local naming context on ldap1; remote data lives on ldap2
• Manage users and groups — client identity such as uid=user3 under ou=people,dc=example,dc=com
• 389 Directory Server dsconf commands — online configuration baseline

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

How database chaining works

Database chaining is implemented by a chaining backend in the mapping tree. When a client targets the chained suffix, the local server selects the database link instead of a local LMDB backend.

The proxy account opens the server-to-server connection. Remote access controls then evaluate the client identity forwarded through proxied authorization, not the proxy DN alone. A working link still fails for users who lack remote ACIs.

Database chaining vs LDAP referrals

Use referrals when clients can follow LDAP URLs and you want a lightweight redirect. Use database chaining when applications should see one directory tree and the server should fan out remote queries. See Configure LDAP Referrals in 389 Directory Server for redirect configuration.

Plan the chaining environment

Production layouts usually place the same subtree on both servers under a shared naming context root such as dc=example,dc=com:

This lab uses two hosts: ldap1.example.com (192.168.56.108) runs instance ldap1 on port 389, and ldap2.example.com (192.168.56.109) runs instance ldap2 on port 1389 with suffix dc=lab,dc=example,dc=com. The chained subtree tested here is ou=Customers,dc=lab,dc=example,dc=com on both sides. When both servers share dc=example,dc=com, use the same subtree DN from the production table above. The suffix must correspond to the remote data tree.

Confirm the remote hostname resolves from the local Directory Server host:

getent hosts ldap2.example.com

Sample output:

192.168.56.109  ldap2.example.com ldap2

Allow the LDAP or LDAPS port through intervening firewalls so ldap1 can reach ldap2 for server-to-server chaining.

Verify the remote suffix directly from ldap1 before you create the database link with ldapsearch:

ldapsearch -LLL -x -H ldap://ldap2.example.com:1389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=Customers,dc=lab,dc=example,dc=com" "(objectClass=*)" dn

Sample output:

dn: ou=Customers,dc=lab,dc=example,dc=com

dn: o=Acme Corp,ou=Customers,dc=lab,dc=example,dc=com

The remote subtree exists and is searchable with Directory Manager credentials before chaining is configured.

Create the proxy bind account and ACI

Configure the remote server first. Without configured bind credentials, the database link connects anonymously. With a proxy account but no (proxy) ACI, it cannot forward the original client identity.

Create the proxy account on the remote server

Create a dedicated account under cn=config. Do not use Directory Manager as the chaining bind DN.

cat > /tmp/chaining-user.ldif << 'EOF'
dn: cn=chaining-user,cn=config
objectClass: top
objectClass: person
objectClass: organizationalPerson
objectClass: inetOrgPerson
cn: chaining-user
sn: chaining-user
userPassword: REPLACE_WITH_PASSWORD
EOF

Import the entry on ldap2 with ldapadd:

ldapadd -x -H ldap://ldap2.example.com:1389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/chaining-user.ldif

Sample output:

adding new entry "cn=chaining-user,cn=config"

Store the proxy password in a root-owned file for later dsconf use. Avoid placing it on the shell command line, then set mode 600 with the chmod command:

printf 'REPLACE_WITH_PASSWORD\n' > /root/chaining.pw
chmod 600 /root/chaining.pw

Grant proxy authorization on the chained subtree

Add a proxy ACI on the remote chained suffix so the link may forward client identities:

cat > /tmp/proxy-aci.ldif << 'EOF'
dn: ou=Customers,dc=lab,dc=example,dc=com
changetype: modify
add: aci
aci: (targetattr="*")(version 3.0; acl "Proxied authorization for database links"; allow (proxy) userdn="ldap:///cn=chaining-user,cn=config";)
EOF

Apply the modification on ldap2 with ldapmodify:

ldapmodify -x -H ldap://ldap2.example.com:1389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/proxy-aci.ldif

Sample output:

modifying entry "ou=Customers,dc=lab,dc=example,dc=com"

The proxy ACI allows only the (proxy) right. That is enough for the link to pass client identities, not enough to read data by itself. Because the ACI is stored on ou=Customers, it applies to that entry and its descendants.

Grant remote access for client identities

Remote ACIs must allow the actual client DN. Add a read rule for the lab client uid=user3 on the same subtree:

cat > /tmp/client-aci.ldif << 'EOF'
dn: ou=Customers,dc=lab,dc=example,dc=com
changetype: modify
add: aci
aci: (targetattr="*")(version 3.0; acl "Allow user3 read customers"; allow (read,search,compare) userdn="ldap:///uid=user3,ou=people,dc=example,dc=com";)
EOF

Apply the client read ACI on ldap2 with the same ldapmodify credentials:

ldapmodify -x -H ldap://ldap2.example.com:1389 -D "cn=Directory Manager" -y /root/dm.pw -f /tmp/client-aci.ldif

Sample output:

modifying entry "ou=Customers,dc=lab,dc=example,dc=com"

When a client searches through the database link, the remote server evaluates ACIs against uid=user3,..., not against cn=chaining-user,cn=config.

The direct userdn rule in this lab works when the user entry exists only on ldap1. Role-, group-, filter-, IP-, or DNS-based ACIs on the remote server may not behave as expected unless their supporting entries are available on ldap2. The remote server also sees the database-link host’s network identity rather than the original client IP.

Test the proxy account

Confirm the proxy entry binds to the remote server using the same transport the database link will use. This lab uses plain LDAP on port 1389:

ldapwhoami -x -H ldap://ldap2.example.com:1389 -D "cn=chaining-user,cn=config" -y /root/chaining.pw

Sample output:

dn: cn=chaining-user,cn=config

The bind identity matches the proxy DN you will reference in link-create.

For remote hosts on untrusted networks, configure certificate trust and use LDAPS or add --use-starttls=on to the database link. When the instance requires secure simple binds, test the proxy account with StartTLS or LDAPS instead of plain LDAP.

Create the database link

I'll create the database link on the local instance (ldap1):

dsconf ldap1 chaining link-create \
  --suffix="ou=Customers,dc=lab,dc=example,dc=com" \
  --server-url="ldap://ldap2.example.com:1389" \
  --bind-mech=SIMPLE \
  --bind-dn="cn=chaining-user,cn=config" \
  --bind-pw-file=/root/chaining.pw \
  customers-link

Sample output:

Successfully created database link

Use --bind-pw-file or --bind-pw-prompt instead of embedding passwords in the command line.

Verify the database link

List configured links:

dsconf ldap1 chaining link-list

Sample output:

customers-link

Inspect the link entry:

dsconf ldap1 chaining link-get customers-link

Sample output (trimmed):

dn: cn=customers-link,cn=chaining database,cn=plugins,cn=config
cn: customers-link
nsfarmserverurl: ldap://ldap2.example.com:1389
nsmultiplexorbinddn: cn=chaining-user,cn=config
nsslapd-suffix: ou=Customers,dc=lab,dc=example,dc=com
nsproxiedauthorization: on
nsbindtimeout: 15
nsbindretrylimit: 3
nsusestarttls: off

The suffix, remote URL, proxy DN, and proxied-authorization default (on) match the intended design.

Store user3's password in a protected file and set mode 600 before the chained bind tests:

printf '%s\n' 'User3Lab2026!' > /root/user3.pw
chmod 600 /root/user3.pw

Search through the local server as uid=user3 to confirm the chained suffix returns remote entries:

ldapsearch -LLL -x -H ldap://ldap1.example.com:389 -D "uid=user3,ou=people,dc=example,dc=com" -y /root/user3.pw -b "ou=Customers,dc=lab,dc=example,dc=com" "(objectClass=*)" dn

Sample output:

dn: ou=Customers,dc=lab,dc=example,dc=com

dn: o=Acme Corp,ou=Customers,dc=lab,dc=example,dc=com

Compare with a direct query against the remote server using Directory Manager:

ldapsearch -LLL -x -H ldap://ldap2.example.com:1389 -D "cn=Directory Manager" -y /root/dm.pw -b "ou=Customers,dc=lab,dc=example,dc=com" "(objectClass=*)" dn o description

Sample output:

dn: ou=Customers,dc=lab,dc=example,dc=com

dn: o=Acme Corp,ou=Customers,dc=lab,dc=example,dc=com
o: Acme Corp
description: Chained customer entry for lab

The chained search returns the same entries the remote server stores. Do not use Directory Manager as the client identity for chained tests. The chaining backend rejects proxied root DN operations.

Secure the chaining connection

Server-to-server traffic should not carry simple bind passwords in cleartext on untrusted networks.

Supported link bind mechanisms include SIMPLE, EXTERNAL, GSSAPI, and DIGEST-MD5. Certificate trust and SASL mapping details belong in the LDAPS chapter; import the remote CA into the local NSS database before you enable StartTLS or LDAPS on the link.

Avoid long-term simple binds over unencrypted LDAP between data centers. Red Hat recommends TLS, StartTLS, or SASL when secure binds are required for simple-password authentication.

Configure failover and connection settings

Database links inherit defaults from config-get-def. New links copy those values at creation time; per-link settings override them afterward.

Inspect global defaults:

dsconf ldap1 chaining config-get-def

Sample output (trimmed):

dn: cn=default instance config,cn=chaining database,cn=plugins,cn=config
nsbindtimeout: 15
nsbindretrylimit: 3
nsbindconnectionslimit: 3
nsoperationconnectionslimit: 20
nsconnectionlife: 0
nshoplimit: 10
nsproxiedauthorization: on
nsmaxresponsedelay: 60
nsslapd-sizelimit: 2000
nsslapd-timelimit: 3600

Update one link:

dsconf ldap1 chaining link-set customers-link --bind-timeout=20 --bind-attempts=5

Sample output:

Successfully updated database chaining link

Confirm the new values:

dsconf ldap1 chaining link-get customers-link

Sample output (trimmed):

nsbindtimeout: 20
nsbindretrylimit: 5

For failover, add alternate remote LDAP URLs to nsFarmServerURL, separated by spaces, with link-set --server-url:

dsconf ldap1 chaining link-set customers-link \
  --server-url="ldap://ldap2.example.com:1389 ldap://ldap2-backup.example.com:1389"

Every failover destination must expose the same chained suffix and compatible data, schema, ACIs, and TLS trust. Database chaining provides routing and failover; it does not synchronize the destination servers.

The link tries URLs in order when the primary remote server is unavailable. Set --conn-lifetime to a non-zero value if you need the link to reopen connections to the primary after failover. When nsconnectionlife is 0, the link may stay on the alternate server until the connection pool is recycled.

Change defaults for future links with dsconf ldap1 chaining config-set-def. Existing links keep their current values until you run link-set.

Configure chaining controls and components

Some LDAP controls and internal server components must be explicitly allowed to pass through the chaining backend.

List supported control OIDs:

dsconf ldap1 chaining config-get --avail-controls

Sample output (trimmed):

Available Components:
1.2.840.113556.1.4.319
1.2.840.113556.1.4.473
1.3.6.1.1.13.1
1.3.6.1.1.13.2
2.16.840.1.113730.3.4.12
...

List supported server components:

dsconf ldap1 chaining config-get --avail-comps

Sample output (trimmed):

Available Controls:
cn=acl plugin,cn=plugins,cn=config
cn=password policy,cn=components,cn=config
cn=roles,cn=components,cn=config
cn=sasl,cn=components,cn=config
...

dsconf labels these lists inversely to the flag names in 389 Directory Server 3.2.0. Treat the OID list as LDAP controls and the cn= list as chainable components.

The database link uses proxied authorization automatically when nsProxiedAuthorization is on, which is the default on new links. Use config-set --add-control for additional client-supplied controls that must reach the remote server, such as paged results when the OID appears in --avail-controls and the remote server supports it. Explicit forwarding of the proxy-authorization control is mainly relevant to cascading chaining through an intermediate database link.

Review the active control list:

dsconf ldap1 chaining config-get

Sample output (trimmed):

nstransmittedcontrols: 2.16.840.1.113730.3.4.2
nstransmittedcontrols: 2.16.840.1.113730.3.4.9
nstransmittedcontrols: 1.2.840.113556.1.4.473

Add a control OID when an application requires it:

dsconf ldap1 chaining config-set --add-control=1.2.840.113556.1.4.319

Enable password-policy or roles components only when you understand the remote-side implications. Each --add-comp forwards internal operations to the remote server.

Monitor the database link

After client traffic flows through the link, inspect counters:

dsconf ldap1 chaining monitor customers-link

Sample output:

dn: cn=monitor,cn=customers-link,cn=chaining database,cn=plugins,cn=config
nssearchsubtreecount: 1
nsopenopconnectioncount: 1
nsopenbindconnectioncount: 0
nsbindcount: 0
nsaddcount: 0
nsmodifycount: 0

nsSearchSubtreeCount increments when subtree searches pass through the link. nsBindCount counts chained bind operations; it is not a proxy-bind failure counter. Use the local and remote error logs to diagnose invalid proxy credentials, TLS failures, connection errors, or rejected proxied-authorization controls. Open connection counters can change quickly, so interpret them together with active traffic and log messages.

Review /var/log/dirsrv/slapd-ldap1/errors and the remote instance error log for chaining database or cb_get_connection messages alongside these counters.

Update or remove a database link

Change link settings without recreating the entry:

dsconf ldap1 chaining link-set customers-link --bind-timeout=15

Before deletion:

1. Confirm applications no longer search the chained suffix.
2. Verify no child database links depend on this suffix (cascading chaining).
3. Export link-get output if you need to rebuild the link later.

Remove the link:

dsconf ldap1 chaining link-delete customers-link

Sample output:

Successfully deleted database link

Deleting the link removes only local chaining configuration. Remote directory entries under ou=Customers,... on ldap2 remain in place, as do any proxy account, ACIs, and password files you created for the lab.

Run the following cleanup only when the proxy account and ACIs were created exclusively for this lab.

Remove both ACIs using their exact stored values:

ldapmodify -x -H ldap://ldap2.example.com:1389 -D "cn=Directory Manager" -y /root/dm.pw <<'EOF'
dn: ou=Customers,dc=lab,dc=example,dc=com
changetype: modify
delete: aci
aci: (targetattr="*")(version 3.0; acl "Proxied authorization for database links"; allow (proxy) userdn="ldap:///cn=chaining-user,cn=config";)
-
delete: aci
aci: (targetattr="*")(version 3.0; acl "Allow user3 read customers"; allow (read,search,compare) userdn="ldap:///uid=user3,ou=people,dc=example,dc=com";)
EOF

Delete the proxy account:

ldapdelete -x -H ldap://ldap2.example.com:1389 -D "cn=Directory Manager" -y /root/dm.pw "cn=chaining-user,cn=config"

Remove password files:

rm -f /root/chaining.pw /root/user3.pw

dsconf supports both --del-control and --del-comp for reversing global chaining-policy changes you added during testing.

Troubleshoot database chaining

Summary

1. Verify the remote suffix and entries with direct ldapsearch on the destination server.
2. Create a restricted proxy bind account (cn=chaining-user,cn=config) on the remote host. Never use Directory Manager.
3. Grant (proxy) and client data ACIs on the remote chained subtree without a target clause so rules inherit to descendants.
4. Create the database link with dsconf ldap1 chaining link-create, using --bind-pw-file for the proxy password.
5. Secure server-to-server traffic with LDAPS, StartTLS, EXTERNAL, or GSSAPI on production networks.
6. Test client permissions through the local server and compare results with a direct remote query.
7. Tune failover URLs, timeouts, and connection limits; monitor with dsconf chaining monitor and server error logs.

What's Next

• Directory views — present chained data in a virtual tree
• LDAP referrals — when clients should follow URLs themselves
• Delegated administration — ACIs over chained subtrees

References

• Red Hat Directory Server 13 — Creating and maintaining database links
• Red Hat Directory Server 13 — Settings required for creating a database link
• Red Hat Directory Server 13 — Configuring chaining policy and LDAP controls
• Red Hat Directory Server 13 — Database links and access-control evaluation
• dsconf(8) — chaining commands
• Red Hat Directory Server 13 Configuration and Schema Reference — nsConnectionLife, nsProxiedAuthorization, nsFarmServerURL
