Configure TLS Versions and Cipher Suites in 389 Directory Server

After LDAPS and STARTTLS are working, you can harden transport security by disabling obsolete TLS protocol versions, reviewing the cipher suites Directory Server negotiates, and applying a stricter policy when compliance or interoperability requirements demand it. The goal is stronger defaults without breaking LDAP clients, replication, chaining, or monitoring tools that still depend on specific protocol or cipher support.

This guide covers protocol and cipher inventory, minimum TLS version configuration, nsSSL3Ciphers patterns, operating-system crypto policy interaction, OpenSSL and ldapsearch verification, staged rollout, troubleshooting, and rollback.

Before you start:

• Configure TLS, STARTTLS, and LDAPS — working server certificate, LDAPS on port 636, STARTTLS on port 389
• dsconf commands — online security configuration
• dsctl commands — instance restart

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

The lab uses instance ldap1 on ldap1.example.com with LDAP port 389 and LDAPS port 636. Instance ldap2 on ports 1389 and 1636 provides a second listener pair for non-default port tests. Commands that target ldap2 through dsconf use an explicit LDAP URL because local instance-name resolution can behave differently from ldap1.

Understand TLS protocols and cipher suites

A successful LDAPS or STARTTLS connection requires a shared TLS version and compatible cryptographic parameters. With TLS 1.2, the selected suite must match the server certificate authentication type, such as RSA or ECDSA. With TLS 1.3, cipher suites no longer encode the certificate or key-exchange type; compatible signature algorithms and key-exchange groups are negotiated separately.

Directory Server stores protocol bounds in sslVersionMin and optionally sslVersionMax under cn=encryption,cn=config. Cipher policy is stored in nsSSL3Ciphers and can be influenced by allowWeakCipher.

A connection succeeds only when the client and server share a compatible protocol and negotiable cryptographic parameters. Changing only one side (an old Java LDAP client, a hardened server, or a stricter host crypto policy) can produce no shared cipher or protocol version errors even when the certificate itself is valid.

Check the current TLS configuration

Start by recording the protocol range Directory Server is configured to allow.

dsconf ldap1 security get |
    grep -Ei 'sslVersionMin|sslVersionMax'

Sample output:

sslversionmin: TLS1.2
sslversionmax: TLS1.3

On this lab host, sslVersionMin is TLS1.2. The sslversionmax line shows the effective maximum; when sslVersionMax is not stored in dse.ldif, Directory Server can still report the strongest version supported by the installed NSS stack.

List the cipher suites currently enabled for this instance:

dsconf ldap1 security ciphers list --enabled

Sample output:

TLS_AES_128_GCM_SHA256
TLS_CHACHA20_POLY1305_SHA256
TLS_AES_256_GCM_SHA384
TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256
TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256
TLS_ECDHE_ECDSA_WITH_CHACHA20_POLY1305_SHA256
TLS_ECDHE_RSA_WITH_CHACHA20_POLY1305_SHA256
TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384
TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384

The full enabled list in this lab contains twenty-two suites spanning TLS 1.2 and TLS 1.3. That list includes both TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256 and TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 even though the active server certificate in this lab is RSA. The ECDSA suite is enabled in NSS configuration but is not negotiable for TLS 1.2 with that RSA certificate.

List every cipher the installed Directory Server and NSS versions support locally:

dsconf ldap1 security ciphers list --supported

Sample output:

TLS_AES_128_GCM_SHA256
TLS_CHACHA20_POLY1305_SHA256
TLS_AES_256_GCM_SHA384
TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256
TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256
TLS_ECDHE_ECDSA_WITH_CHACHA20_POLY1305_SHA256
TLS_ECDHE_RSA_WITH_CHACHA20_POLY1305_SHA256
TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384
TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384
TLS_ECDHE_ECDSA_WITH_3DES_EDE_CBC_SHA
TLS_ECDHE_RSA_WITH_3DES_EDE_CBC_SHA

Supported output in this lab lists seventy-one suites, including legacy algorithms that are not enabled by default.

Record the current nsSSL3Ciphers expression:

dsconf ldap1 security ciphers list

Sample output:

default

default means the instance relies on the NSS default cipher policy unless you override nsSSL3Ciphers. Supported, default, and enabled lists can differ between operating-system and Directory Server releases. Always build policy from local output rather than copying another host.

Understand default, supported, and enabled ciphers

dsconf security ciphers list --enabled lists ciphers enabled by the server’s NSS cipher configuration. Actual negotiation still depends on protocol version, certificate and signature compatibility, client capabilities, and crypto policy. The CLI distinguishes configured, supported, enabled, and disabled lists but does not claim that every enabled cipher is usable in every handshake.

Directory Server applies nsSSL3Ciphers using NSS cipher-spec patterns:

default
-all,+CIPHER_NAME
default,-CIPHER_NAME

Use default when the NSS default set is acceptable. Use -all,+CIPHER_NAME when you need an explicit allow-list. Prefix with default, when you want to start from NSS defaults and remove individual suites.

Do not copy a cipher list from another server without first checking dsconf INSTANCE security ciphers list --supported on the target host. An RSA server certificate cannot negotiate an ECDSA-authenticated TLS 1.2 suite such as TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384. TLS 1.3 uses separate signature-algorithm negotiation, so its short cipher names do not indicate RSA or ECDSA. A restricted allow-list that omits all TLS 1.3 suites disables TLS 1.3 even when the protocol version permits it.

Set the minimum TLS version

Raise the minimum TLS version when every client, replication peer, and monitoring tool in your environment supports the newer protocol.

I'll require TLS 1.2 or newer:

dsconf ldap1 security set --tls-protocol-min="TLS1.2"

For an environment where every client supports TLS 1.3:

dsconf ldap1 security set --tls-protocol-min="TLS1.3"

Sample output:

Successfully updated security configuration (nsSSL3Ciphers)

On the tested build, dsconf printed nsSSL3Ciphers even though this command changed sslVersionMin. Treat this as a CLI reporting issue rather than proof that the cipher expression changed. Verify the stored and effective protocol values with dsconf security get after the restart.

Restart the instance so the listener loads the new protocol bounds:

dsctl ldap1 restart

Verify the stored values:

dsconf ldap1 security get |
    grep -Ei 'sslVersionMin|sslVersionMax'

Sample output after setting the minimum to TLS 1.3 in the lab:

sslversionmin: TLS1.3
sslversionmax: TLS1.3

When the minimum is TLS 1.3, a TLS 1.2-only client receives a protocol-version alert:

openssl s_client \
    -connect ldap1.example.com:636 \
    -servername ldap1.example.com \
    -tls1_2 </dev/null 2>&1 |
    grep -E 'Protocol|alert|Cipher'

Sample output:

40F748C9E47F0000:error:0A00042E:SSL routines:ssl3_read_bytes:tlsv1 alert protocol version:ssl/record/rec_layer_s3.c:918:SSL alert number 70
Protocol: TLSv1.2
New, (NONE), Cipher is (NONE)

TLS 1.3-only configuration can break older LDAP libraries, replication peers, monitoring tools, and Java runtimes. Inventory clients before you raise the minimum, test in a non-production instance first, and roll back if any dependency still requires TLS 1.2.

Restore TLS 1.2 as the minimum before continuing the lab guide:

dsconf ldap1 security set --tls-protocol-min="TLS1.2"

I restart the instance so the restored minimum takes effect:

dsctl ldap1 restart

Leave the maximum TLS version unset

The normal production policy is:

Minimum TLS version: explicitly configured
Maximum TLS version: unset

When sslVersionMax is not set in cn=encryption,cn=config, Directory Server can adopt newer protocols supported by the server and client after software upgrades. Red Hat explicitly warns that setting a maximum can force clients to negotiate a weaker protocol than their default standard.

Inspect whether a maximum is currently configured:

dsconf ldap1 security get |
    grep -Ei 'sslVersionMin|sslVersionMax'

I also check whether sslVersionMax is stored directly in dse.ldif:

grep -i 'sslVersionMax' /etc/dirsrv/slapd-ldap1/dse.ldif

If dse.ldif contains an sslVersionMax line you no longer need, remove it while planning a controlled maintenance window. One supported method is an online modify of cn=encryption,cn=config:

ldapmodify -x -H ldaps://ldap1.example.com:636 \
    -D "cn=Directory Manager" -y /root/dm.pw <<'EOF'
dn: cn=encryption,cn=config
changetype: modify
delete: sslVersionMax
EOF

Restart the instance after changing TLS protocol bounds:

dsctl ldap1 restart

Verify both the stored configuration and the effective values:

grep -i 'sslVersionMax' /etc/dirsrv/slapd-ldap1/dse.ldif

No output means the maximum is not explicitly stored in dse.ldif.

dsconf ldap1 security get |
    grep -Ei 'sslVersionMin|sslVersionMax'

dsconf security get can still display the effective NSS maximum even when sslVersionMax is absent from dse.ldif.

Set a maximum only temporarily when you are troubleshooting a client defect, reproducing a protocol-specific problem, or meeting a narrowly defined compatibility requirement. Document the exception, retest after the client is upgraded, and remove the restriction.

Configure the enabled cipher suites

Save the current configuration before you restrict ciphers:

dsconf ldap1 security ciphers list

Sample output:

default

I save the enabled cipher list to a file so I can compare it after changes:

dsconf ldap1 security ciphers list --enabled > /root/ldap1-ciphers-enabled-before.txt

To replace the enabled set with one explicit TLS 1.2 suite, use the -- separator so the shell does not treat -all as a dsconf option:

dsconf ldap1 security ciphers set -- "-all,+TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384"

Sample output:

Remember to restart the server to apply the new cipher set.
Some ciphers may be disabled anyway due to allowWeakCipher attribute.

Confirm the stored expression:

dsconf ldap1 security ciphers get

Sample output:

-all,+TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384

Restart and list enabled suites:

dsctl ldap1 restart

After the restart, I confirm only the selected suite remains enabled:

dsconf ldap1 security ciphers list --enabled

Sample output:

TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384

After restart, only the selected TLS 1.2 suite is enabled. TLS 1.3 handshakes fail until you also allow TLS 1.3 cipher suites or return to default.

For multiple suites:

dsconf ldap1 security ciphers set -- "-all,+CIPHER_1,+CIPHER_2,+CIPHER_3"

Build every allow-list from:

• The locally supported ciphers
• Server certificate key type
• Client compatibility
• Organizational security policy
• Operating-system crypto policy
• FIPS requirements where applicable

Do not publish one universal “best cipher list.” Available ciphers change with Directory Server, NSS, and operating-system updates.

Restore the NSS default policy before you continue:

dsconf ldap1 security ciphers set -- "default"

I restart the instance so the listener reloads the default cipher set:

dsctl ldap1 restart

Understand weak and insecure ciphers

Check whether insecure ciphers are allowed:

dsconf ldap1 security get |
    grep -i allowWeakCipher

Sample output:

allowweakcipher:

An empty value means weak ciphers are not explicitly allowed. Legacy suites such as TLS_ECDHE_RSA_WITH_3DES_EDE_CBC_SHA can still appear in --supported output but remain disabled unless you change policy.

Where a temporary legacy exception is unavoidable:

dsconf ldap1 security set --allow-insecure-ciphers=on

Allowing weak ciphers does not by itself enable a legacy suite. Select the exact cipher in nsSSL3Ciphers, restart the instance, and confirm that it appears in the enabled list:

dsconf ldap1 security ciphers set -- "-all,+REQUIRED_LEGACY_CIPHER"

I restart the instance because cipher changes load only after a restart:

dsctl ldap1 restart

I confirm the legacy suite now appears in the enabled list:

dsconf ldap1 security ciphers list --enabled |
    grep -F 'REQUIRED_LEGACY_CIPHER'

Replace REQUIRED_LEGACY_CIPHER with the exact NSS name from dsconf ldap1 security ciphers list --supported, such as TLS_ECDHE_RSA_WITH_3DES_EDE_CBC_SHA.

Enabling allowWeakCipher does not override the operating-system crypto policy. A cipher rejected by the host policy can remain unavailable even after you select it in nsSSL3Ciphers.

This is not part of a recommended production baseline. Before enabling a legacy cipher:

1. Identify the exact incompatible client.
2. Confirm that upgrading the client is not immediately possible.
3. Enable only the minimum required cipher.
4. Document the exception.
5. Set a removal date.
6. Retest after the client is upgraded.

Do not enable every supported cipher or switch the entire host to the LEGACY crypto policy merely to support one old LDAP client.

Roll back a temporary weak-cipher exception with:

dsconf ldap1 security set --allow-insecure-ciphers=off

I restore the default cipher expression next:

dsconf ldap1 security ciphers set -- "default"

I restart so both settings take effect on the listener:

dsctl ldap1 restart

Check operating-system crypto policies

On Red Hat Enterprise Linux, Rocky Linux, AlmaLinux, and other distributions that ship crypto-policies, inspect the active profile:

update-crypto-policies --show

Sample output:

DEFAULT

The system crypto policy can further constrain Directory Server protocol and cipher settings. Instance configuration can usually make the policy stricter, but it cannot re-enable algorithms the operating system rejects. Common profiles include DEFAULT, LEGACY, FUTURE, and FIPS.

On older RHEL-family releases, LEGACY could lower the system TLS floor. RHDS 13 on RHEL 10 documents TLS 1.2 as the minimum for all standard profiles, including LEGACY. Do not expect update-crypto-policies --set LEGACY to restore TLS 1.0 on the tested platform.

Treat crypto-policy commands as a distribution-specific compatibility section. Ubuntu, Debian, and other distributions without the RHEL system-wide crypto-policy framework use different mechanisms; compare your distribution documentation before you assume update-crypto-policies exists.

When a cipher appears in dsconf security ciphers list --supported but not in --enabled, check both nsSSL3Ciphers and the host crypto policy before you weaken the server.

Test TLS protocol versions

The following commands isolate protocol and cipher negotiation with OpenSSL. They do not by themselves prove that the certificate chain is trusted. openssl s_client can continue after certificate-verification errors unless -verify_return_error is supplied, and the grep filters remove verification details. Run a verified handshake before and after changing policy.

Establish a verified LDAPS baseline:

openssl s_client \
    -connect ldap1.example.com:636 \
    -servername ldap1.example.com \
    -verify_hostname ldap1.example.com \
    -verify_return_error \
    -CAfile /root/example-ca-chain.pem \
    </dev/null

Sample output near the end:

Verify return code: 0 (ok)

Verify STARTTLS the same way:

openssl s_client \
    -starttls ldap \
    -connect ldap1.example.com:389 \
    -servername ldap1.example.com \
    -verify_hostname ldap1.example.com \
    -verify_return_error \
    -CAfile /root/example-ca-chain.pem \
    </dev/null

Sample output near the end:

Verify return code: 0 (ok)

For a lab that still uses the dscreate host SSCA, /etc/dirsrv/ssca/ca.crt can validate the listener instead of /root/example-ca-chain.pem. After importing or renewing through another CA, use the CA bundle that validates the certificate currently presented by the listener.

Test LDAPS with TLS 1.2:

openssl s_client \
    -connect ldap1.example.com:636 \
    -servername ldap1.example.com \
    -tls1_2 </dev/null 2>&1 |
    grep -E 'Protocol|Cipher'

Sample output:

New, TLSv1.2, Cipher is ECDHE-RSA-AES128-GCM-SHA256
Protocol: TLSv1.2
    Protocol  : TLSv1.2
    Cipher    : ECDHE-RSA-AES128-GCM-SHA256

Test TLS 1.3:

openssl s_client \
    -connect ldap1.example.com:636 \
    -servername ldap1.example.com \
    -tls1_3 </dev/null 2>&1 |
    grep -E 'Protocol|Cipher'

Sample output:

New, TLSv1.3, Cipher is TLS_AES_128_GCM_SHA256
Protocol: TLSv1.3

Test STARTTLS on the plain LDAP port:

openssl s_client \
    -connect ldap1.example.com:389 \
    -starttls ldap \
    -servername ldap1.example.com \
    -tls1_2 </dev/null 2>&1 |
    grep -E 'Protocol|Cipher|STARTTLS'

Sample output:

New, TLSv1.2, Cipher is ECDHE-RSA-AES128-GCM-SHA256
Protocol: TLSv1.2
    Protocol  : TLSv1.2
    Cipher    : ECDHE-RSA-AES128-GCM-SHA256

Repeat the same tests against the second instance on its non-default secure port when you need to confirm listener-specific behavior:

openssl s_client \
    -connect ldap2.example.com:1636 \
    -servername ldap2.example.com \
    -tls1_2 </dev/null 2>&1 |
    grep -E 'Protocol|Cipher'

Check the negotiated TLS version, cipher, certificate verification result, handshake alerts, and whether a disabled protocol correctly fails.

Test specific cipher suites

For TLS 1.2, force one cipher:

openssl s_client \
    -connect ldap1.example.com:636 \
    -servername ldap1.example.com \
    -tls1_2 \
    -cipher 'ECDHE-RSA-AES256-GCM-SHA384' </dev/null 2>&1 |
    grep -E 'Protocol|Cipher|handshake failure|alert'

Sample output when the suite is allowed:

New, TLSv1.2, Cipher is ECDHE-RSA-AES256-GCM-SHA384
Protocol: TLSv1.2
    Protocol  : TLSv1.2
    Cipher    : ECDHE-RSA-AES256-GCM-SHA384

When the suite is disabled, OpenSSL reports a handshake failure:

SSL alert number 40
New, (NONE), Cipher is (NONE)
Protocol: TLSv1.2

For TLS 1.3, use the OpenSSL option supported by your client version:

openssl s_client \
    -connect ldap1.example.com:636 \
    -servername ldap1.example.com \
    -tls1_3 \
    -ciphersuites 'TLS_AES_128_GCM_SHA256' </dev/null 2>&1 |
    grep -E 'Protocol|Cipher'

Sample output:

New, TLSv1.3, Cipher is TLS_AES_128_GCM_SHA256
Protocol: TLSv1.3

OpenSSL cipher names are not always identical to the NSS names displayed by dsconf security ciphers list. Map between them by testing one suite at a time.

Verify both LDAPS on port 636 and STARTTLS on port 389 after every change.

Test LDAP clients and server-to-server connections

OpenSSL confirms the handshake. Applications still need real binds and searches.

export LDAPTLS_CACERT=/root/example-ca-chain.pem

For a lab that still uses the dscreate host SSCA, /etc/dirsrv/ssca/ca.crt can be used instead. After importing or renewing through another CA, use the CA bundle that validates the certificate currently presented by the listener.

Test LDAPS with ldapsearch after you set client CA trust:

ldapsearch -x -H ldaps://ldap1.example.com:636 \
    -D "cn=Directory Manager" -y /root/dm.pw \
    -b "" -s base "(objectClass=*)" namingContexts

Sample output near the end:

result: 0 Success

# numResponses: 2
# numEntries: 1

Test STARTTLS:

ldapsearch -x -ZZ -H ldap://ldap1.example.com:389 \
    -D "cn=Directory Manager" -y /root/dm.pw \
    -b "" -s base "(objectClass=*)" namingContexts

Sample output near the end:

result: 0 Success

# numResponses: 2
# numEntries: 1

Use a compatibility matrix during staged rollout:

Record pass/fail for each row before you remove the previous configuration.

Apply a staged cipher-policy change

1. Record the current protocol and cipher configuration.
2. Inventory all LDAP clients and server-to-server connections.
3. Test the proposed policy in a non-production instance such as ldap2.
4. Change the minimum TLS version first.
5. Test all clients.
6. Apply cipher restrictions separately.
7. Restart and verify both LDAPS and STARTTLS.
8. Monitor connection failures before you delete the saved rollback files.

Avoid changing TLS version, ciphers, certificates, and secure-bind enforcement in the same maintenance window. Each layer has different rollback steps and failure modes.

Troubleshoot TLS and cipher failures

Roll back safely

Restore the previous cipher expression:

dsconf ldap1 security ciphers set -- "default"

That returns nsSSL3Ciphers to the NSS default policy. Or replace default with the saved value from dsconf ldap1 security ciphers get.

Restore the previous minimum protocol:

dsconf ldap1 security set --tls-protocol-min="TLS1.2"

That command returns the instance to TLS 1.2 as the minimum when you are undoing a temporary hardening change.

If you enabled a temporary weak-cipher exception, restore it as well:

dsconf ldap1 security set --allow-insecure-ciphers=off

That turns off explicit weak-cipher allowance before you return to the default cipher set.

Remove an unnecessary sslVersionMax restriction from cn=encryption,cn=config when you no longer need a temporary maximum.

I restart the instance after restoring protocol and cipher settings:

dsctl ldap1 restart

Repeat LDAPS, STARTTLS, application, and replication tests. Confirm enabled ciphers match the pre-change inventory before you close the change ticket.

What's Next

• Require secure LDAP connections — block plaintext password binds
• Client certificate authentication — mutual TLS for binds
• FIPS mode — cryptographic compliance after cipher hardening

References

• Red Hat Directory Server 13 — Securing Red Hat Directory Server
• Red Hat Directory Server 13 — Configuration and schema reference
• Red Hat Enterprise Linux 10 — System-wide cryptographic policies
• 389 Directory Server — Supported ciphers design
• 389 Directory Server — Howto: TLS/StartTLS
• RFC 8446 — The Transport Layer Security (TLS) Protocol Version 1.3

Summary

1. Inventory current protocols with dsconf security get and enabled ciphers with dsconf security ciphers list --enabled.
2. Distinguish enabled ciphers from negotiable ciphers that match the TLS version, certificate, client, and crypto policy.
3. Set an appropriate minimum TLS version and restart the instance.
4. Normally leave the maximum TLS version unset.
5. Use NSS default ciphers unless a stricter policy is required.
6. Build custom allow-lists from local --supported output, not from another host.
7. Test verified LDAPS and STARTTLS handshakes, then application and replication traffic after every change.
