12 practical grubby command examples (cheat cheet)

In this tutorial I will share different examples on the usage of grubby command in Linux to modify kernel boot entries, check and change default kernel, list active installed kernel and many more. grubby is a utility for manipulating bootloader-specific configuration files. You can use grubby also for changing the default boot entry, and for adding/removing arguments from a GRUB2 menu entry.



What are boot entries

  • We will be working with kernel boot entries in this tutorial so first let me give you a brief overview on boot entries
  • A boot entry is a collection of options which are stored in a configuration file and tied to a particular kernel version.
  • In practice, you have at least as many boot entries as your system has installed kernels.
  • The file name above consists of a machine ID stored in the /etc/machine-id file, and a kernel version.
  • The boot entry configuration file contains information about the kernel version, the initial ramdisk image, and the kernelopts environment variable, which contains the kernel command-line parameters.

The boot entry configuration file is located in the /boot/loader/entries/ directory and can look like below. The kernelopts environment variable is defined in the /boot/grub2/grubenv file.

# cat /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.14.3.el8_2.x86_64.conf
title Red Hat Enterprise Linux (4.18.0-193.14.3.el8_2.x86_64) 8.2 (Ootpa)
version 4.18.0-193.14.3.el8_2.x86_64
linux /vmlinuz-4.18.0-193.14.3.el8_2.x86_64
initrd /initramfs-4.18.0-193.14.3.el8_2.x86_64.img $tuned_initrd
options $kernelopts $tuned_params
id rhel-20200720151339-4.18.0-193.14.3.el8_2.x86_64
grub_users $grub_users
grub_arg --unrestricted
grub_class kernel



1. grubby command to add new kernel entry

Assuming you have built your own kernel which is installed on the server and you wish to add a custom entry for this new kernel. So you can use below syntax:

grubby --add-kernel=new_kernel --title="entry_title" --initrd="new_initrd" --copy-default

Here I have used --copy-default to copy all the kernel arguments from our default kernel to this new kernel entry. To add your own custom kernel arguments you can use:

grubby --add-kernel=new_kernel --title="entry_title" --initrd="new_initrd" --args=kernel_args

To get the list of available boot entries

# ls -l /boot/loader/entries/*
-rw-r--r--. 1 root root 408 Nov 13  2019 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-0-rescue.conf
-rw-r--r--  1 root root 366 Aug 15 16:03 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.1.2.el8_2.x86_64.conf
-rw-r--r--  1 root root 371 Aug 15 16:07 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.14.3.el8_2.x86_64.conf
-rw-r--r--  1 root root 336 Aug 15 15:12 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.el8.x86_64.conf

In this example I will create a new boot entry for 4.18.0-193.el8.x86_64 kernel

# grubby --grub2 --add-kernel=/boot/vmlinuz-4.18.0-193.el8.x86_64 --title="Red Hat Enterprise 8 Test" --initrd=/boot/initramfs-4.18.0-193.el8.x86_64.img --copy-default

Verify the newly added boot entry:

# ls -l /boot/loader/entries/*
-rw-r--r--. 1 root root 408 Nov 13  2019 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-0-rescue.conf
-rw-r--r--  1 root root 366 Aug 15 16:03 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.1.2.el8_2.x86_64.conf
-rw-r--r--  1 root root 371 Aug 15 16:07 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.14.3.el8_2.x86_64.conf
-rw-r--r--  1 root root 287 Aug 16 15:17 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.el8.x86_64.0~custom.conf
-rw-r--r--  1 root root 287 Aug 16 15:29 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.el8.x86_64.conf

Now you can change the default kernel and reboot your server to verify the changes.



2. Remove kernel entry

IMPORTANT NOTE:

Use this command with caution as it will remove the boot entry of the provided kernel. If you remove kernel entry of incorrect kernel, your system may fail to boot and then you will have to boot into single user mode to fix your broken server
# grubby --remove-kernel=old_kernel

OR you can also use

grubby --remove-kernel=menu_index



3. Add new kernel arguments

To add new arguments in GRUB2 use:

grubby --update-kernel=current_kernel --args="kernel_args"

For example, I will disable IPv6 in this command:

# grubby --update-kernel=/boot/vmlinuz-$(uname -r) --args="ipv6.disable=1"

I have used uname -r to get the release information of my default kernel. It is easier this way rather than providing the kernel version. Although if you plan to add new arguments to some kernel other than default then you must provide the kernel version manually.

Now verify your changes.

# grep ipv6 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-$(uname -r).conf
options root=/dev/mapper/rhel-root ro resume=/dev/mapper/rhel-swap rd.lvm.lv=rhel/root rd.lvm.lv=rhel/swap rhgb quiet biosdevname=0 net.ifnames=0 enforcing=0 $tuned_params ipv6.disable=1

To add new kernel argument to all the available kernel

grubby --update-kernel=ALL --args="kernel_args"



4. Remove kernel arguments

Similar to add we can also remove additional kernel arguments from kernel boot entries using:

grubby --update-kernel=current_kernel --remove-args="kernel_args"

In the last example I had disabled ipv6 so now I will remove this kernel argument

# grubby --update-kernel=/boot/vmlinuz-$(uname -r) --remove-args="ipv6.disable=1"

Verify the boot entry of the default kernel to make sure the entry is removed

# grep ipv6 /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-$(uname -r).conf

Similarly to remove kernel entry from all the kernels

grubby --update-kernel=ALL --args="kernel_args"



5. Remove and Add kernel arguments

We can combine both remove and add kernel arguments with grubby command.

grubby --remove-args="kernel-args" --args="kernel_args"

In this example I am removing "quiet" and adding "console=ttys0" argument in the same grubby command

# grubby --update-kernel=/boot/vmlinuz-$(uname -r) --remove-args="quiet" --args="console=ttsy0"

Verify your changes

# grep console /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-$(uname -r).conf
options root=/dev/mapper/rhel-root ro resume=/dev/mapper/rhel-swap rd.lvm.lv=rhel/root rd.lvm.lv=rhel/swap rhgb biosdevname=0 net.ifnames=0 enforcing=0 $tuned_params console=ttsy0



6. List installed kernels

To list all the installed kernel you can use:

# grubby --info=ALL | grep ^kernel
kernel="/boot/vmlinuz-4.18.0-193.14.3.el8_2.x86_64"
kernel="/boot/vmlinuz-4.18.0-193.1.2.el8_2.x86_64"
kernel="/boot/vmlinuz-4.18.0-193.el8.x86_64"
kernel="/boot/vmlinuz-0-rescue-d88fa2c7ff574ae782ec8c4288de4e85"



7. Get more information on kernel boot entries

To get more details on the installed kernel we can use grubby --info. This will give you information such as index number, boot entry id, arguments applied to the kernel etc

# grubby --info="/boot/vmlinuz-$(uname -r)"
index=1
kernel="/boot/vmlinuz-4.18.0-193.1.2.el8_2.x86_64"
args="ro resume=/dev/mapper/rhel-swap rd.lvm.lv=rhel/root rd.lvm.lv=rhel/swap rhgb biosdevname=0 net.ifnames=0 enforcing=0 $tuned_params console=ttsy0"
root="/dev/mapper/rhel-root"
initrd="/boot/initramfs-4.18.0-193.1.2.el8_2.x86_64.img $tuned_initrd"
title="Red Hat Enterprise Linux (4.18.0-193.1.2.el8_2.x86_64) 8.2 (Ootpa)"
id="d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.1.2.el8_2.x86_64"



8. List path of the default kernel

A default kernel is the kernel version which will be activated post reboot. It is possible that if you have installed/removed any kernel then your active kernel version will be different compared to default kernel version

To get the default kernel version use:

# grubby --default-kernel
/boot/vmlinuz-4.18.0-193.el8.x86_64



9. List index of the default kernel

Now to get the index value of the default kernel use grubby --default-index. For example below output is from my server:

# grubby --default-index
2



10. List default kernel title

The kernel title is the output which you see in the GRUB2 menu while rebooting the Linux server. So to check the title of your default kernel use:

# grubby --default-title
Red Hat Enterprise Linux (4.18.0-193.1.2.el8_2.x86_64) 8.2 (Ootpa)



11. Set default kernel using kernel path

To change the default kernel i.e. the kernel to be activated post reboot using kernel path:

# grubby --set-default="/boot/vmlinuz-4.18.0-193.1.2.el8_2.x86_64"
The default is /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.1.2.el8_2.x86_64.conf with index 1 and kernel /boot/vmlinuz-4.18.0-193.1.2.el8_2.x86_64

So now kernel-4.18.0-193.1.2.el8_2 is set as default boot to be activated post reboot.



12. Set default kernel using index

Instead of using the kernel vmlinuz entry we can also provide the index number to change the default kernel.

To get the index number of all the installed kernels:

# grubby --info=ALL | grep -E "^kernel|^index"
index=0
kernel="/boot/vmlinuz-4.18.0-193.14.3.el8_2.x86_64"
index=1
kernel="/boot/vmlinuz-4.18.0-193.1.2.el8_2.x86_64"
index=2
kernel="/boot/vmlinuz-4.18.0-193.el8.x86_64"
index=3
kernel="/boot/vmlinuz-4.18.0-193.el8.x86_64"
index=4
kernel="/boot/vmlinuz-0-rescue-d88fa2c7ff574ae782ec8c4288de4e85"

So now you have the mapping index number of each kernel which is installed on your server. Now we can use --set-default-index=<val> to change default kernel

# grubby --set-default-index=2
The default is /boot/loader/entries/d88fa2c7ff574ae782ec8c4288de4e85-4.18.0-193.el8.x86_64.0~custom.conf with index 2 and kernel /boot/vmlinuz-4.18.0-193.el8.x86_64

You can verify the output to make sure the correct kernel is added as default



Recommended Read

I have written some more articles on related topic i.e. grubby and grub2-editenv which you find interesting



Conclusion

In this tutorial we learned about grubby command and different examples to modify and update kernel boot entries with GRUB2. Since I don't have access to any ELILO server, I won't be able to cover thos e arguments but you can learn more about individual arguments used in this article and much more using the man page of grubby command

Lastly I hope this tutorial on grubby comand with examples on Linux was helpful. So, let me know your suggestions and feedback using the comment section.
