lvdisplay Command in Linux: Syntax, Options & Show LV Details

lvdisplay prints detailed logical volume fields — path, UUID, size, extents, allocation, snapshot status, and device-mapper block major:minor. Use it when lvs is not enough.

Published

Updated

Read time 5 min read

Reviewed byDeepak Prasad

lvdisplay Command in Linux: Syntax, Options & Show LV Details
About lvdisplay prints detailed logical volume fields — path, UUID, size, extents, allocation, snapshot status, and device-mapper block major:minor. Use it when lvs is not enough.
Tested on Ubuntu 25.04 (Plucky Puffin); LVM 2.03.27(2); kernel 7.0.0-27-generic
Package lvm2 (apt/deb) · lvm2 (dnf/rpm)
Man page lvdisplay(8)
Privilege root / sudo
Distros

All Linux distros with LVM2 (lvm2 package).

Quick list: lvscan.
Related guide

lvdisplay — quick reference

Display modes

When to use Command
All LVs on the system sudo lvdisplay
One LV by VG/LV name sudo lvdisplay myvg/mylv
Every LV in a volume group sudo lvdisplay myvg
Colon-separated (script parsing) sudo lvdisplay -c myvg/mylv
Column view (like lvs) sudo lvdisplay -C myvg
Extent map to physical volumes sudo lvdisplay -m myvg/mylv
Include internal component LVs sudo lvdisplay -a myvg
When to use Command
One-line scan with active/inactive sudo lvscan
Custom report columns sudo lvs -o +devices
Change LV attributes sudo lvchange ...

Help and version

When to use Command
Show built-in usage lvdisplay --help
Show LVM version lvm version

lvdisplay — command syntax

Synopsis from lvdisplay --help on Ubuntu 25.04 (LVM 2.03.27):

text
lvdisplay
	[ -a|--all ]
	[ -c|--colon ]
	[ -C|--columns ]
	[ -m|--maps ]
	[ VG|LV|Tag ... ]

lvdisplay reads LVM metadata only — it does not mount filesystems. Needs sudo on shared systems.

lvdisplay — command examples

Essential Display one logical volume

Replace labvg/datalv with your VG/LV.

bash
sudo lvdisplay labvg/datalv

Sample output (trimmed):

text
--- Logical volume ---
  LV Path                /dev/labvg/datalv
  LV Name                datalv
  VG Name                labvg
  LV UUID                bZw1J7-YTHK-vxhy-hO4j-K0L2-yDR1-WkCUFZ
  LV Write Access        read/write
  LV Status              available
  # open                 0
  LV Size                64.00 MiB
  Current LE             16
  Segments               1
  Allocation             inherit
  Block device           252:1

# open counts processes using the device — should be 0 before lvremove.

Essential When to use lvs instead

For monitoring, lvs is shorter:

bash
sudo lvs -o lv_name,vg_name,lv_size,lv_attr,devices labvg

Use lvdisplay when you need UUID, LE count, readahead, or snapshot relationships in one report.

Common Snapshot origin shows in lvdisplay

Origin LVs list active snapshots under LV snapshot status.

bash
sudo lvcreate -L 48M -n origin labvg
sudo lvcreate -s -L 12M -n snap labvg/origin
sudo lvdisplay labvg/origin | grep -A2 'snapshot status'

Sample output:

text
LV snapshot status     source of
                         snap [active]

The snapshot LV has its own lvdisplay block with LV snapshot status active origin.

Common Machine-readable colon format with -c

-c emits one colon-separated record per LV — useful in legacy scripts.

bash
sudo lvdisplay -c labvg/datalv

Sample output:

text
/dev/labvg/datalv:labvg:3:1:-1:0:131072:16:-1:0:-1:252:1

Field order is documented in lvdisplay(8) — prefer lvs --reportformat json for new tooling.

Common Column output with -C

-C matches the familiar lvs table layout.

bash
sudo lvdisplay -C labvg

Sample output:

text
LV     VG    Attr       LSize  Pool Origin Data%
  datalv labvg -wi-a----- 64.00m
  snaplv labvg swi-a-s--- 16.00m      datalv 0.00

Handy when you want lvs-style output from lvdisplay.

Advanced Show extent mapping with -m

-m lists which physical extents on which PV back each logical extent segment.

bash
sudo lvdisplay -m labvg/datalv

Sample output (trimmed):

text
--- Logical volume ---
  LV Path                /dev/labvg/datalv
  ...
  --- Segments ---
  Logical extent 0 to 15:
    Type                linear
    Physical volume     /dev/loop24
    Physical extents    0 - 15

Use this when diagnosing split segments or uneven PV usage.

Advanced List internal LVs with -a

RAID, mirror, and thin pools expose component LVs. -a includes them in the report.

bash
sudo lvdisplay -a labvg 2>/dev/null | grep 'LV Name' | head -10

On a linear-only lab VG you see the same names as without -a.

lvdisplay — when to use / when not

Use lvdisplay when Use something else when
  • You need UUID, LE count, block device, or snapshot details
  • You are mapping extents to PVs (-m)
  • You are troubleshooting segment layout
  • Quick active/inactive list — lvscan
  • JSON or scripted reports — lvs --reportformat json
  • You need to change attributes — lvchange

lvdisplay vs lvs

lvdisplay lvs
Detail Full multi-line block One line per LV
Maps -m -o seg_pe_ranges
Scripts -c (legacy) -o, JSON reports
Command One line
lvdisplay Detailed LV report (this page)
pvs Physical volume summary

lvdisplay — interview corner

Which lvdisplay fields matter before lvremove?

Check LV Status, # open, and LV snapshot status. Non-zero # open means something still uses the device.

A strong answer is:

"I look at # open and LV Status — if open is zero and it's not a needed snapshot origin, it's safer to lvremove."

What are Current LE and Segments?

LE is logical extents allocated to the LV. Segments counts how many disjoint regions (for example after pvmove or mirrors) compose the LV.

A strong answer is:

"Current LE is extent count; Segments tells me if the LV is split across regions or PVs."

Why use lvdisplay -c?

Legacy scripts parse the colon-separated line. Modern automation should prefer lvs --reportformat json.

A strong answer is:

"-c is for legacy parsers — I'd use lvs JSON output for new automation."

When do you use lvdisplay -m?

When you need to see which PV and physical extents back each logical extent — capacity planning or after pvmove.

A strong answer is:

"lvdisplay -m when I need the PE-to-PV map for balance or migration troubleshooting."

Troubleshooting

Symptom Likely cause Fix
Failed to find logical volume Typo or VG inactive lvs -a, vgchange -ay
Empty output for one LV Foreign VG vgimport / vgchange -ay
Sizes differ from df Filesystem smaller than LV Normal — FS does not fill LV
-c fields confusing Undocumented positions Use lvs -o or man page field table
