In this tutorial we will cover different examples to configure network using ncmli command such as nmcli con reload, add ethernet connection using nmcli, add bond connection using nmcli in linux, add and configure network teaming using nmcli, configure networkmanager using nmcli, exit an existing connection with nmcli, nmcli enable dhcp, nmcli rename connection. nmcli remove static ipv4 address and much more.
Understanding nmcli
- nmcli is a command-line tool for controlling NetworkManager and reporting network status.
- It can be utilised as a replacement for nm-applet or other graphical clients. nmcli is used to create, display, edit, delete, activate, and deactivate network connections, as well as control and display network device status.
- Connections are stored in configuration files
- The NetworkManager service must be running to manage these files
Compare nm-settings with ifcfg-* directives (IPv4)
| nmcli con mod | ifcfg-* file | Effect |
|---|---|---|
ipv4.method manual |
BOOTPROTO=none |
IPv4 address configured statically |
ipv4.method auto |
BOOTPROTO=dhcp |
Will look for configuration settings from a DHCPv4 server |
ipv4.address "192.168.0.10/24" |
IPADDR=192.168.0.10PREFIX=24 |
Set static IPv4 address, network prefix |
ipv4.gateway 192.168.0.1 |
GATEWAY=192.168.0.1 |
Set IPv4 Gateway |
ipv4.dns 8.8.8.8 |
DNS1=8.8.8.8 |
Modify /etc/resolv.conf to use this nameserver |
ipv4.dns-search example.com |
DOMAIN=example.com |
Modify /etc/resolv.conf to use this domain in the search directive |
ipv4.ignore-auto-dns true |
PEERDNS=no |
Ignore DNS Server information from the DHCP Server |
connection.autoconnect yes |
ONBOOT=yes |
Automatically activate this connection on boot |
connection.id eth0 |
NAME=eth0 |
The name of this connection |
connection.interface-name eth0 |
DEVICE=eth0 |
The connection is bound to the network interface with this name |
802-3-ethernet.mac-address 08:00:27:4b:7a:80 |
HWADDR=08:00:27:4b:7a:80 |
The connection is bound to the network interface with this MAC Address |
ipv4.never-default no |
DEFROUTE=yes |
Never use provided interface's gateway as default gateway |
Compare nm-settings with ifcfg-* directives (IPv6)
| nmcli con mod | ifcfg-* file | Effect |
|---|---|---|
ipv6.method manual |
IPV6_AUTOCONF=no |
IPv6 is configured statically |
ipv6.method auto |
IPV6_AUTOCONF=yes |
Will configure network settings using SLAAC from router advertisements. |
ipv6.method dhcp |
IPV6_AUTOCONF=noDHCPV6C=yes |
Will configure network settings by using DHCPv6, but not SLAAC |
ipv6 . addresses |
IPV6ADDR=2001:db8::a/64 |
Sets static IPv6 Address and Gateway |
ipv6.dns . . . |
DNS0=. . . |
Modify /etc/resolv.conf to use this nameserver |
ipv6.dns-search example.com |
DOMAIN=example.com |
Modify /etc/resolv.conf to use to use this domain in the search directive |
ipv6.ignore-auto-dns true |
IPV6_PEERDNS=no |
Ignore DNS server information from the DHCP server |
connection.autoconnect yes |
ONBOOT=YES |
Automatically activates the connection at boot |
connection.id eth0 |
NAME=eth0 |
The name of this connection |
connection.interface-name eth0 |
DEVICE=eth0 |
The connection is bound to this network interface with this name |
802-3-ethernet.mac-address . . . |
HWADDR=. . . |
The connection is bound to the network interface with this MAC Address |
Brief list of nmcli commands syntax
| Command | Purpose |
|---|---|
nmcli dev status |
Show the Network Manager status of all network interfaces |
nmcli con show |
List all connections |
nmcli con show name |
List the current settings for the connection name |
nmcli con add con-name name .. |
Add a new connection named name |
nmcli con mod name .. |
Modify the connection name |
nmcli con reload |
Tell networkManager to reread the configuration files (useful after they have been edited by hand) |
nmcli con up name |
Activate the connection name |
nmcli dev dis dev |
Deactivate and disconnect the current connection on the network interface dev |
nmcli con del name |
Delete the connection name and its configuration file |
nmcli command examples (cheatsheet)
Below are some of the chosen nmcli command examples
1. Check if NetworkManager is running
You can use below command to check if NetworkManager is running or not
# nmcli -t -f RUNNING general
running
To get a general status
# nmcli general
STATE CONNECTIVITY WIFI-HW WIFI WWAN-HW WWAN
connected full enabled enabled enabled enabled
2. List all the available device
To view and list all the available devices on your Linux system
# nmcli dev status
DEVICE TYPE STATE CONNECTION
eth0 ethernet connected eth0
virbr0 bridge disconnected --
eth1 ethernet disconnected --
eth2 ethernet disconnected --
lo loopback unmanaged --
virbr0-nic tun unmanaged --
3. List all the available connections
To list all the available connections
# nmcli con show
NAME UUID TYPE DEVICE
eth1 01fa0bf4-b6bd-484f-a9a3-2b10ff701dcd ethernet eth1
eth0 2e9f0cdd-ea2f-4b63-b146-3b9a897c9e45 ethernet eth0
eth2 186053d4-9369-4a4e-87b8-d1f9a419f985 ethernet eth2
4. List all the configuration of interface
To view all the configured values (default and custom) of an interface
# nmcli con show eth2 connection.id: eth2 connection.uuid: 186053d4-9369-4a4e-87b8-d1f9a419f985 connection.stable-id: -- connection.type: 802-3-ethernet connection.interface-name: eth2 connection.autoconnect: yes <Output trimmed>
5. Check physical network device status
Now the status of all the connection network devices
# nmcli dev status DEVICE TYPE STATE CONNECTION eth1 ethernet connected eth1 eth0 ethernet connected eth0 eth2 ethernet disconnected -- lo loopback unmanaged --
6. Change hostname using nmcli
You can ideally change hostname using hostnamectl command, but you can also update hostname using nmcli
To get the current hostname
# nmcli general hostname centos-8.example.com
Next to update the hostname
# nmcli general hostname centos-8.golinuxcloud.com
Verify the same
# nmcli general hostname centos-8.golinuxcloud.com # hostname centos-8.golinuxcloud.com
7. Create a new ethernet connection and assign static IP Address
In this example nmcli configures the eth2 interface statically, using the IPv4 address and network prefix 10.10.10.4/24 and default gateway 10.10.10.1, but still auto connects at
startup and saves its configuration into /etc/sysconfig/network-scripts/ifcfg-eth2 file.
# nmcli con add con-name eth2 type ethernet ifname eth2 ipv4.method manual ipv4.address 10.10.10.4/24 ipv4.gateway 10.10.10.1 Connection 'eth2' (460b16aa-e755-403e-b0ec-5e1560dcc441) successfully added.
8. Create a new ethernet connection and assign DHCP IP Address
The following command will add a new connection for the interface eth2, which will get IPv4 networking information using DHCP and will autoconnect on startup. The configuration will be
saved in /etc/sysconfig/network-scripts/ifcfg-eth2 because the con-name is eth2
# nmcli con add con-name eth2 type ethernet ifname eth2 ipv4.method auto Connection 'eth2' (d75cb87f-cd15-40a2-9c33-138e69a06a1f) successfully added.
We can verify the same in the mapped interface configuration file
# egrep BOOTPROTO /etc/sysconfig/network-scripts/ifcfg-eth2 BOOTPROTO=dhcp
9. Create and configure bond connection (active-backup) with two slave interface
You can create bond connection with multiple slave interface using nmcli.
Delete any configuration file which exists for slave interface
# nmcli con del "eth1" # nmcli con del "Wired connection 1"
Add bond interface using nmcli. This command adds a master bond connection, naming the bonding interface mybond0 and using active-backup mode. I have given some dummy values for MII, UPDELAY and DOWNDELAY. If you wish to add primary interface using "primary=<ifname>"
# nmcli con add type bond ifname mybond0 bond.options "mode=active-backup,downdelay=5,miimon=100,updelay=10"
Connection 'bond-mybond0' (a5c76dbe-550b-4abf-8dc0-88184ade369e) successfully added.
Similarly for round-robin bonding you can use bond.options as "downdelay=5,miimon=100,mode=balance-rr,updelay=10"
Next add the slaves for mybond0 using nmcli. This command binds first slave to eth1 interface
# nmcli con add type ethernet ifname eth1 master mybond0
Connection 'bond-slave-eth1' (54dc4282-b90b-4469-9cbf-82bce042de85) successfully added.
This command binds slave 2 to eth2 interface
# nmcli con add type ethernet ifname eth2 master mybond0
Connection 'bond-slave-eth2' (41a5b4a6-8e6b-4df9-bff2-b67c5328311a) successfully added.
List the active connections. So we have our bond and slave interface with us.
# nmcli con show NAME UUID TYPE DEVICE bond-mybond0 25ce17b2-fffb-4bf1-a5a3-e7593299f303 bond mybond0 bond-slave-eth1 54dc4282-b90b-4469-9cbf-82bce042de85 ethernet eth1 bond-slave-eth2 41a5b4a6-8e6b-4df9-bff2-b67c5328311a ethernet eth2 eth0 d05aee6a-a069-4e55-9fe4-771ca3336db6 ethernet eth0
Here I am setting static IP Address, NetMask, Gateway, DNS and DNS Search to mybond0 using nmcli
# nmcli con mod bond-mybond0 ipv4.method manual ipv4.address 10.10.10.8/24 ipv4.gateway 10.10.10.1 ipv4.dns 8.8.8.8 ipv4.dns-search example.com
ipv4.method auto and do not provide any IP Address related details in the above commandVerify your mybond0 configuration file
# egrep 'BOOTPROTO|IPADDR|PREFIX|GATEWAY|DNS' /etc/sysconfig/network-scripts/ifcfg-bond-mybond0 BOOTPROTO=none IPADDR=10.10.10.8 PREFIX=24 GATEWAY=10.10.10.1 DNS1=8.8.8.8
refresh/reload the network configuration change for mybond0
# nmcli con up bond-mybond0
Connection successfully activated (master waiting for slaves) (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/11)
Verify the bond IP Address
# ip addr show mybond0 7: mybond0: <BROADCAST,MULTICAST,MASTER,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000 link/ether 08:00:27:0d:ca:0c brd ff:ff:ff:ff:ff:ff inet 10.10.10.8/24 brd 10.10.10.255 scope global noprefixroute mybond0 valid_lft forever preferred_lft forever
Verify the list of available connection
# nmcli con show --active
NAME UUID TYPE DEVICE
eth1 01fa0bf4-b6bd-484f-a9a3-2b10ff701dcd ethernet eth1
eth0 2e9f0cdd-ea2f-4b63-b146-3b9a897c9e45 ethernet eth0
10. Create and configure Network Bridge
I have written another article with detailed steps to create and configure network bridge using nmcli and nmtui separately on RHEL/CentOS 7 and 8 Linux.
11. Create and configure Network Teaming
I have written another article with detailed steps to create and configure NIC teaming with two slaves using nmcli validated on RHEL/CentOS 7/8 Linux
12. Reload connection using nmcli (restart)
Reload all connection files from disk. NetworkManager does not monitor changes to connection files by default. So you need to use this command in order to tell NetworkManager to re-read the connection profiles from disk when a change was made to them.
# nmcli con reload
13. Interactively add/edit a connection
You can use nmcli con edit to Edit an existing connection or add a new one, using an interactive editor. In the below example we will edit eth1's IP Address
# nmcli con edit eth1 ===| nmcli interactive connection editor |=== Editing existing '802-3-ethernet' connection: 'eth1' Type 'help' or '?' for available commands. Type 'print' to show all the connection properties. Type 'describe [.]' for detailed property description. You may edit the following settings: connection, 802-3-ethernet (ethernet), 802-1x, dcb, sriov, ethtool, match, ipv4, ipv6, tc, proxy nmcli> help ------------------------------------------------------------------------------ ---[ Main menu ]--- goto [ | ] :: go to a setting or property remove [.] | :: remove setting or reset property value set [. ] :: set property value describe [.] :: describe property print [all | [.]] :: print the connection verify [all | fix] :: verify the connection save [persistent|temporary] :: save the connection activate [] [/|] :: activate the connection back :: go one level up (back) help/? [] :: print this help nmcli :: nmcli configuration quit :: exit nmcli ------------------------------------------------------------------------------ nmcli> print ipv4.address ipv4.addresses: 10.10.10.4/24 nmcli> remove ipv4.address "10.10.10.4/24" nmcli> print ipv4.address ipv4.addresses: nmcli> set ipv4.address 10.10.10.5/24 Do you also want to set 'ipv4.method' to 'manual'? [yes]: yes nmcli> print ipv4.address ipv4.addresses: 10.10.10.5/24 nmcli> verify Verify connection: OK nmcli> save Connection 'eth1' (7e3a1246-1743-4bb8-9eab-09664ab996b8) successfully updated. nmcli> quit
Now verify your changes in eth1's configuration file
# egrep IPADDR /etc/sysconfig/network-scripts/ifcfg-eth1 IPADDR=10.10.10.5
14. Change ethernet connection BOOTPROTO from DHCP to Static
Now to change ethernet connection BOOTPROTO from DHCP to static using nmcli, we must modify ipv4.method directive to use manual
# nmcli con mod eth2 ipv4.method manual ipv4.address 10.10.10.4/24 ipv4.gateway 10.10.10.1
Now verify the network configuration file for eth2
# egrep 'BOOTPROTO|IPADDR|PREFIX|GATEWAY' /etc/sysconfig/network-scripts/ifcfg-eth2 BOOTPROTO=none IPADDR=10.10.10.4 PREFIX=24 GATEWAY=10.10.10.1
15. Change ethernet connection BOOTPROTO from Static to DHCP
Similarly to change ethernet connection BOOTPROTO from static to DHCP using nmcli, we must modify ipv4.method directive to use auto
# nmcli con mod eth2 ipv4.method auto
Now verify the eth2 network configuration file
# egrep 'BOOTPROTO|IPADDR|PREFIX|GATEWAY' /etc/sysconfig/network-scripts/ifcfg-eth2 BOOTPROTO=dhcp IPADDR=10.10.10.4 PREFIX=24 GATEWAY=10.10.10.1
As you see we still have IPADDR and other variables from previous command but they are considered null, because you can see my DHCP has assigned 10.10.10.5 to eth2
# ip addr show dev eth2 4: eth2: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000 link/ether 08:00:27:a8:19:0a brd ff:ff:ff:ff:ff:ff inet 10.10.10.5/24 brd 10.10.10.255 scope global noprefixroute dynamic eth2 valid_lft 1068sec preferred_lft 1068sec inet6 fe80::b81f:a58b:43f1:b8d3/64 scope link noprefixroute valid_lft forever preferred_lft forever
16. Change ONBOOT directive using nmcli
By default ONBOOT is yes in the interface configuration file. So to disable ONBOOT we must modify connection.autoconnect directive using nmcli
Verify the ONBOOT value before changing this directive
# egrep 'ONBOOT' /etc/sysconfig/network-scripts/ifcfg-eth2 ONBOOT=yes
Change ONBOOT directive, disable ONBOOT using nmcli
# nmcli con mod eth2 connection.autoconnect no
Re-verify the ONBOOT directive for eth2
# egrep 'ONBOOT' /etc/sysconfig/network-scripts/ifcfg-eth2 ONBOOT=no
17. Change DEFROUTE directive (Never use this network for default route)
By default any gateway we add for any ethernet connection will also be considered as default gateway, to turn off this directive use ipv4.never-default with nmcli
Before we make any change verify DEFROUTE directive in the eth2 configuration file
# egrep '^DEFROUTE' /etc/sysconfig/network-scripts/ifcfg-eth2 DEFROUTE=yes
So by default this directive is ON, we will disable the default gateway option for eth2. To turn off this directive we must select ipv4.never-default as "yes"
# nmcli con mod eth2 ipv4.never-default yes
Next verify the DEFROUTE directive for eth2
# egrep '^DEFROUTE' /etc/sysconfig/network-scripts/ifcfg-eth2 DEFROUTE=no
18. Disable IPv6 Address for ethernet connection (IPV6INIT)
By default both IPv4 and IPv6 connection type (IPV6INIT) is enabled for any ethernet connection type. To only use IPv4 and disable IPv6 using nmcli
Verify the existing status of IPv6 connection type for eth2
# egrep 'IPV6INIT' /etc/sysconfig/network-scripts/ifcfg-eth2 IPV6INIT=yes
So this is enabled, we will disable IPv6 connection type using ipv6.method directive with nmcli
# nmcli con mod eth2 ipv6.method ignore
ipv6.method are ignore, auto, dhcp, link-local, manual, shared. You can use the same options to enable/disable IPv4 using ipv4.methodNow re-verify the IPV6INIT directive from eth2 config file
# egrep 'IPV6INIT' /etc/sysconfig/network-scripts/ifcfg-eth2 IPV6INIT=no
19. Change "Automatically Connect" Directive
By default any ethernet connection will be allowed to automatically connect, you can modify this using
# nmcli con mod eth2 connection.autoconnect no
20. Add or Modify DNS to existing connection
You can use ipv4.dns to add DNS server to an new connection or modify any existing connection using nmcli.
Currently there are no DNS server IP provided for eth1
# egrep DNS /etc/sysconfig/network-scripts/ifcfg-eth1
Next modify connection to add DNS Server IP Address
# nmcli con mod eth1 ipv4.dns 8.8.8.8
Verify the eth1 config file
[root@rhel-8 ~]# egrep DNS /etc/sysconfig/network-scripts/ifcfg-eth1 DNS1=8.8.8.8
21. Append single/multiple DNS Server to connection
Use + prefix with ipv4.dns to append new DNS IP Addresses to an existing connection using nmcli. In the previous example we added 8.8.8.8 as my DNS server for eth1. Now we will append 8.2.2.2 to the same connection
# nmcli con mod eth1 +ipv4.dns 8.2.2.2
Verify the eth1 configuration file
# egrep DNS /etc/sysconfig/network-scripts/ifcfg-eth1 DNS1=8.8.8.8 DNS2=8.2.2.2
22. Remove single/multiple DNS Server from connection
As it is understood, with + we append so with - we remove single/multiple entries of DNS Server from the interface connection using nmcli.
# nmcli con mod eth1 -ipv4.dns 8.2.2.2,8.8.8.8
Verify the eth1 configuration file
# egrep DNS /etc/sysconfig/network-scripts/ifcfg-eth1
23. Display selected fields with values of connection
You can list all the configured values of a connection using "nmcli con show <ifname>" but that gives you a long list of details, you can actually also get selected value of the provided directive of an individual connection
To get the IPv4 Address of eth1
# nmcli -g ip4.address connection show eth1
10.10.10.4/24
You can use -g to print values from specific fields using nmcli
# nmcli -g ip4.address,ipv4.dns connection show eth1
8.8.8.8,8.2.2.2
10.10.10.4/24
But here as you see we do not get a field to value mapping. You can use -f to specify what fields (column names) should be printed using nmcli. Valid field names differ for specific commands. List available fields by providing an invalid value to the --fields option.
# nmcli -f ipv4.dns,ipv4.addresses,ipv4.gateway con show eth1
ipv4.dns: 8.8.8.8,8.2.2.2
ipv4.addresses: 10.10.10.4/24
ipv4.gateway: 10.10.10.1
24. Monitor connection and device activity
Using nmcli monitor you can observe NetworkManager activity. Watches for changes in connectivity state, devices or connection profiles. Here in this example we will execute nmcli monitor for eth1 in one terminal, and on the other terminal we will make some modification to eth1 connection
# nmcli con mod eth1 ipv4.method manual ipv4.address 10.10.10.4/24
As you see, after the modification, the monitor command gives below output
# nmcli con monitor eth1
eth1: connection profile changed
25. Activate a connection
Just opposite to what we used above, we will use nmcli con up
# nmcli con up eth2
Connection successfully activated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/23)
Verify the list of available connection
# nmcli con show --active
NAME UUID TYPE DEVICE
eth1 01fa0bf4-b6bd-484f-a9a3-2b10ff701dcd ethernet eth1
eth0 2e9f0cdd-ea2f-4b63-b146-3b9a897c9e45 ethernet eth0
eth2 186053d4-9369-4a4e-87b8-d1f9a419f985 ethernet eth2
26. De-activate a connection
Deactivate a connection from a device without preventing the device from further auto-activation using nmcli con down <ifname>. Multiple connections can be passed to the command.
# nmcli con down eth1
Connection 'eth1' successfully deactivated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/32)
Verify the list of active connections
# nmcli con show --active
NAME UUID TYPE DEVICE
eth0 d05aee6a-a069-4e55-9fe4-771ca3336db6 ethernet eth0
27. Delete connection
Lastly in nmcli command examples, you can delete all type of available connection using "nmcli con del <ifname>"
# nmcli con del bond-mybond0 bond-slave-eth1 bond-slave-eth2
Connection 'bond-mybond0' (25ce17b2-fffb-4bf1-a5a3-e7593299f303) successfully deleted.
Connection 'bond-slave-eth1' (54dc4282-b90b-4469-9cbf-82bce042de85) successfully deleted.
Connection 'bond-slave-eth2' (41a5b4a6-8e6b-4df9-bff2-b67c5328311a) successfully deleted.
Lastly I hope the steps from the article with nmcli command examples (cheatsheet) on Linux was helpful. So, let me know your suggestions and feedback using the comment section.
References:
man page nmcli
man page nmcli-examples
how do you tell it not to use uuid’s considering a virtual-environment where the vNIC could potentially change with vMotion, “hw” upgrades, etc.
Thanks a lot for the syntax.
Sorry if i didn’t explain clearly.
I understand # nmcli con mod “enp1s0” +ipv4.addresses “192.168.122.3/24” syntax will allow 192.168.122.3/24 inbount to enp1s0.
I am after a syntax where i can only allow incoming traffic into specific network interface eg: enp1s0 from one MAC address but not IP.
I have a situation where i need one of the network interface in linux server to only accept traffic from a directly connected camera MAC. So if another camera or device is connected, the server won’t accept traffic from the end device other than whitelisted MAC for that network interface.
Thanks for the added clarification. I doubt this can be achieved with
nmcliand should be handled with firewall.If you have IPtables then you can use this rule assuming you want to allow traffic from
00:11:22:33:44:55If you are using firewalld then you can use rich rules.
any suggestion for adding or blocking MAC addresses instead of IP address?
I didn’t get your question? You want to block a MAC or subnet in the network? this is something you should do with your firewall
Well done – just the post I was looking for. I’d like to suggest you also insert an item for the management of multiple IPs on the same interface, along the lines of:
Add secondary
Remove secondary
Thank You for adding this.
Congratulation for the brilliant explanation! And now I understand the problems when trying to use networkmanager, For I have to study networkmanagers expressions first for they are really quite different to my knowledge about networkwhich I got by using ip and kernel.
Would you please review the misnomer which nowadays are tried to change for hardware?
well mannered doc to understand and study. Helping for my RHCSA exam.
Thanks bro.
Just want to say thank you for you hard work! It has/will be instrumental in my RHCSA/RHCE journey.
Stay Safe
…..and great hopes for your journey!
