Configure LDAP Search Limits in 389 Directory Server

A single broad LDAP search can walk thousands of candidate entries and return more data than an application can handle. Directory Server enforces size, time, look-through, and ID-list limits so one client cannot exhaust the instance.

This guide covers search resource limits in 389 Directory Server:

• Global instance limits in cn=config
• Global LDBM database plug-in limits for look-through and ID-list behaviour
• Per-user operational overrides for application bind accounts
• Paged and range search limits
• Access-log indicators for limit and index problems

Before you start:

• Install 389 Directory Server — running instance with a suffix (this lab uses ldap1 on dc=example,dc=com)
• dsconf commands — online configuration
• Configure 389 Directory Server Indexes for Faster LDAP Searches — notes=U and missing-index diagnosis

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

The lab instance is ldap1 on ldap1.example.com with LDAP port 389. The suffix dc=example,dc=com is served by backend userroot.

Understand search resource limits

Directory Server applies limits at several layers. Instance-wide settings in cn=config cap ordinary searches for most bind identities. Look-through, ID-list, paged look-through, paged ID-list, and range look-through limits live on the global LDBM database plug-in entry at cn=config,cn=ldbm database,cn=plugins,cn=config. The command dsconf ldap1 backend config get reads that global database configuration; it does not read an individual backend such as userroot. Per-entry operational attributes on a bind DN can tighten or relax limits for one application account.

LDAP client bind
        |
        v
Per-entry operational limits (nsSizeLimit, nsTimeLimit, ...)
        |
        v
Global instance limits (nsslapd-sizelimit, nsslapd-timelimit, ...)
        |
        v
Global LDBM plug-in limits (nsslapd-lookthroughlimit, nsslapd-idlistscanlimit, ...)
        |
        v
Search executes or stops with LDAP result 4 (size limit) or 3 (time limit)

Size limit:
How many entries can be returned

Look-through limit:
How many entries may be examined to find those results

ID-list scan limit:
How many candidate IDs may be loaded from an index

A search can return only one entry but still examine thousands of candidates.

Clarifications that prevent the most common mistakes:

• Directory Manager bypasses global size and time limits. Testing nsslapd-sizelimit with Directory Manager will not show the same behaviour application accounts see.
• Per-user limits override global defaults for that bind DN. When uid=reporting-app carries nsSizeLimit: 2, that value wins over nsslapd-sizelimit for searches bound as that user.
• -1 means unlimited only where the attribute schema documents that value. Use it sparingly on trusted accounts.
• Paged limit 0 inherits the ordinary limit. When nsslapd-pagedsizelimit is 0, paged searches use nsslapd-sizelimit. The same fallback design applies to nsslapd-pagedlookthroughlimit and nsslapd-pagedidlistscanlimit. Use -1 only when the paged limit must be explicitly unlimited.
• Client page size is separate from nsslapd-pagedsizelimit. The client requests a batch size through the paged-results control, for example ldapsearch -E pr=50/noprompt. nsslapd-pagedsizelimit caps the total entries returned by the complete paged search operation.
• notes=U is not only a missing-index signal. It also appears when an index key matches more entry IDs than nsslapd-idlistscanlimit allows. See Configure LDAP indexes for index creation.

Check current search limits

Read the active instance configuration before changing anything. Recording the baseline makes rollback straightforward.

dsconf ldap1 config get nsslapd-sizelimit nsslapd-timelimit nsslapd-pagedsizelimit

nsslapd-sizelimit: 2000
nsslapd-timelimit: 3600
nsslapd-pagedsizelimit: 0

The lab allows up to 2000 entries per ordinary search and 3600 seconds of processing time. nsslapd-pagedsizelimit: 0 means paged searches inherit nsslapd-sizelimit.

Read the global LDBM database plug-in limits:

dsconf ldap1 backend config get | grep -E 'lookthrough|idlist|paged|rangelookthrough'

nsslapd-lookthroughlimit: 5000
nsslapd-pagedlookthroughlimit: 0
nsslapd-idlistscanlimit: 4000
nsslapd-pagedidlistscanlimit: 0
nsslapd-rangelookthroughlimit: 5000

On the tested upstream 389 Directory Server 3.2.0 build, dsconf reported nsslapd-idlistscanlimit: 4000. Do not assume that value on other builds. Current RHDS 13 documentation marks the global setting as deprecated and documents different defaults. Inspect the active value on the installed release.

Paged look-through and paged ID-list values of 0 inherit nsslapd-lookthroughlimit and nsslapd-idlistscanlimit respectively.

Create the reporting-app service account when it does not exist yet. Save reporting-app.ldif:

dn: uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com
objectClass: top
objectClass: person
objectClass: organizationalPerson
objectClass: inetOrgPerson
cn: Reporting Application
sn: Application
uid: reporting-app
userPassword: ReportingAppPass!

ldapadd -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -f reporting-app.ldif

Grant read access under ou=People before limit tests. Save reporting-app-aci.ldif:

dn: ou=people,dc=example,dc=com
changetype: modify
add: aci
aci: (targetattr="*")(version 3.0; acl "reporting-app read people"; allow (read,search,compare) userdn="ldap:///uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com";)

ldapmodify -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -f reporting-app-aci.ldif

Verify the ACI was accepted, then confirm reporting-app can search under ou=people. See ACI examples when the bind succeeds but searches return no entries.

Configure search size, time, and look-through limits

Size limit

Lower the global size limit temporarily so the lab can demonstrate result code 4:

dsconf ldap1 config replace nsslapd-sizelimit=3

Successfully replaced value(s) for 'nsslapd-sizelimit': '3'

No restart is required for nsslapd-sizelimit.

Test with Directory Manager first to confirm the bypass:

Directory queries in this section use the ldapsearch command.

ldapsearch -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -b "ou=people,dc=example,dc=com" -s sub "(objectClass=inetOrgPerson)" dn 2>&1 | tail -3

Directory Manager still returns every matching entry even when nsslapd-sizelimit=3. Use an application bind DN when you validate limit changes.

Bind as reporting-app:

ldapsearch -x -H ldap://ldap1.example.com:389 -D "uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com" -W -b "ou=people,dc=example,dc=com" -s sub "(objectClass=inetOrgPerson)" dn

result: 4 Size limit exceeded
# numEntries: 3

The server returned three entries and stopped with LDAP result code 4.

Restore the global size limit:

dsconf ldap1 config replace nsslapd-sizelimit=2000

Time limit

Set a global time limit in seconds:

dsconf ldap1 config replace nsslapd-timelimit=60

Successfully replaced value(s) for 'nsslapd-timelimit': '60'

A tiny lab suffix often finishes every search before the limit is reached, so this build may not produce err=3 during testing. On a sufficiently large suffix, bind as a non-Directory-Manager account, run an intentionally expensive search, and look for Time limit exceeded (3) in the client output and access log.

Restore the lab default when testing finishes:

dsconf ldap1 config replace nsslapd-timelimit=3600

Look-through limit

Raise the global look-through limit only when representative filters genuinely need to examine more candidates:

dsconf ldap1 backend config set --lookthroughlimit=10000

Successfully updated database configuration

dsconf ldap1 backend config get | grep nsslapd-lookthroughlimit

nsslapd-lookthroughlimit: 10000

Look-through limits apply while the server evaluates a filter, not only when entries are returned. A filter that returns 250 entries can still examine 8,000 candidates along the way.

Restore the original value after the demonstration:

dsconf ldap1 backend config set --lookthroughlimit=5000

Do not increase the look-through limit merely to hide an indexing problem.

Configure paged and range search limits

Simple paged results let a client walk a large result set in smaller chunks using the LDAP paged-results control.

Check the current paged size limit:

dsconf ldap1 config get nsslapd-pagedsizelimit

nsslapd-pagedsizelimit: 0

When the value is 0, paged searches inherit nsslapd-sizelimit. Set a positive value such as 500 with dsconf ldap1 config replace nsslapd-pagedsizelimit=500 when a complete paged search must not return more than 500 entries total. The client's requested page size in the paged-results control remains a separate value.

Paged look-through and paged ID-list limits are global LDBM plug-in settings:

dsconf ldap1 backend config get | grep -E 'pagedlookthrough|pagedidlist'

nsslapd-pagedlookthroughlimit: 0
nsslapd-pagedidlistscanlimit: 0

Values of 0 inherit nsslapd-lookthroughlimit and nsslapd-idlistscanlimit. Use -1 on the paged attribute when the paged search must be explicitly unlimited.

Range searches use nsslapd-rangelookthroughlimit. The lab default is 5000. Directory Manager is not exempt from range look-through limits.

Test the simple paged-results control

This command proves the client and server support paging. It does not by itself prove enforcement of nsslapd-pagedsizelimit; that requires a suffix large enough to exceed the configured total paged cap.

ldapsearch -x -H ldap://ldap1.example.com:389 -D "uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com" -W -b "ou=people,dc=example,dc=com" -s sub "(objectClass=inetOrgPerson)" uid -E pr=50/noprompt 2>&1 | tail -6

When paging works, the access log records notes=P on the RESULT lines. Test total paged-search enforcement separately on a populated suffix with nsslapd-pagedsizelimit or nsPagedSizeLimit set below the result count.

Configure limits for one user or application

Service accounts often need tighter caps than the global defaults. Store overrides on the user entry as operational attributes. The example below demonstrates common controls; it is not the complete supported set. Official documentation also lists nsIDListScanLimit, nsPagedLookThroughLimit, and nsPagedIDListScanLimit. Range look-through has no per-user counterpart.

Save reporting-app-limits.ldif:

dn: uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com
changetype: modify
replace: nsSizeLimit
nsSizeLimit: 2
-
replace: nsTimeLimit
nsTimeLimit: 60
-
replace: nsLookThroughLimit
nsLookThroughLimit: 5000
-
replace: nsPagedSizeLimit
nsPagedSizeLimit: 100

ldapmodify -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -f reporting-app-limits.ldif

Read the effective per-user limits with +:

ldapsearch -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -b "uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com" -s base "(objectClass=*)" "+" nsSizeLimit nsTimeLimit nsLookThroughLimit nsPagedSizeLimit

nsSizeLimit: 2
nsTimeLimit: 60
nsLookThroughLimit: 5000
nsPagedSizeLimit: 100

With nsslapd-sizelimit at 2000, the per-user nsSizeLimit: 2 still wins for this bind DN:

ldapsearch -x -H ldap://ldap1.example.com:389 -D "uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com" -W -b "ou=people,dc=example,dc=com" -s sub "(objectClass=inetOrgPerson)" dn

result: 4 Size limit exceeded
# numEntries: 2

Protect operational limit attributes with ACIs so users cannot raise their own caps.

Tune ID-list scan limits

When one index key points at a very large candidate set, Directory Server can treat the search as partially unindexed even though the attribute is indexed.

Indexed value matches 50,000 entry IDs
        |
        v
ID-list scan limit is 4,000
        |
        v
Server stops loading that index list
        |
        v
Search is processed as an unindexed search

Check the active global value:

dsconf ldap1 backend config get | grep nsslapd-idlistscanlimit

nsslapd-idlistscanlimit: 4000

On the tested upstream 389 Directory Server 3.2.0 build, dsconf reported 4000. Current RHDS 13 documentation states that changes to the global ID-list setting affect subsequent searches without a restart. Because the attribute is deprecated and its defaults vary by release, inspect rather than change it unless performance testing demonstrates a specific need. Prefer selective nsIndexIDListScanLimit rules, narrower filters, and better indexes over broadly raising the global setting.

Fine-grained ID-list rules

Fine-grained rules modify a specific index entry in a specific backend. The objectClass equality index under userroot is a common target for (&(objectClass=inetOrgPerson)(...)) filters.

Save objectclass-idlist-limit.ldif:

dn: cn=objectclass,cn=index,cn=userroot,cn=ldbm database,cn=plugins,cn=config
changetype: modify
add: nsIndexIDListScanLimit
nsIndexIDListScanLimit: limit=0 type=eq flags=AND values=inetOrgPerson

ldapmodify -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -f objectclass-idlist-limit.ldif

The syntax is limit=NNN [type=eq[,sub,...]] [flags=AND[,XXX,...]] [values=val[,val,...]]. Setting limit=0 for objectClass=inetOrgPerson in an AND filter deliberately avoids building an ID list for that value.

Remove the rule when the lab demonstration finishes. Save remove-objectclass-idlist-limit.ldif:

dn: cn=objectclass,cn=index,cn=userroot,cn=ldbm database,cn=plugins,cn=config
changetype: modify
delete: nsIndexIDListScanLimit
nsIndexIDListScanLimit: limit=0 type=eq flags=AND values=inetOrgPerson

ldapmodify -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -f remove-objectclass-idlist-limit.ldif

Diagnose search-limit problems in access logs

/var/log/dirsrv/slapd-ldap1/access

grep -E 'notes=.*(A|U|P)|err=4|err=3' /var/log/dirsrv/slapd-ldap1/access | tail -5

[17/Jul/2026:23:47:01 +0530] conn=79 op=1 RESULT err=0 tag=101 nentries=1 etime=0.014392270 notes=U details="Partially Unindexed Filter"
[17/Jul/2026:23:47:19 +0530] conn=85 op=1 RESULT err=4 tag=101 nentries=3 etime=0.004090297
[17/Jul/2026:23:47:47 +0530] conn=3 op=7 RESULT err=0 tag=101 nentries=50 etime=0.022746790 notes=P details="Paged Search"

notes=U does not always mean a missing index file. When every indexed attribute is present but notes=U persists, check whether the ID-list scan limit was exceeded before adding more indexes.

Correlate SRCH, BIND, and RESULT lines by conn and op numbers.

Test and troubleshoot

Security and operational recommendations:

• Test limit changes with the real application bind DN, not Directory Manager.
• Avoid -1 unlimited size or time limits except on tightly controlled administrative accounts.
• Keep per-service-account limit attributes in change control alongside ACIs.
• Use simple paged results for large directory browsers instead of raising global size limits alone.
• Treat notes=U as a limit or index design problem before blindly raising nsslapd-idlistscanlimit.
• Change one setting at a time and retest with access logs.

What's next

After you complete this guide, continue with:

• Configure LDAP Threads and Connections in 389 Directory Server — worker threads under heavy search load
• Configure Virtual List View Indexes in 389 Directory Server — paged browsing for large result sets
• Tune LMDB, Entry Cache and DN Cache in 389 Directory Server — LMDB tuning when limits are raised
• Benchmark 389 Directory Server Performance with ldclt and logconv — measure the effect of limit changes

Summary

1. Instance attributes in cn=config cap ordinary searches; global LDBM plug-in attributes control look-through and ID-list behaviour.
2. Directory Manager bypasses global size and time limits; validate changes with application bind accounts.
3. Per-entry operational attributes override global defaults for that bind DN.
4. Paged limit 0 inherits the corresponding ordinary limit; -1 means explicitly unlimited where the schema allows it.
5. nsslapd-idlistscanlimit behaviour varies by release; prefer fine-grained nsIndexIDListScanLimit rules and better filters over broad global changes.
6. notes=U signals unindexed work or an ID-list cap, not only a missing index file.

For worker threads, listeners, and connection descriptors, see Configure LDAP threads and connections.
