389 Directory Server Threads: nsslapd-threadnumber and Listeners

When many clients connect at once, worker threads, listener threads, and file descriptors determine whether operations queue or fail. This guide covers thread and connection tuning in 389 Directory Server.

Before you start:

Install 389 Directory Server — running instance (ldap1 on dc=example,dc=com in this lab)
dsconf commands — online configuration
Configure LDAP Search Limits in 389 Directory Server — size and time caps that protect workers from expensive searches

IMPORTANT

This guide covers nsslapd-threadnumber, nsslapd-numlisteners, nsslapd-maxthreadsperconn, idle and I/O timeouts, and file descriptors. It does not configure search limits, LMDB cache, or host-level TCP stack tuning.

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

Understand worker and connection resources

Thread or limit	Attribute	Purpose
Worker threads	`nsslapd-threadnumber`	Execute LDAP operations (`-1` = auto-tune from CPU count; takes effect at startup after restart)
Listener threads	`nsslapd-numlisteners`	Monitor established client connections (valid range `1`–`4`; restart required)
Per-connection workers	`nsslapd-maxthreadsperconn`	Cap simultaneous asynchronous operations from one connection (`1` through active worker count)
Idle timeout	`nsslapd-idletimeout` / `nsIdleTimeout`	Close unused connections after N seconds (`0` disables automatic idle disconnect)
I/O block timeout	`nsslapd-ioblocktimeout`	Milliseconds to wait on blocked network I/O (lab default `10000` = 10 seconds)
File descriptors	`nsslapd-maxdescriptors` / `nsslapd-reservedescriptors`	Total descriptor ceiling and reserved pool for non-client use
Socket backlog	`nsslapd-listen-backlog-size`	Pending socket queue for incoming connections during bursts

nsslapd-numlisteners configures threads that monitor established client connections. nsslapd-listen-backlog-size controls the pending socket queue for incoming connections. Backlog tuning does not increase the number of threads monitoring established connections.

Increasing worker threads cannot fix unindexed searches, slow storage, lock contention, or client-side delays. Too many threads can add scheduling overhead without raising throughput.

Check current thread and connection settings

bash

dsconf ldap1 config get nsslapd-threadnumber nsslapd-numlisteners nsslapd-maxthreadsperconn nsslapd-maxdescriptors nsslapd-reservedescriptors nsslapd-listen-backlog-size nsslapd-idletimeout nsslapd-ioblocktimeout

output

nsslapd-threadnumber: 16
nsslapd-numlisteners: 1
nsslapd-maxthreadsperconn: 5
nsslapd-maxdescriptors: 524288
nsslapd-reservedescriptors: 65
nsslapd-listen-backlog-size: 128
nsslapd-idletimeout: 3600
nsslapd-ioblocktimeout: 10000

The lab baseline is sixteen worker threads, one listener, five operations per connection, and 524288 max descriptors with 65 reserved.

The configured descriptor allowance for TCP clients is approximately nsslapd-maxdescriptors minus nsslapd-reservedescriptors, which is 524223 in this lab. This is not a guaranteed simultaneous-client count. The live dtablesize monitor value reports the Directory Server connection-table size; in this lab it is 63936, which is a lower practical connection-slot boundary. Monitor dtablesize, currentconnections, the operating-system descriptor limit, and the error log together. Changes to either descriptor setting require a restart.

Tune worker threads

Prefer automatic tuning unless repeatable load tests justify a fixed count:

bash

dsconf ldap1 config replace nsslapd-threadnumber=-1

output

Successfully replaced value(s) for 'nsslapd-threadnumber': '-1'

nsslapd-threadnumber defines the worker threads created at startup. Restart so auto-tuning takes effect:

bash

dsctl ldap1 restart

Read the attribute after restart:

bash

dsconf ldap1 config get nsslapd-threadnumber

output

nsslapd-threadnumber: 16

Setting -1 enables auto-tuning, but config get displays the calculated active thread count. On this lab host, which falls in the 1–16 CPU range, the value is 16. That displayed number does not mean the configuration has become a fixed manual value.

Automatic behaviour on current RHDS guidance:

text


1–16 CPU threads:
  16 Directory Server worker threads

17–512 CPU threads:
  One worker per CPU thread

More than 512 CPU threads:
  Maximum 512 worker threads

Return to a fixed pool only when measurement requires it. The fixed value takes effect after restart:

bash

dsconf ldap1 config replace nsslapd-threadnumber=16

bash

dsctl ldap1 restart

Auto-tuning should remain the normal recommended end state unless repeatable load testing justifies a fixed value.

Tune listener threads and per-connection limits

Connection listener threads

bash

dsconf ldap1 config get nsslapd-numlisteners

output

nsslapd-numlisteners: 1

The documented default is 1 and the valid range is 1 through 4. Increase listener threads only when testing with many established connections shows that one listener cannot service connection activity efficiently:

bash

dsconf ldap1 config replace nsslapd-numlisteners=4

Restart after changing listener count:

bash

dsctl ldap1 restart

Pending connection bursts during accept are controlled separately by nsslapd-listen-backlog-size, not by adding listener threads.

Per-connection worker limit

bash

dsconf ldap1 config get nsslapd-maxthreadsperconn

output

nsslapd-maxthreadsperconn: 5

This limit matters when one LDAP connection submits several asynchronous operations. Search the access log for per-connection pressure before raising the cap:

bash

grep -E 'notes=.*(N|B)' /var/log/dirsrv/slapd-ldap1/access

output

conn=66 op=973 RESULT err=0 tag=101 nentries=2 etime=0.000571769 notes=N details="Not synchronous operation"

notes=N identifies asynchronous operations that may consume multiple workers. notes=B identifies an operation that is delaying other incoming operations on the same connection.

Raise the limit only when monitoring supports it. The valid range is 1 through the active worker-thread count:

bash

dsconf ldap1 config replace nsslapd-maxthreadsperconn=10

output

Successfully replaced value(s) for 'nsslapd-maxthreadsperconn': '10'

Verify the change:

bash

dsconf ldap1 config get nsslapd-maxthreadsperconn

output

nsslapd-maxthreadsperconn: 10

Monitor while the application exercises concurrent operations on one connection:

bash

dsconf ldap1 monitor server

Watch maxthreadsperconnhits and currentconnectionsatmaxthreads during the test. Increasing this value reallocates more of the global worker pool to a single connection. It can help a legitimate asynchronous client but can also let one connection consume a disproportionate number of workers.

Restore the lab baseline after testing:

bash

dsconf ldap1 config replace nsslapd-maxthreadsperconn=5

Do not raise nsslapd-maxthreadsperconn merely because an application opens many separate connections.

Configure idle, I/O, and connection limits

Global idle timeout

Close idle connections after ten minutes:

bash

dsconf ldap1 config replace nsslapd-idletimeout=600

output

Successfully replaced value(s) for 'nsslapd-idletimeout': '600'

nsslapd-idletimeout: 0 disables automatic idle disconnection. A value that is too low can interrupt long-lived application pools and replication initialization.

Per-user idle timeout

Service or replication accounts can carry a longer idle timeout without weakening the global policy. With the global value at 600 seconds above, grant reporting-app thirty minutes. Save application-idle-timeout.ldif:

ldif


dn: uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com
changetype: modify
replace: nsIdleTimeout
nsIdleTimeout: 1800

bash

ldapmodify -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -f application-idle-timeout.ldif

output

modifying entry "uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com"

bash


ldapsearch -x -H ldap://ldap1.example.com:389 \
  -D "cn=Directory Manager" -W \
  -b "uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com" \
  -s base "(objectClass=*)" nsIdleTimeout

output

nsIdleTimeout: 1800

Per-user nsIdleTimeout overrides nsslapd-idletimeout for that bind DN. Selected accounts can also receive a tighter timeout when a stricter per-application limit is required.

Blocked I/O timeout

nsslapd-ioblocktimeout closes a connection when the client makes no progress during a read or write. The lab default 10000 is ten seconds. Raising the value allows slow clients longer to recover, but also retains blocked connections and their descriptors for longer.

bash

dsconf ldap1 config replace nsslapd-ioblocktimeout=180000

output

Successfully replaced value(s) for 'nsslapd-ioblocktimeout': '180000'

180000 milliseconds is 180 seconds. Use such a high value only when legitimate slow clients are being disconnected by the default ten-second timeout. Confirm the unit and supported range in the configuration reference for the installed release before selecting a production value.

File descriptors

bash

dsconf ldap1 config get nsslapd-maxdescriptors nsslapd-reservedescriptors

Check the systemd unit limit before raising Directory Server descriptors:

bash

systemctl show dirsrv@ldap1 -p LimitNOFILE

output

LimitNOFILE=524288

The service limit matches nsslapd-maxdescriptors: 524288 on the lab host. nsslapd-reservedescriptors protects descriptors needed for indexes, databases, logs, replication, chaining, and other non-client activity. Do not set nsslapd-maxdescriptors above the operating-system limit.

Socket backlog

bash

dsconf ldap1 config replace nsslapd-listen-backlog-size=256

Use backlog tuning only when connection bursts fill the pending socket queue. It does not add listener threads for established connections.

Monitor connections, threads, and queued operations

bash

dsconf ldap1 monitor server

Sample output (trimmed):

output

threads: 18
currentconnections: 1
totalconnections: 2
currentconnectionsatmaxthreads: 0
maxthreadsperconnhits: 0
dtablesize: 63936
readwaiters: 0
opsinitiated: 12
opscompleted: 11

currentconnections is the open connection count right now. maxthreadsperconnhits shows how often clients exceeded nsslapd-maxthreadsperconn. dtablesize reports the connection-table size. The supported operation counters are opsinitiated and opscompleted.

threads reports the current number of active request-handling threads. Red Hat documents that internal tasks such as replication can create additional threads beyond the nsslapd-threadnumber pool. On this lab host config get shows 16 configured workers while monitor reports threads: 18. Use nsslapd-threadnumber for the startup worker pool and threads for the live count.

Restore lab baseline after testing

The examples above change production-impacting values. Restore the lab defaults and restart when tuning exercises finish:

bash


dsconf ldap1 config replace nsslapd-threadnumber=-1
dsconf ldap1 config replace nsslapd-numlisteners=1
dsconf ldap1 config replace nsslapd-maxthreadsperconn=5
dsconf ldap1 config replace nsslapd-idletimeout=3600
dsconf ldap1 config replace nsslapd-ioblocktimeout=10000
dsconf ldap1 config replace nsslapd-listen-backlog-size=128

bash

dsctl ldap1 restart

Remove the per-user idle override when the exercise used application-idle-timeout.ldif. Save remove-application-idle-timeout.ldif:

ldif


dn: uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com
changetype: modify
delete: nsIdleTimeout

bash

ldapmodify -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -W -f remove-application-idle-timeout.ldif

output

modifying entry "uid=reporting-app,ou=ServiceAccounts,dc=example,dc=com"

Verify the restored configuration:

bash

dsconf ldap1 config get nsslapd-threadnumber nsslapd-numlisteners nsslapd-maxthreadsperconn nsslapd-idletimeout nsslapd-ioblocktimeout nsslapd-listen-backlog-size

output

nsslapd-threadnumber: 16
nsslapd-numlisteners: 1
nsslapd-maxthreadsperconn: 5
nsslapd-idletimeout: 3600
nsslapd-ioblocktimeout: 10000
nsslapd-listen-backlog-size: 128

After restart with nsslapd-threadnumber=-1, config get may still display the calculated thread count such as 16. That is expected auto-tuning behaviour, not a fixed manual setting.

Troubleshoot thread and connection problems

Symptom	Likely cause	Fix
`maxthreadsperconnhits` climbing	Too many concurrent ops per connection	Raise `nsslapd-maxthreadsperconn` within the worker count or spread load across connections
`notes=N` or `notes=B` in access logs	Asynchronous or blocking operations on one connection	Review client behaviour before raising per-connection limits
Connections dropped after idle periods	`nsslapd-idletimeout` or load-balancer timeout	Align server, firewall, and client pool keepalive settings; consider per-user `nsIdleTimeout`
Bind failures under load	Descriptor limit mismatch	Align `nsslapd-maxdescriptors` with `LimitNOFILE`; check usable capacity minus reserved descriptors
`Not listening for new connections -- too many fds open`	Descriptor exhaustion	Review `dtablesize`, `currentconnections`, and reserved descriptors
Thread count unchanged after `-1`	Auto-tune displays calculated value	Read `monitor server` `threads` and CPU count
Increasing threads does not help	Bottleneck is indexing, I/O, or locks	Restore automatic tuning; fix search and storage problems first

What's next

After you complete this guide, continue with:

Tune LMDB, Entry Cache and DN Cache in 389 Directory Server — LMDB cache and reader settings
Benchmark 389 Directory Server Performance with ldclt and logconv — baseline before changing thread counts
Configure 389 Directory Server Indexes for Faster LDAP Searches — index coverage for concurrent searches
Configure Low Disk Space Protection in 389 Directory Server — I/O pressure under load

Summary

Prefer nsslapd-threadnumber=-1 unless load tests justify a fixed count after restart.
Listener threads default to 1; raise nsslapd-numlisteners only when many established connections show response-time degradation.
Usable client descriptor capacity is approximately nsslapd-maxdescriptors minus nsslapd-reservedescriptors.
Monitor currentconnectionsatmaxthreads, maxthreadsperconnhits, readwaiters, dtablesize, and access-log wtime after every change.
Fix expensive searches through search limits and indexes before adding workers.

References

Frequently Asked Questions

1. What happens when nsslapd-threadnumber is set to -1?

A value of -1 enables automatic thread tuning based on available CPUs. After restart, config get may still display a calculated positive number such as 16 on a 16-core host. That number is the active thread count, not a fixed manual setting.

2. Should I raise nsslapd-numlisteners on every server?

No. The documented default is 1. Increase listener threads only when a large number of established client connections causes measured response-time degradation. Pending connection bursts are controlled separately by nsslapd-listen-backlog-size.

3. How do worker threads differ from listener threads?

Worker threads execute LDAP operations. Listener threads monitor established client connections and hand work to the pool. They solve different problems and are tuned separately.

4. What should nsslapd-maxdescriptors be relative to the operating system?

nsslapd-maxdescriptors must stay at or below the process file-descriptor limit from systemd LimitNOFILE. Usable client capacity is approximately nsslapd-maxdescriptors minus nsslapd-reservedescriptors. Raising the Directory Server value above the OS limit does not create additional usable descriptors.
