Manage 389 Directory Server Replication Agreements with dsconf

A replication agreement tells one 389 Directory Server replica how to send updates to another replica for a suffix. You create and manage agreements on the server that initiates replication sessions, not on the destination. This guide focuses on individual agreement lifecycle tasks with dsconf repl-agmt: list, inspect, create, modify, schedule, enable, verify, and delete.

For replication roles, changelog behavior, and topology design, read 389 Directory Server replication. For full supplier-to-consumer deployment, see single-supplier replication, multi-supplier replication, or cascading replication.

Tested on: Rocky Linux 10.2; 389 Directory Server 3.2.0.

Choose your task:

• Inspect an existing agreement
• Create a new agreement
• Change host, TLS, or bind settings
• Configure schedules or timeouts
• Pause or force replication
• Read agreement status fields
• Delete an agreement safely

How 389 Directory Server replication agreements work

A replication agreement is a directional link from one replica to another. The supplier (or hub) that owns the agreement connects to the destination, authenticates, and pushes updates recorded in its changelog.

Important points:

• Agreements are configured on the server that sends updates.
• Each agreement is directional. Multi-supplier replication needs a separate agreement in each direction.
• Creating ldap1-to-ldap2 does not create ldap2-to-ldap1.
• Agreements are per suffix. The same hosts can hold different agreements for different suffixes.
• Most agreement changes take effect without restarting Directory Server.

Typical agreement administration follows this order: inspect → create → tune → operate → verify → delete. You do not need to read every section in sequence; use the task links above to jump to the command you need.

Keep RUV, CSN, and topology theory in the replication architecture article. This page stays focused on agreement commands.

get versus status versus init-status

Use get before you change settings. Use status to see whether the last replication session succeeded. Use init-status only around initialization or reinitialization.

When Directory Manager passwords differ between the supplier and destination, pass consumer credentials to repl-agmt status so synchronization state and lag are read from the destination replica:

dsconf -y /root/dm.pw ldap1 repl-agmt status \
  --suffix "dc=example,dc=com" \
  --bind-dn "cn=Directory Manager" \
  --bind-passwd-file /root/consumer1-dm.pw \
  ldap1-to-consumer1

For the disposable agreement, use /root/agmt-delete-dm.pw instead.

dsconf repl-agmt command reference

Initialization uses repl-agmt init and repl-agmt init-status. See initialize and reinitialize replicas for the full procedure; this guide mentions init only where creation and verification require it. Role changes use replication promote and replication demote — see promote or demote a replica.

Lab environment and prerequisites

Examples use the shared replication lab with hostnames mapped in /etc/hosts (no DNS). Most tasks operate on an existing supplier-to-consumer agreement. Create and delete exercises use a separate disposable destination so you do not disturb live replication paths.

In this lab, ldap1 and ldap2 run on the same host (192.168.56.108). consumer1.example.com and agmt-delete.example.com both resolve to that address through /etc/hosts.

Map hostnames in /etc/hosts

Add matching entries on every host that runs dsconf or LDAP client commands for these examples. Edit the existing /etc/hosts line for 192.168.56.108 rather than appending a duplicate. Remove any conflicting mappings for consumer1.example.com or agmt-delete.example.com (for example 127.0.0.1 aliases) before you test replication.

Required mapping for this lab:

192.168.56.108 ldap1.example.com ldap1 consumer1.example.com agmt-delete.example.com

Confirm name resolution before you create or modify agreements:

for host in ldap1.example.com consumer1.example.com agmt-delete.example.com; do
  printf '%s: ' "$host"
  getent ahostsv4 "$host" | awk 'NR == 1 {print $1}'
done

Sample output:

ldap1.example.com: 192.168.56.108
consumer1.example.com: 192.168.56.108
agmt-delete.example.com: 192.168.56.108

Commands run on ldap1.example.com against instance ldap1 unless noted. Password files live under /root with mode 600:

If you already completed a topology guide and ldap1-to-consumer1 exists, start at List and inspect replication agreements. Use Create a replication agreement only when you need a new directional link on a destination that is not already covered.

Confirm the basics before you modify agreements:

• Replication is enabled on the suffix with dsconf ldap1 replication get --suffix "dc=example,dc=com".
• The destination replica is prepared (consumer, hub, or supplier role as required by your topology).
• The supplier can reach the destination hostname and LDAP port configured in the agreement. If your topology also has a separate return agreement, that peer must reach its supplier in turn.
• Clocks are synchronized on both hosts.
• The replication manager account or certificate identity exists on the destination.
• TLS is configured and CA trust is in place before you switch an agreement to LDAPS or StartTLS.
• For a new empty consumer, plan to run repl-agmt init (or pass --init at create time). Red Hat states that replication does not begin until a new consumer is initialized. For an already initialized destination, do not reinitialize; incremental replication resumes once the agreement is enabled and connectivity works.

If ou=People,dc=example,dc=com does not exist on your supplier, create it or change the test entry DNs in the verification section.

List and inspect replication agreements

List agreements for a suffix

List every agreement configured on ldap1 for dc=example,dc=com:

dsconf -y /root/dm.pw ldap1 repl-agmt list --suffix "dc=example,dc=com"

Sample output (trimmed):

cn: ldap1-to-consumer1

The same instance can hold different agreements for other suffixes. Always pass --suffix so you inspect the correct replicated area.

Display agreement configuration

repl-agmt get shows stored settings: destination host and port, connection protocol, bind DN and method, enabled state, schedule, timeouts, and fractional attribute lists when configured.

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output (trimmed):

cn: ldap1-to-consumer1
nsDS5ReplicaHost: consumer1.example.com
nsDS5ReplicaPort: 1389
nsDS5ReplicaTransportInfo: LDAP
nsDS5ReplicaBindDN: cn=replication manager,cn=config
nsDS5ReplicaBindMethod: simple
nsds5ReplicaEnabled: on

Record agreement settings before destructive changes. get is the authoritative view of what Directory Server will use on the next replication session.

Check initialization progress

After repl-agmt init, poll total initialization with init-status:

dsconf -y /root/dm.pw ldap1 repl-agmt init-status --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output when initialization completed earlier:

Agreement successfully initialized.

For runtime health checks and sample status output, see Verify an individual replication agreement.

Create a replication agreement

The lab already includes ldap1-to-consumer1 toward consumer1.example.com. The example below creates ldap1-to-agmt-delete on a disposable destination used only for the create-and-delete exercises in this guide. For full supplier, consumer, or multi-supplier deployment, follow the topology guide that matches your design.

Review required settings

Before you run repl-agmt create, decide:

Use a directional agreement name that states the source and destination role, such as ldap1-to-consumer1 or ldap1-to-agmt-delete.

Prepare the disposable destination

Provision a minimal consumer on agmt-delete.example.com before you create the agreement. In this lab, instance agmt-del listens on port 2390 on the same host as ldap1. Follow the consumer steps in single-supplier replication on the disposable instance only: enable the consumer role, create the replication manager, and leave the suffix empty. Do not point a second agreement at a live replica that already receives updates from another supplier.

Create the agreement with dsconf

Create a mode-600 password file on the supplier that matches the replication manager password configured on the disposable destination:

umask 077
read -rsp 'Replication manager password (agmt-delete): ' REPL_PASSWORD
echo
printf '%s' "$REPL_PASSWORD" > /root/agmt-delete-repl.pw
unset REPL_PASSWORD
chmod 600 /root/agmt-delete-repl.pw

Create the agreement on the supplier:

dsconf -y /root/dm.pw ldap1 repl-agmt create ldap1-to-agmt-delete --suffix "dc=example,dc=com" --host agmt-delete.example.com --port 2390 --conn-protocol LDAP --bind-method SIMPLE --bind-dn "cn=replication manager,cn=config" --bind-passwd-file /root/agmt-delete-repl.pw

Sample output:

Successfully created replication agreement "ldap1-to-agmt-delete"

Decide whether to initialize immediately

repl-agmt create accepts --init to run total initialization right after the agreement is created. Use it when the destination suffix is empty or must be replaced from the supplier.

Do not pass --init when the destination already holds authoritative data, when you are adding the return path in multi-supplier replication, or when another agreement already initialized the replica. For a new empty consumer such as agmt-delete.example.com, initialization is required before incremental replication can begin. For complete initialization and reinitialization procedures, see initialize and reinitialize replicas.

Initialize the disposable consumer after creation:

dsconf -y /root/dm.pw ldap1 repl-agmt init --suffix "dc=example,dc=com" ldap1-to-agmt-delete

Sample output:

Agreement initialization started...

Poll until initialization completes:

dsconf -y /root/dm.pw ldap1 repl-agmt init-status --suffix "dc=example,dc=com" ldap1-to-agmt-delete

Sample output:

Agreement successfully initialized.

Verify the new agreement

Confirm stored settings with repl-agmt get — hostname, port, protocol, bind DN, and enabled state should match your plan.

Run repl-agmt status after initialization completes. Last Update Status should end with Incremental update succeeded when replication is working.

For sample status output, field meanings, and an LDAP convergence test on the primary agreement, see Verify an individual replication agreement below.

Modify connection and authentication settings

Back up or record the current agreement with repl-agmt get before you change connection settings.

Confirm the destination hostname and port

Before you change connection settings, verify the destination is reachable:

nc -zv consumer1.example.com 1389

Sample output:

Ncat: Connected to 192.168.56.108:1389.

To update the stored hostname or port, pass both values to repl-agmt set. The replacement must identify the same prepared replica, or a destination you have intentionally migrated and validated:

read -rp 'New destination hostname: ' NEW_DESTINATION_HOST
read -rp 'New destination port: ' NEW_DESTINATION_PORT

dsconf -y /root/dm.pw ldap1 repl-agmt set \
  --suffix "dc=example,dc=com" \
  --host "$NEW_DESTINATION_HOST" \
  --port "$NEW_DESTINATION_PORT" \
  ldap1-to-consumer1

unset NEW_DESTINATION_HOST NEW_DESTINATION_PORT

Sample output:

Successfully updated agreement

Confirm the stored values:

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Confirm that nsDS5ReplicaHost and nsDS5ReplicaPort contain the exact hostname and port you passed to repl-agmt set.

Pointing an agreement at the wrong host or an uninitialized replica can introduce generation or topology problems. Verify get output and run a small LDAP write test after every connection change.

Change LDAP, LDAPS, or StartTLS settings

Update the connection protocol when TLS trust and hostname validation are already working on both hosts. On consumer1.example.com, instance ldap2 listens for LDAPS on port 1636, not the default 636.

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --conn-protocol LDAPS --port 1636 ldap1-to-consumer1

Sample output:

Successfully updated agreement

Confirm the stored protocol and port:

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output (trimmed):

nsDS5ReplicaHost: consumer1.example.com
nsDS5ReplicaPort: 1636
nsDS5ReplicaTransportInfo: SSL

dsconf accepts --conn-protocol LDAPS, but Directory Server stores the transport as SSL in nsDS5ReplicaTransportInfo. StartTLS is stored as TLS.

Check runtime health after the switch:

dsconf -y /root/dm.pw ldap1 repl-agmt status \
  --suffix "dc=example,dc=com" \
  --bind-dn "cn=Directory Manager" \
  --bind-passwd-file /root/consumer1-dm.pw \
  ldap1-to-consumer1

If LDAPS validation fails, roll back to plain LDAP on the lab port before you leave the agreement in a broken state:

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --conn-protocol LDAP --port 1389 ldap1-to-consumer1

Test LDAPS on a lab agreement before you apply the change in production. This lab switched ldap1-to-consumer1 to LDAPS on port 1636 and rolled back to LDAP on port 1389 successfully. Confirm the destination certificate matches consumer1.example.com and that the supplier trusts the issuing CA. Certificate-based replication authentication is covered in Secure replication with certificate-based authentication.

Change the replication bind identity

Update the bind DN and password together when you rotate the replication manager credential:

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --bind-dn "cn=replication manager,cn=config" --bind-passwd-file /root/consumer1-repl.pw ldap1-to-consumer1

Sample output:

Successfully updated agreement

Use mode-600 password files instead of passing passwords on the command line. In 389 Directory Server 3.2.0, replication create-manager deletes and recreates an existing manager entry, which resets its password. Check whether the manager exists before you run it on the destination replica.

Coordinate credential rotation across every agreement that authenticates with the same destination identity. A safer production pattern is to create a new authorized replication identity, update each agreement to use it, verify replication, and only then remove the old identity.

Confirm changes without restarting

Run repl-agmt get to confirm the stored values, then repl-agmt status to confirm the last session succeeded. Agreement changes do not require an instance restart. See Verify an individual replication agreement for how to read status output.

Configure replication schedules

Understand schedule syntax

nsDS5ReplicaUpdateSchedule uses HHMM-HHMM DDDDDDD, where each D is a day number (0 = Sunday through 6 = Saturday). Example: 0800-1700 12345 allows replication updates Monday through Friday between 08:00 and 17:00.

When the schedule is * or the attribute is absent, no custom restriction is applied and replication can run continuously.

Configure a custom schedule

Set a weekday business-hours window on ldap1-to-consumer1:

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --schedule "0800-1700 12345" ldap1-to-consumer1

Sample output:

Successfully updated agreement

Confirm the effective schedule:

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output (trimmed):

nsDS5ReplicaUpdateSchedule: 0800-1700 12345

Remove or replace a schedule

Return the agreement to continuous replication:

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --schedule "*" ldap1-to-consumer1

Sample output:

Successfully updated agreement

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output (trimmed):

nsDS5ReplicaUpdateSchedule: *

Test scheduled replication

To validate a schedule in a lab:

1. Set a narrow window that excludes the current time.
2. Write a directory change on the supplier outside the window.
3. Confirm the change does not appear on the destination immediately.
4. Wait until the window opens or temporarily restore --schedule '*' for testing.
5. Confirm queued changes replicate and repl-agmt status reports a successful update.

Full window testing can take hours. Record the schedule with get before and after each test.

Configure agreement timeouts and retry behavior

Set the connection timeout

--conn-timeout sets the per-agreement connection timeout in seconds. Derive the value from observed connection and replication times on your network rather than copying an arbitrary default.

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --conn-timeout 120 ldap1-to-consumer1

Sample output:

Successfully updated agreement

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output (trimmed):

nsds5replicaTimeout: 120

Configure busy-wait and session-pause intervals

When destinations frequently return busy responses, tune retry spacing on the agreement. Red Hat’s monopolization guidance uses a shorter busy-wait interval and a longer session pause between retries:

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --busy-wait-time 5 --session-pause-time 15 ldap1-to-consumer1

Sample output:

Successfully updated agreement

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output (trimmed):

nsds5replicaBusyWaitTime: 5
nsds5replicaSessionPauseTime: 15

Distinguish agreement and replica-level timeouts

--conn-timeout, --busy-wait-time, and --session-pause-time are agreement settings. --repl-release-timeout applies to the suffix replica and limits how long a supplier holds a replication session before yielding to other agreements. The documented default is 60 seconds; Red Hat warns that values above 120 seconds slow replication in most cases.

Raise the release timeout only when a supplier monopolizes replication sessions and shorter values did not help. This example sets 90 seconds:

dsconf -y /root/dm.pw ldap1 replication set --suffix "dc=example,dc=com" --repl-release-timeout 90

Sample output:

Successfully updated replication configuration

Red Hat requires an instance restart after changing this replica-level setting:

dsctl ldap1 restart

After the instance is back online, confirm the stored value:

dsconf -y /root/dm.pw ldap1 replication get --suffix "dc=example,dc=com"

Sample output (trimmed):

nsds5ReplicaReleaseTimeout: 90

This section covers agreement administration only, not full replication performance tuning.

Control agreement runtime behavior

Temporarily disable an agreement

Disable one agreement during planned maintenance on the destination:

dsconf -y /root/dm.pw ldap1 repl-agmt disable --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output:

Agreement has been disabled

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output (trimmed):

nsds5ReplicaEnabled: off

Re-enable an agreement

dsconf -y /root/dm.pw ldap1 repl-agmt enable --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output:

Agreement has been enabled

Queued updates are processed on the next replication session after the agreement is enabled.

Force an immediate incremental update

If the agreement is enabled and no custom schedule blocks replication, use repl-agmt poke to push pending incremental updates without reinitializing the destination:

dsconf -y /root/dm.pw ldap1 repl-agmt poke --suffix "dc=example,dc=com" ldap1-to-consumer1

Sample output:

Agreement has been poked

Verify the last session succeeded:

dsconf -y /root/dm.pw ldap1 repl-agmt status \
  --suffix "dc=example,dc=com" \
  --bind-dn "cn=Directory Manager" \
  --bind-passwd-file /root/consumer1-dm.pw \
  ldap1-to-consumer1

Sample output (trimmed):

Last Update Status: Error (0) Replica acquired successfully: Incremental update succeeded

When a custom schedule is active, follow the Red Hat force-update procedure:

1. Record the current schedule with repl-agmt get.
2. If a custom schedule is set, temporarily set --schedule '*'.
3. Disable the agreement.
4. Re-enable the agreement.
5. Restore the original schedule.
6. Verify Last Update Status in repl-agmt status.

Example when a weekday schedule was active:

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --schedule "*" ldap1-to-consumer1

dsconf -y /root/dm.pw ldap1 repl-agmt disable --suffix "dc=example,dc=com" ldap1-to-consumer1

dsconf -y /root/dm.pw ldap1 repl-agmt enable --suffix "dc=example,dc=com" ldap1-to-consumer1

Restore the original schedule:

dsconf -y /root/dm.pw ldap1 repl-agmt set --suffix "dc=example,dc=com" --schedule "0800-1700 12345" ldap1-to-consumer1

Confirm replication resumed:

dsconf -y /root/dm.pw ldap1 repl-agmt status \
  --suffix "dc=example,dc=com" \
  --bind-dn "cn=Directory Manager" \
  --bind-passwd-file /root/consumer1-dm.pw \
  ldap1-to-consumer1

Sample output (trimmed):

Last Update Status: Error (0) Replica acquired successfully: Incremental update succeeded
Replication Status: In Synchronization

This workflow forces pending incremental updates when a schedule blocked them. It is not the same as repl-agmt init, which performs a total update. Do not use repl-winsync-agmt poke for standard Directory Server replication agreements; that command applies to Windows synchronization agreements.

Verify an individual replication agreement

repl-agmt status is the primary runtime check for one agreement. Run it on the supplier that owns the agreement. When supplier and destination Directory Manager passwords differ, pass the destination credentials so lag and synchronization fields are populated from the consumer:

dsconf -y /root/dm.pw ldap1 repl-agmt status \
  --suffix "dc=example,dc=com" \
  --bind-dn "cn=Directory Manager" \
  --bind-passwd-file /root/consumer1-dm.pw \
  ldap1-to-consumer1

Useful fields in the output:

• Replica Enabled — agreement enabled state
• Update In Progress — active replication session
• Last Update Start / Last Update End — timestamps for the latest session
• Last Update Status — result of the latest incremental update
• Number Of Changes Sent — changes pushed in the last session
• Last Init Status — result of the last total initialization
• Replication Status — summarized synchronization state
• Replication Lag Time — time behind the supplier when available
• Destination host and port in the agreement title line

Healthy example (trimmed):

Status For Agreement: "ldap1-to-consumer1" (consumer1.example.com:1389)
Replica Enabled: on
Last Update Status: Error (0) Replica acquired successfully: Incremental update succeeded
Replication Status: In Synchronization
Replication Lag Time: 00:00:00

Connection failure when an agreement points at an unreachable destination port. Illustrative status output (do not run this against a production agreement):

Status For Agreement: "ldap1-to-consumer1" (consumer1.example.com:9999)
Replica Enabled: on
Last Update Status: Error (-1) Problem connecting to replica - LDAP error: Can't contact LDAP server (connection error)
Replication Status: Not in Synchronization: supplier (Unknown) consumer (Unknown) State (red) Reason (Consumer can not be contacted)

In a disposable lab only, you can reproduce this by setting --port 9999, running repl-agmt poke, capturing status, then restoring port 1389 and disabling and re-enabling the agreement before you trust status again.

Confirm data convergence with LDAP, not status text alone. Add or modify a marker entry on the supplier:

ldapadd -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -y /root/dm.pw <<'EOF'
dn: cn=agmt-test-entry,ou=People,dc=example,dc=com
objectClass: top
objectClass: person
cn: agmt-test-entry
sn: agmt
description: replication agreement validation
EOF

Sample output:

adding new entry "cn=agmt-test-entry,ou=People,dc=example,dc=com"

After a short wait, search for the entry on the destination. When Directory Manager passwords differ between hosts, store the consumer password in /root/consumer1-dm.pw on the supplier (mode 600) and pass it to destination LDAP commands:

ldapsearch -LLL -x -H ldap://consumer1.example.com:1389 -D "cn=Directory Manager" -y /root/consumer1-dm.pw -b "cn=agmt-test-entry,ou=People,dc=example,dc=com" -s base description

Sample output:

dn: cn=agmt-test-entry,ou=People,dc=example,dc=com
description: replication agreement validation

Modify the entry on the supplier and confirm the change replicates. If the agreement is enabled and no custom schedule blocks replication, run repl-agmt poke when the destination still shows the old value after a short wait:

ldapmodify -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -y /root/dm.pw <<'EOF'
dn: cn=agmt-test-entry,ou=People,dc=example,dc=com
changetype: modify
replace: description
description: agreement status verification
EOF

Sample output:

modifying entry "cn=agmt-test-entry,ou=People,dc=example,dc=com"

ldapsearch -LLL -x -H ldap://consumer1.example.com:1389 -D "cn=Directory Manager" -y /root/consumer1-dm.pw -b "cn=agmt-test-entry,ou=People,dc=example,dc=com" -s base description

Sample output (trimmed):

description: agreement status verification

For deeper entry comparison between two hosts, use ds-replcheck online as described in Comparing two Directory Server instances. Topology-wide monitoring belongs in dedicated operations documentation, not in per-agreement administration.

Delete an agreement safely

This section removes the disposable ldap1-to-agmt-delete agreement created earlier. Do not create a second live agreement to the same destination solely to demonstrate deletion.

Check the agreement before deletion

Record the configuration and status:

dsconf -y /root/dm.pw ldap1 repl-agmt get --suffix "dc=example,dc=com" ldap1-to-agmt-delete

dsconf -y /root/dm.pw ldap1 repl-agmt status \
  --suffix "dc=example,dc=com" \
  --bind-dn "cn=Directory Manager" \
  --bind-passwd-file /root/agmt-delete-dm.pw \
  ldap1-to-agmt-delete

Confirm no other supplier or hub depends on this agreement as its only path to a destination.

Disable and validate before deleting

In production, disable the agreement first and confirm you are removing the intended replication path:

dsconf -y /root/dm.pw ldap1 repl-agmt disable --suffix "dc=example,dc=com" ldap1-to-agmt-delete

Sample output:

Agreement has been disabled

Delete the agreement

dsconf -y /root/dm.pw ldap1 repl-agmt delete --suffix "dc=example,dc=com" ldap1-to-agmt-delete

Sample output:

Agreement has been successfully deleted

Confirm it no longer appears in the list:

dsconf -y /root/dm.pw ldap1 repl-agmt list --suffix "dc=example,dc=com"

Sample output (trimmed):

cn: ldap1-to-consumer1

ldap1-to-agmt-delete should be absent from the list.

Disable replication on the disposable consumer

Deleting the supplier agreement does not remove the consumer role from agmt-del. Because this instance exists only for the create-and-delete exercise, disable replication on the disposable destination:

dsconf -y /root/agmt-delete-dm.pw agmt-del replication disable --suffix "dc=example,dc=com"

Sample output:

Replication disabled for "dc=example,dc=com"

If the instance is no longer needed, remove it separately after replication is disabled, following Removing an instance from a replication topology.

Understand what deletion does not remove

Deleting an agreement does not:

• Disable replication for the suffix
• Delete directory data on the destination
• Remove the destination server from the topology
• Clean a replica ID or RUV
• Delete agreements configured on other servers

To remove a server from a topology safely, see Removing an instance from a replication topology.

Clean up marker entries

Remove test entries created during verification:

ldapdelete -x -H ldap://ldap1.example.com:389 -D "cn=Directory Manager" -y /root/dm.pw "cn=agmt-test-entry,ou=People,dc=example,dc=com"

The command exits without output when the entry is deleted successfully.

Common agreement-management problems

For log analysis, error-code investigation, and recovery after extended outages, see 389 Directory Server replication troubleshooting and Red Hat Directory Server 13: Troubleshooting replication-related problems.

References

• Red Hat Directory Server 13: Configuring and managing replication
• Red Hat Directory Server 13: Forcing replication updates
• Red Hat Directory Server 13: Preventing monopolization of a replica in a multi-supplier replication topology
• Red Hat Directory Server 13: Removing an instance from a replication topology
• 389 Directory Server: dsctl, dsconf, and dsidm design
• 389 DS upstream issue: Scheduled replication problem

Summary

389 Directory Server replication agreements are directional links configured on the sending replica with dsconf repl-agmt. Use list and get to inspect stored settings, status and init-status for runtime state, create and set to add or change connection and schedule options, enable / disable to control individual agreements without disabling suffix-wide replication, and poke to force an immediate incremental update when no schedule blocks replication. Verify changes with LDAP write tests and, when you need entry-level proof, ds-replcheck. Record configuration before destructive changes, and distinguish deleting an agreement from removing a server from the topology.
